Uhf wireless guitar transmitter and receiver with 6.5mm mono plug
Hide thumbs
1
2
3

Advertisement

Table of Contents

UHF Wireless Guitar Transmitter and Receiver
With 6.5mm Mono Plug
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AM4109 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DigiTech AM4109

Summary of Contents for DigiTech AM4109

  • Page 1 UHF Wireless Guitar Transmitter and Receiver With 6.5mm Mono Plug User Manual...

  • Page 2: Specifications

    Specifications: Transmitter: Frequencies: CH1: 520.5MHz CH2: 532.9MHz Freq stability: 0.002% Range: 60m max Receiver: Sensitivity: 2µV (12dB) Signal/noise: 90dB Dimensions: 115(W) x 80(D) x 25(H) mm Flyout: 1. Telescopic Antenna 2. 3 x LED Indicators 3. Channel Selector 4. Power Input 5.
  • Page 3 Installation and Operation (Receiver) For best results, the receiver should be placed at least 1m off the ground, and should not be placed directly in front of the speaker system. Position the receiver on a stable platform and attach the AC adaptor. Plug one end of the provided lead into the AF output connector of the receiver, and the other end to the input jack of your amplifier or PA system.
