- Page 1 Ayre AX-7 Owner’s Manual A y r e Integrated Amplifier...
-
Page 3: Table Of Contents
Table of Contents Ayre ..... . . 2 Welcome to Installation ....3 Connections and Operation . -
Page 4: Ayre
Welcome to Ayre Please send in your warranty Your Ayre AX-7 offers a significant advance in the registration card so we can musical performance of high-fidelity equipment. stay in contact with you. The warmth and immediacy of a live performance are apparent from the first listening. -
Page 5: Installation
The infrared beam will also travel through glass. The Ayre AX-7 is easy to hook up and use. The following guidelines will ensure that the installation goes smoothly. A good location for your integrated amplifier is near eye level in an open-backed cabinet or on a shelf. -
Page 6: Tape Outputs
In this modern era of diverse source components, it has become impractical to pre-label the inputs with the actual name of the source. Instead, the AX-7 has simple icons that allow you to easily remember the selector button associated with each source component. -
Page 7: Loudspeaker Outputs
“Moon” input of the AX-7. This will prevent the undesired possibility of creating a feedback loop when making a recording. The Ayre AX-7 drives the loudspeakers with balanced outputs. Since none of the output terminals are grounded, connecting any of them to ground may result in damage to the amplifier. - Page 8 AC Power The best sound quality is Connect the Ayre AX-7 to an unswitched power normally achieved when the source. When the unit is first connected to the AC AX-7 is plugged directly into power, the input selector will default to “Star”, the the wall outlet, without using volume control will default to “11”, the display will...
-
Page 9: Operation
The remote control may also be used to change the volume. At the heart of the Ayre AX-7’s control system is a sophisticated microprocessor. This microprocessor is normally “asleep” and all digital systems are turned off, including the master clock. When the microprocessor receives a command, either from the front panel or the remote control, it “wakes up”... -
Page 10: Input Source Selection
low setting. After that, the current volume setting is retained in memory, and will remain constant when changing inputs or when the unit is placed in “Standby”. A y r e Input Source Selection The source component may also The input selector buttons are located at the right be selected with the remote side of the unit. -
Page 11: Tape Output
AX-7 (including the ground connection), avoiding the possibility of undesired ground loops. The display of the AX-7 may be turned off, if desired. A single blue light indicates that the display is turned off. When further commands are... - Page 12 If you are using a surround-sound processor, connect the front left and right outputs of the processor to one of the inputs on the AX-7. Please note that the AX-7 can accept either balanced or unbalanced signals. To activate the “Processor Pass-Through” mode for that input, remove the AC power from the AX-7 for at least 10 seconds.
- Page 13 AX-7. When that input is selected, the preamplifier section of the AX-7 is set to unity gain (0 dB), and the volume is controlled directly from the surround-sound processor. The volume indicator of the AX-7 will display “PP”...
-
Page 14: Specifications
Numbers and Specifications Power Output 60 watts per channel continuous into 8 ohms 120 watts per channel continuous into 4 ohms Maximum Input Level 4 V rms – unbalanced inputs 8 V rms – balanced inputs Input Impedance 20 k – unbalanced inputs 40 k –... -
Page 15: Warranty Statement
Warranty Statement Your Ayre AX-7 integrated amplifier is warranted against defects in workmanship and materials for a period of five years from the date of purchase. This warranty is transferable to subsequent purchasers within the original five-year period. - Page 16 or to Ayre’s authorized agent. 3. Ayre reserves the right to inspect any product that is the subject of any warranty claim prior to repairing or replacing it. Final determination of warranty coverage lies solely with Ayre. Out-of-warranty claims will be billed for labor, materials, return freight, and insurance as required.
- Page 17 6. Ayre does not authorize any third party, including any dealer or sales representative to assume any liability of Ayre or make any warranty for Ayre. The unit must not have been altered or improperly serviced. The serial number on the unit must not have been altered or removed.
-
Page 18: Notes
A Place for Notes Rev. 1.1... - Page 20 Ayre Acoustics, Inc. 2300-B Central Avenue Boulder, Colorado 80301 www.ayre.com +1-303-442-7300...
