Model : HTC-7AH2910HD
IR LED Night Vision Camera
Made in KOREA
■ FEATURES
ㆍ SONY 1/3" Super HAD High Resolution Color Camera
ㆍ CDS Auto Switching IR-LED Control (80pcs)
ㆍ Viewable Length at Night : 150 ft.
ㆍ Vari-Focal Auto Iris Lens
( 2.9mm~10mm / F1.2 )
ㆍ Focus, Viewing Angle & DC Level adjustment externally
ㆍ Cable located in the bracket
ㆍ Weather resistance (IP67)
■ DIMENSION
122.5
18
17.5
87.5
108
■ SPECIFICATIONS
114.7
100.9
8
31.6
56
(unit : mm)
Model : HTC-7AH2910HD
Long Range IR Camera
Instruction Guide
Please read this manual thoroughly before use.
※
Keep this manual handy for future reference.
Long Range IR Camera
Advertisement
Table of Contents
Related Manuals for Hunt Electronic HTC-7AH2910HD
Summary of Contents for Hunt Electronic HTC-7AH2910HD
-
Page 1: Specifications
Model : HTC-7AH2910HD Long Range IR Camera Instruction Guide Model : HTC-7AH2910HD IR LED Night Vision Camera Please read this manual thoroughly before use. ※ Keep this manual handy for future reference. Made in KOREA ■ FEATURES ■ SPECIFICATIONS ㆍ SONY 1/3" Super HAD High Resolution Color Camera ㆍ... -
Page 2: Exploded View
Long Range IR Camera ■ EXPLODED VIEW VIDEO BRACKET POWER BASE RING SUN SHIELD (FOCUS) BRIGHT DARK Near (VIEWING ANGLE) Wide Tele BODY RING WINDOW RING ■ INSTALLATION 1) Bracket & Camera Mounting - Affix the bracket to the mounting surface. - Drill up the supplied screws on the mounting surface through the holes on the bracket.
