Summary of Contents for ECOsee ESC-DF700R
-
Page 1: Instruction Manual
Vandal-proof IR Dome Camera Instruction Manual Before operating the unit, please read this manual thoroughly and retain it for future reference. - Page 2 Safety Precautions DO NOT ATTEMPT TO DISASSEMBLE THE CAMERA. Risk of Electric Shock, Do not Open CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER NO USER- SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSON This symbol is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
- Page 3 Warning This product has patented for configuration and appearance design, and copying is not permitted. If this product fails to operate normally, contact authorized distributor. Never disassemble or modify the product in any way. Problem caused by unauthorized user disassembly or repairs are out of warranty scope.
-
Page 4: Important Safety Instructions
Cautions Do not drop objects on the products or apply strong shock to it. Keep it away from a location subject to excessive vibration or magnetic-field interference. Do not install in a location subject to high temperature (over 122°F or +50℃ ), low temperature（below 14°F or -20℃）, or may cause fire. - Page 5 Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. Only use attachment/accessories specified by the manufacturer. For added protection for this product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system.
-
Page 6: Table Of Contents
Table of Contents Chapter 1 Overview ............Instruction ....................Specification ............Package ..........Product Parts Chapter 2 Operating Instruction ........9-10 ..........Connection ..........Installation ........Before Installation ......Installing the Camera ....... Cautions for Installation Chapter 3 Common Troubleshooting ......Chapter 4 Current Maintenance ........ -
Page 7: Chapter 1 Overview
Chapter 1 Overview Instruction This is a Vandal-proof IR Dome camera. It saves costly installation time and provides more convenience and functions. Built-in 3.6mm 1/3” IR 1.3 Megapixel Lens Built-in ICR 2 Pcs of IR LED Array, Total Power 4W Visible Range up to 20m/60feet in Total Darkness 3-Axis Vertical/Horizontal/Rotational Full Metal Body Vandal-proof... -
Page 8: Package
Model 3.6mm IR 1.3MP Lens Angle of View 70° Mount Power Supply DC 12V Power Max. 1W (Max. 6 W with IR Cut Filter ON) -20°C ~ 50°C Operating IR Light 2 Pcs of Array LED (2W Each) General IR Range 20m/60ft±3m/10ft Weather Proof IP66... -
Page 9: Product Parts
Fixed Holder Connecting Ring Holding Housing Eyeball IR LED Array Photovaristor Function of product parts Fixed Holder—Fixing the camera to the ceiling or wall Connecting Ring— Fixing the main housing and the eyeball to fix the monitoring direction Holding Housing — Holding the eyeball Eyeball —... -
Page 10: Chapter 2 Operating Instruction
Chapter 2 Operating Instruction Connection Connect one end of the BNC Cable to the terminals of the monitor. Connect the other end of the BNC Cable to the VIDEO OUT Then, plug in the power adapter into the power receptacle. The screen will be displayed when the monitor is on. -
Page 11: Installing The Camera
Installing the Camera Installation process is illustrated as below Step 1: Place the dielectrial paper on the wall/ceiling, which is to protect the camera from damage by conducted current. Then fix the fixed holder to the wall/ceiling with 3 screws. *Pay attention to the cable trough. -
Page 12: Chapter 3 Common Troubleshooting
Chapter 3 Common Troubleshooting If encounter troubles in use of the bullet camera, please refer to the following instructions. For more information, please consult nearby local authorized distributor. Troubles Solution Check the power supply, or the connection among the No Video Output cable, camera and monitor.
