Summary of Contents for roger schult W2344 MK2
- Page 1 W2344 MK2 RS-MATRIX Operating Manual Quick Guide W2344 MK2 RS-MATRIX Operating Manual Version 01.2018 roger schult D 50374 Erftstadt Peter-May-Str. 104 -1 -...
-
Page 2: Table Of Contents
Table of Contents Page Table of contents Introduction and safety instructions Concept Controls of the W2344 MK2 RS-MATRIX Part 1 Controls of the W2344 MK2 RS-MATRIX Part 2 Data sheet Functions Scope of delivery Disposal Manufacturer, contact and service -2 -... - Page 3 Dear customer, congratulations for your purchase of the W2344 MK2 RS-MATRIX. We thank you for your confidence. This unit was built according to the best available state of technology and fulfils all European and national standards. The EMV conformity was proven, all documents and declarations can be made available on request.
-
Page 4: Concept
Being a completely analog tool for the flexible editing of stereo signals, the W2344 MK2 RS-MATRIX offers the solution for those problems. Besides two switchable stereo inputs the first section provides precise level controls for left and right input channel, a summing possibility for left and right channel for an easy control of the mono compatibility of the signal, and a phase reverse switch for the left channel. - Page 5 All switches of the W2344 MK2 RS-MATRIX are illuminated in active state to provide reliable optical control of the settings at any time. Stepped filter frequency potentiometers are available as an option. This...
-
Page 6: Technical Data
Technical Data Tentative spec sheet, 01/2018 Filter - side signal Frequency range 125 Hz to 6 kHz (375 Hz to 18 kHz on activated x3-function) Gain, 41 stepped Alps-rotary control range -10 dB / +10 dB Q-factor, 11-position switch 0.3 / 0.5 / 0.7 / 1.0 / 1.5 / 2.5 / 4 / 6 /10 HP on left stop, LP on right stop „S“-solo, switch solo/preview side channel... -
Page 7: Functions
- Quick start guide in German - Quick start guide in English Compatibility The compatibility certification records for this product are available upon request from the manufactur As all Roger Schult products, the W2344 MK2 RS-MATRIX is hand-crafted and precision-engineered in Germany. -7 -... -
Page 8: Disposal
Information on appropriate waste collection points can be obtained at your responsible authorities or at the dealer from whom you purchased this product. Manufacturer roger schult german audio lab Peter-May-Str.104 D 50374 Erftstadt www.rogerschult.com info@rogerschult.com W2344 MK2 RS-MATRIX – Extended image processing system -8 -...
