This product hos been corefully engineered ond monufoctured to give you dependoble operotion'.
Prior to use, pleose ensure thot you reod ond undersiond oll woirings, coutions ond initructions
included in this instruction. monuol, ond those published by your u-"hi"l" bottery monufocturer
ond monufoclurer of ony device intended to be'used with this unit. Pleose retoin ihis monuol for
s.IN.I POWER STATION WITH AIR CO'IIPRESSOR
ORDER CODE: A67HY
FEATUR,ES:
. 600 AMP BATTERY
JUMPER
. 260 PSIAIR COMPRESSOR
O 2OO WATT POWER INVERTOR
O I2 VOI-T POWER STATION
. WORK TIGHT
IMPORTANT:
future reference.
I
CONTRO[S:
l.
Rubberized Hondle
2. Air Compressor On/Off Switch
3. Air Compressor Gouge
4.
Heovy Duty Booster Clomps
5.
l2V Socket
6.
LED Work Light OnlOff Swilch
7.
Voltmeter
8.
Bottery Stotus Button
9. 5 LED Work Light
10. lnvertor On/Off Switch
I l . A C O u t l e t
12. Air Hose Comportment
13. Jumpstorfer On/Off Switch
14. Air Cooling Fon
IMPORTANT SAFEGUARDS:
o To protect ogoinst electricol hozords or shock,
woter or sources of moisture.
do not expose chorger, odoptors, or unit to
,YIAPIIN ETECTRONICS
[TD.
o Jumpstort vehicles in well ventiloted oreos only.
o Monitor the pressure gouge during us9.. g9 coreful not to over-inflote
obiects.
r lhis device contoins. seoled,,non-sp-illoble
leod ocid botteries ond must be disposed of
properly ot the,end of the product's life. Contoct your locol outhority for odvice on tlie proper
disposol,/recycli ng procedure.
o lf the u.nit is domoged by dropping or other heovy impocts,
seek professionol guidonce from
o quotttted engtneer betore using ogoin.
WORK LIGHT:
.
!jrp.!V turn the work light switch (on front ponel) ro ON posirion.
o The 5 x LEDs will illuminote.
r Turn OFF when not in use.
BAITERY STATUS:
r Press ond hold the Botfery Level Button.
o The Voltoge Meter will show the bottery level.
o A reoding of I3-_l 5 volts meons your
iumpstort system is reody to use.
o A reoding of 12 volts meons your
iumpsfort iystem shouli be rechorged os soen os
possible.
o A reoding of below |2 volts meons you should chorge your
iumpstort system immediotAly.
CHARGING YOUR JUiiPSTART SYSTEM:
This unit hos o mointenonce free, built-in seoled leod ocid bottery. Alihouqh the Jumpstort Svsterrl
orrives porliolly chorged.from the foctory, it must be fully chorged for 3d hours beior. firsi ,re,
even if the bottery stotus lights indic-ote o "full" chorge. This initiol chorge preconditions the bot-
tery ond will provide optimum performonce in the Tuture. Foilure to dlow this procedure moy
permonently domoge the bottery.
AC CHARGING AT HOME:
l. Use o stondord domestic Ac 230v moins power socket to chorge from the moins.
2. Only use the chorger provided with unit.
3. Keep the power on,/off switch in the OFF position whilst chirging.
4. Plug the AC chorging cord into ony stondtrd woll outlet ond"the"other end into the ACl
chorging input sockel.
5. A full chorge from AC tokes opproximotely 34 hours.
6. Do not exceed moximum AC chorging time of 48 hours.
Z. Ensure thot chorging tokes ploce in o well ventiloted oreo ond in on oreo where the cho,
stotus con be regulorly monitored.
DC CHARGING IN YOUR VEHICIE:
L K,eep.the_p_ow3r
on/ofl switch in the OFF position whilst chorging.
2 flu^S.!h9 D.C chorging cord into ony 12 vol't (cigoreite lighter) s-ocklet ond the orher end inro rhe
AC/DC chorging input socket.
3. A full chorge from DC tokes opproximotely l2 hours.
4. Do not exceed moximum DC chorging time of 24hours.
USING THE AIR CO'YIPRESSOR:
i . Open the comportment door ot the bock of the power centre ond pull out the oir hose. Moke
sure the nozzle lever is in thg UP position.
2. Attoch the volve odoptor to the volve stem on the tyre ond push the volve odopior lever down
to lock into ploce.
3. Turn compressor switch on front ponel to the ON position.
4. Monitor the pressure g-ouge while infloiing - do not exceed recommended pressure for the
tyre,/device you ore infloting. lt is recommended thot you use o seporote oir gouge to check
6
7
8
9
o Close supervision is necessory when used neor children.
. Do not use unit for opplicotions other thon its intended use.
'
Rechorge bottery ofter eoch. use, or every 2 months to moximize the life of the bottery.
o Avoid touching your eyes when working with botteries.
o lt bottery ocid comes in contoct with skin or eyes, immediotely wosh with woter ond seek
medicol ottention.
r Remove metol
iewelry or other metollic obiects thot moy be exposed to the bottery clomps
trom your body when using the unit.
r Never ollow the red ond block bottery clomps to touch eoch other or to touch the some metol
obiect ot the some time.
. Alwoys connectlhe red (+) clomp to the positive bottery terminol first.
r Do not connect block (-) clomp
lo the negotive bottery terminol, connect it to o non-moving,
eorthed metol port of your vehicle.
