DigiSpec DTT-PRO Operation Manuals

Digital date / time titler
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DTT
DTT
DTT -Pr
DTT
DTT
Digital Date / Time Titler
-Pr
-Pr o o o o o
-Pr
-Pr
May 2011
Operation Manual
TM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DTT-PRO and is the answer not in the manual?

Questions and answers

Summary of Contents for DigiSpec DTT-PRO

  • Page 1 -Pr o o o o o DTT -Pr Digital Date / Time Titler May 2011 Operation Manual...
  • Page 2 -Pr o o o o o DTT -Pr CAUTION! RISK OF ELECTRICAL SHOCK! DO NOT OPEN! TO PREVENT ELECTRIC SHOCK, DO NOT REMOVE THE COVER. DO NOT EXPOSE THE EQUIPMENT TO RAIN OR MOISTURE. NO USER SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL.

  • Page 3: Table Of Contents

    DATE FORMAT ........................8 DST............................8 EXIT............................9 DISPLAY............................9 TITLER..........................10 TIME-DATE........................10 VIDEO LOSS........................10 VL OUTPUT......................11 TIME-DATE......................11 CAPTURE......................12 VL MESSAGE.......................12 EXIT.........................12 GRAYSCALE........................13 BORDER...........................13 EXIT.............................14 Video Loss Detection..........................14 Master Reset............................14 Warranty..............................15 FIGURES Figure 1: DTT-Pro Front Indicator LEDs and Programming Push buttons.......5 Figure 2: DTT-Pro Rear Connections....................5...

  • Page 4: Introduction

    VCR/DVR, or printed on a video printer. The characters have full programmability in 8 gray scales along with background in 8 gray scales. In the event the video input fails or not used the DTT-Pro will output a composite video image with the T/D Title information visible.

  • Page 5: Connections

    Power Input The DTT-Pro operates from a multi voltage input 7.5V to 24VDC 65 mA or 24 VAC 100 mA . The power input connector is a standard 2.1mm x 5.5mm DC Coax power jack, must have positive (+) on the center and negative (- or ground) on the outer shell.

  • Page 6: Operating Mode

    PROGRAMMING MODE The DTT-Pro is programmed by pressing the “Select” button while in operating mode then the “MAIN MENU” will appear and the Setup indicator (Yellow LED) will light. Press the “UP” or “Down” buttons to move the cursor up or down and press the “Select”...

  • Page 7: Time-Date

    : Year (00-99). Note: the year 2000 is 00 : Hours (1-12 with AM/PM, or 00-23, depending on 12 or 24 time format) : Minutes (00-59) : Seconds (00-59) TIIME-DATE T-DSETTING T-D SETTING JAN-01-08 8:00:00 A TIME FORMAT 12 Hour DATE FORMAT MMM-DD-YY EXIT DTT-Pro (DATE/TIME TITLER)

  • Page 8: Time Format

    “USA” , “CANADA” , “AUSTRALIA” , “TASMANIA” or ”OFF” DST. This mode automatically adjusts for daylight saving time, a 1-hour decrease in the Fall and a 1-hour increase in the Spring for the selected countries or terrritories. DTT-Pro (DATE/TIME TITLER)

  • Page 9: Exit

    Move the cursor by pressing the “Up” or “Down” buttons to access the “DISPLAY” menu and press the “Select” button. The “DISPLAY” menu will apprear. DISPLAY MAIN MENU TITLER TITLER SETUP TIME-DATE TIME - DATE VIDEO LOSS DISPLAY GRAYSCALE EXIT BORDER EXIT DTT-Pro (DATE/TIME TITLER)

  • Page 10: Titler

    DISPLAY TITLER TIME-DATE VIDEO LOSS GRAYSCALE BORDER EXIT VIDEO LOSS Move the cursor by pressing the “Up” or “Down” buttons to access the “VIDEO LOSS” menu and press the “Select” button. The “VIDEO LOSS” menu will apprear. DTT-Pro (DATE/TIME TITLER)

  • Page 11: Vl Output

    The input video is passed through the DTT-Pro continuously whether there is a video loss condition or normal condition. This will allow devices in line with the DTT-Pro to continue to record or to make their own decision if video is lost or not.

  • Page 12: Capture

    : Turn on the “VIDEO LOSS” message that display on screen in the video loss mode : Turn off the “VIDEO LOSS” message that display on screen in the video loss mode VIDEO LOSS VL OUTPUT TIME-DATE CAPTURE TITLER VL MESSAGE EXIT DTT-Pro (DATE/TIME TITLER)

  • Page 13: Grayscale

    “Select” button for selecting the desired gray scale border color. Setting this will effect with character border color in Operating Display Mode. BORDER DISPLAY AAAAAAAAAAAAAAAAAAAA TITLER TIME-DATE AAAAAAAAAAAAAAAAAAAA VL OUTPUT AAAAAAAAAAAAAAAAAAAA GRAYSCALE BORDER EXIT Color of character border will change following border gray scale select. DTT-Pro (DATE/TIME TITLER)

  • Page 14: Exit

    THE DTT-Pro DEFAULTS TO THE FACTORY SETTINGS. Power down DTT-Pro by taking out the power line. Then press and hold the “Up” button and plug in the power. Hold the “Up” button until the Copyright and Version display appear on the screen.

  • Page 15: Warranty

    The RMA (Return Material Authorization) number must be obtained by contacting Seller prior to the shipment of the product for return. The RMA number is valid only for 15 days from the date of issue. The RMA number must be clearly displayed on all shipping labels. DTT-Pro (DATE/TIME TITLER)
  • Page 16 DigiSpec Inc. DigiSpec Inc. DigiSpec Inc. DigiSpec Inc. DigiSpec Inc. 1906 Treble Dr. Humble, Texas 77338 Tel: 281-540-6665 Fax: 281-540-6972 Email: john@digispecvideomotion.com Web Site: www.digispecvideomotion.com...
