INSTALLATION & CONFIGURATION MANUAL
OMNI‐HD1
HD IP Streaming Server
ONELAN Limited
Andersen House, Newtown Road,
Henley-on-Thames, Oxfordshire. UK, RG9 1HG
Tel: +44(0) 1491 411400
Fax: +44(0) 1491 579254
Web site: www.onelan.com
1
OMNI-HD1 Manual V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OMNI-HD1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ONELAN OMNI-HD1

  • Page 1 INSTALLATION & CONFIGURATION MANUAL OMNI‐HD1 HD IP Streaming Server ONELAN Limited Andersen House, Newtown Road, Henley-on-Thames, Oxfordshire. UK, RG9 1HG Tel: +44(0) 1491 411400 Fax: +44(0) 1491 579254 Web site: www.onelan.com OMNI-HD1 Manual V1.0...

  • Page 2: Table Of Contents

    Content SAFETY PRECAUTIONS...........................3 PACKAGE CONTENTS............................3 PRODUCT DESCRIPTION..........................4 SPECIFICATIONS.............................5 UNPACKING and INSPECTION..................................6 HARDWARE INSTALLATION and CONNECTIONS............................6    Front‐Panel..............................7 Procedure to connect to the Streaming Server via the Network port.............8 Streaming methods: (Note: If using VLC player, please install version 2.0.8 or newer version)........18 Case 1: DLNA.........................................18 Case 2: UDP/RTP Multicasting..................................20 Case 3: TCP/UDP/RTP Unicasting................................22 OMNI‐HD1 Streaming Server Notes......................24 OMNI-HD1 Manual V1.0...

  • Page 3: Safety Precautions

    If the device has been in a cold environment allow it to warm to room temperature for at least 2 hours before connecting power PACKAGE CONTENTS This package contains:  One OMNI-HD1 Streaming Server  One Adaptor  One installation / configuration manual Inspect the package before starting installation to ensure there is no damage and all supplied contents are present.

  • Page 4: Product Description

    PRODUCT DESCRIPTION ONELAN's OMNI-HD1 IP Streamer allows the user to stream any one audio/video source over a IP Network to multiple Smart HDTV's or connected computers within the IP Network. The IP Streamer accepts a HDMI, Component, or Composite video input and the unit is designed to deliver a rich HD/SD Streaming experience for its users deploying MPEG-2 or MPEG-4 standards.

  • Page 5: Specifications

    Consumption 500mA Operating Temperature F to +104 F (0 C to +40 F to +140 F (-10 C to +60 Storage Temperature Dimension 236mm x 155mm x 35mm Weight 940g *Specifications subject to change without prior notice OMNI-HD1 Manual V1.0...

  • Page 6: Unpacking And Inspection

    SmartTV, the set-top-box, and the controlling PC, should be located within same network segment/LAN. 2. If a DHCP server is present in the private network, the OMNI-HD1 streaming server will use the IP address assigned by the DHCP server.

  • Page 7: Front-Panel

    Indicates device is encoding video using MPEG-2 Indicates device is encoding video using AVC Indicates device is encoding audio using MPEG-1 Layer 2 For recording Indicates device is encoding audio using AAC AC-3 Indicates device is encoding audio using AC-3 OMNI-HD1 Manual V1.0...

  • Page 8: Procedure To Connect To The Streaming Server Via The Network Port

    Procedure to connect to the Streaming Server via the Network port The following procedure will allow the installer to setup the Streaming Server via the GUI 1. Connecting a standard CAT5e cable from OMNI-HD1 Network port to to a switch then connecting from the switch to TV and PC.
  • Page 9 4. Select Local Area Connection Icon Then Right Click – Select Properties Internet Protocol Version 4(TCP/IPv4) Properties OMNI-HD1 Manual V1.0...
  • Page 10 5. Select “Obtain an IP address automatically” & “Obtain DNS server address automatically” 6. After setting the PC to obtain IP address & Obtain DNS server automatically Select Start ==> Computer ==> Network OMNI-HD1 Manual V1.0...
  • Page 11 7. After selecting Network- the OMNI-HD1 Icon will show up on the right side under Media Devices. Each device found will be displayed by the Device Address. 8. Right Click on the device icon, Select 'View Device Webpage' OMNI-HD1 Manual V1.0...
  • Page 12 9. Overview Welcome page will be displayed OMNI-HD1 Manual V1.0...
  • Page 13 On the Welcome Screen, we have added a tool to help the installer locate a unit in a rack or headend. Press the LED ON button (shown below). This will cause the CFG LED light to flash continuously for the installer to identify and locate the OMNI‐HD1. To turn off, simply press the LED tool again. OMNI-HD1 Manual V1.0...
  • Page 14 Encoder Setup : User Name: admin Default Password: Admin123 Once the Welcome Page is displayed select the Encoder Setup tab and the below Login “Authentication Required” screen will be presented. Enter the User Name and Password then click Login. OMNI-HD1 Manual V1.0...
  • Page 15 1. Connect Video source to HDMI or YPbPr port. 2. Connect Video with supporting Closed Caption source to CVBS port. 3. A supporting Closed Caption Player/TV must be used for this function. Closed Caption input Network Configuration : OMNI-HD1 Manual V1.0...
  • Page 16 Administration: OMNI-HD1 Manual V1.0...
  • Page 17 Saving your configuration files: We highly recommend you save your encoder configuration files. Simply Click the “Backup” button and the config files will be saved to you computer. To upload a configuration file‐ simply click “Choose File” then locate the file you want to upload. Click “Upload Settings” to install the configuration files. This function is helpful to the installer when installing a large number of encoders in a single system. We highly recommend saving the settings of your encoder. A “config.cfg” file will be created. Locate the file My Computer> C Directory > Documents and Settings> User>My Documents>Downloads>configs.cfg. OMNI-HD1 Manual V1.0...

  • Page 18: Streaming Methods: (Note: If Using Vlc Player, Please Install Version 2.0.8 Or Newer Version)

    Streaming methods:  (Note: If using VLC player, please install version 2.0.8 or newer version) Case 1: DLNA ex. VLC media player http://@169.254.22.127:8888/VideoInput/play.ts Streaming Setup Example: Enable/Disable HTTP Enable/Disable Authentication Enter RADIUS IP Enter RADIUS Secret, the password between HDIP server and RADIUS server OMNI-HD1 Manual V1.0...
  • Page 19 Using VLC media player, select Media ==> Open Network Stream... On the Network Protocol, key in the Output IP address and Output Port as following example, ex. http://172.21.6.88:8888/VideoInput/play.ts Press Play button to view the video. OMNI-HD1 Manual V1.0...

  • Page 20: Case 2: Udp/Rtp Multicasting

    Case 2: UDP/RTP Multicasting ex. VLC media player rtp://@224.1.1.8:1234 ex. VLC media player rtp://@224.1.1.8:1234 Streaming Setup Example: Enable/Disable Multicast Enter Multicasting Group IP address between 224.x.x.x and 239.x.x.x Recommend from 1024 to 65535 Multicast TTL Select to Enable RTP, from 1 to 255 Disable to UDP Default 4 OMNI-HD1 Manual V1.0...
  • Page 21 Using VLC media player, select Media ==> Open Network Stream... On the Network Protocol, key in the Output IP address and Output Port as following example, ex. rtp://@224.1.1.8:1234 Press Play button to view the video. OMNI-HD1 Manual V1.0...

  • Page 22: Case 3: Tcp/Udp/Rtp Unicasting

    Case 3: TCP/UDP/RTP Unicasting ex. VLC media player ex. VLC media player udp://@:1234 udp://@:1234 Streaming Setup Example: Select TCP/UDP/RTP Unicasting Enter Player’s IP Address and Port number as required Recommend from 1024 to 65535 Press to add the Unicasting, upto 8 Unicasting OMNI-HD1 Manual V1.0...
  • Page 23 Using VLC media player, select Media ==> Open Network Stream... On the Network Protocol, key in Output Port as following example, ex. udp://@1234 Press Play button to view the video. OMNI-HD1 Manual V1.0...

  • Page 24: Omni-Hd1 Streaming Server Notes

    OMNI‐HD1 Streaming Server Notes PRODUCT NOTES: ITEM VALUE USER NAME / PASSWORD SERIAL NUMBER INSTALLATION DATE PURCHASE DATE DEVICE NAME FIRMWARE VERSION STREAMING METHOD OMNI-HD1 Manual V1.0...
