Changing the MCA-40860 Splitter
The Multicom MCA-40860 comes with an unbalanced splitter
(50/30dBmV output), preinstalled in the unit and a balanced splitter
(50/50dBmV output), in the box.
To change the splitter follow these instructions:
Splitter:
1. Open unit by unscrewing the 6
screws on the top of the unit
2. Open the top
3. Pull splitter straight up
(see illustration)
4. Replace alternative splitter in
exact location
5. Replace top of unit and screws
securely
Established in 1982, Multicom, Inc. is a manufacturer and full-line
stocking distributor for end-to-end integration of communication
solutions.
Multicom stocks over 13,000 products from more than 270 of the
world's major manufacturers. These products are used to acquire,
process and distribute television, data, voice, security, and traffic
control signals over fiber optic, copper, and coax cable.
®
MCA-40860
40db Gain 860MHz
www.multicominc.com
*Specifications subject to change without notice
Indoor Distribution
Amplifier
Multicom, Inc.
Ph: 800-423-2594 | 407-331-7779
Fax: 407-339-0204
Email: multicom@multicominc.com
© Multicom, Inc. 2015
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for MULTICOM MCA-40860
- Page 1 Established in 1982, Multicom, Inc. is a manufacturer and full-line stocking distributor for end-to-end integration of communication solutions. Multicom stocks over 13,000 products from more than 270 of the Multicom, Inc. world’s major manufacturers. These products are used to acquire, Ph: 800-423-2594 | 407-331-7779 www.multicominc.com...
- Page 2 Description Return Loss Out: <12dB Test Points: -20dB The dual output MCA-40860 is a superior quality push-pull wall- Power Input: 110 V AC, 60 Hz, 8 W mounted distribution amplifier producing signals with low-noise Operating Temperature: 14° F to 122° F and harmonic distortion.
