Prowill SmartPOS10 User Manual

Main Features

● 10.1
● Android 5.1.1 System，High compatibility.
● Quad core CPU，1.6GHz.
● Support USB, DSB, OTG2.0 interface for different USB devices to
connect with Q-Boss.
● Built-in WIFI and Bluetooth.
● Support Clock Function.
User's
● Support restaurant, retail POS software installation.
● Support external audio for end user to connect small voice box etc.
Manual

Notice

SmartPOS10
● The printer should be put in dry and clean place.
● Do not touch the screen and plug the power connector when your hands
are with water or oil, to avoid any damage to touch screen or prevent
electric short circuit.
● Users must use our standard power adapter.
● Be careful when you connect the cable into the interface in order to avoid
any damage to any component.
● Before you turn off the printer power, please long press the tablet
ON/OFF button till you see Power-off icon from touch screen, click Power
Off, and then press the printer ON/OFF button to turn off.
● Please don't disassemble the printer without professional support.
● Please keep this manual for reference.
● Please turn off the printer power before cleaning this machine.
● Do not touch print head by your hand and any metal object,avoid scratch
and damage onto print head.roller, gap sensor, surface and touch screen.

Unpacking

After unpacking the unit,please check that all the necessary accessories
are included in the package.
Q-Boss Printer
Power adapter
Power cable

Smart Printing

Paper Roll
IPS LCD，1366*768 HD resolution display.
"
1 pcs
1 pcs
1 pcs
1pcs

Technique Spec

SmartPOS10
Model
Display 10.1" IPS LCD,1366*768 HD resolution
Operation Five points multi-touch,capacitive panel
System Android 5.1.1(lollipop)
CPU Quad CPU, integrated GPU, 1.6GHz
RAM DDR3,1GB
ROM 1-2GB
Flash 8GB
TF card 1-32GB
Ethernet port 100Mbps (IEEE 802.3u)
USB Port USB2.0 / DSB / OTG2.0
WIFI Build-in WIFI (IEEE 802.11b/g/n)
Bluetooth Build-in Bluetooth (Bluetooth2.1)
RS232 (Optional) Standard UART Port
3G module(Optional) Support USB Dongle 3G card
Speaker Dual track 4Ω/2W
Paper type 58mm thermal paper, 70mm out diamater max.
Resolution 384 dots/line
Print speed 90mm/s (Max)
Print width 48mm (Max)
Temperature test Thermistor
Paper exist detection Photoelectric sensor
PC437/Katakana/PC850/PC860/PC863/PC865/Wes
t Europe/Greek/Hebrew/East Europe
Code page /Iran/WPC1252/PC866/PC852/PC858/IranII
/Latvian/Arabic/PT151,1251/PC747/WPC1257
/Vietnan/PC864/PC1001/Uygur/Thai
UPC-A, UPC-E, EAN(JAN)13, EAN(JAN)8,
Barcode CODE39, CODEBAR, ITF, CODE93, CODE128,
QRCODE
ANK font Font A:12*24dots Font B:9*17dots
Font
Korean,simplified/traditional Chinese :24*24dots
Graphics BMP graph can download to the flash of printer
Dimension and Weight350mm*330mm*130mm,
Power adapter Input:AC220 Output:DC12V/3A
Work & storage 0～45℃, 10～90%RH
2.29kg
