0202250 – Vertical Broadband HF Antenna
Thank you for purchasing the 0202250 Broadband HF antenna. For your safety and to get the best
possible results, we recommend that you read this manual to fully familiarize yourself with the antenna.
Please keep this manual in a safe place for your future reference.
Features
Ultra wide-band coverage.
Thick base element (2mm) for heavy operation.
Stainless steel bolt and nuts for longer life.
Before assembly
Please make sure all parts are enclosed in box as listed below:
No.
Description
1
Matching section assembly
2
Worm cramp for Aluminium element (1)
3
Aluminium element (2)
4
Aluminium element (3)
5
Aluminium element (4)
6
Aluminium element (5)
7
U bolt (w/lock washer, nut)
8
Tapping screw (M5 x 8)
9
Tapping screw (M4 x 8)
10
Hex wrench
11
Self adhesive tape (20cm)
Specifications
Feature
Type
Frequency:
Transmit
Receive
Max. Power
Impedance
VSWR
Connector
Max. Length
Weight
Wind survival
Mast size range
BENELEC PTY. LTD
581-587 Gardeners Road, Mascot, Sydney, NSW 2020
Mail : PO Box 21, Mascot, NSW 1460, Australia
Web Site:
www.benelec.com.au
PROFESSIONAL WIRELESS PRODUCTS
Instruction and Assembly Manual
Description
Ground plane antenna
3.5 ~ 57 MHz
2.0 ~ 90 MHz
250 Watts (SSB)
50Ω
<1.5:1 (Typical)
SO-239
7.13m
3.2Kg
108 km/h
2.8 ~ 5.4 cm
ACN# 064708390
Qty
1
1
1
1
1
1
2
3
2
1
1
Telephone
:
+61-2-93647000
Fax
:
+61-2-93647099
Mobile
:
0418 646595
Email
:
david@benelec.com.au
Advertisement
Table of Contents
Related Manuals for Benelec 0202250
Summary of Contents for Benelec 0202250
- Page 1 0202250 – Vertical Broadband HF Antenna Instruction and Assembly Manual Thank you for purchasing the 0202250 Broadband HF antenna. For your safety and to get the best possible results, we recommend that you read this manual to fully familiarize yourself with the antenna.
- Page 2 VHWR Frequency Warning Before you install your antenna, select the most available open site away from electric power lines and telephone lines. To get the maximum performance from your antenna, it must be installed at least 10.67m above the ground. This antenna has a long element and is heavy to carry or install by single person.
- Page 3 Antenna Assembling Diagram Assembling 1. Slide the element (2) into the element (1) 200mm, and then secure worm clamp. 2. Slide out the element (3) from the element (2) until all 3 holes of both elements can be seen together. Using tapping screws (M5 x 8), tighten both elements.
