Page 1 User Manual Model K4-02...
Page 2: Table Of Contents
Table of Contents 1. Important Information 2. Kinoma Create hardware 4. First Run 7. Powering on/o 8. Charging internal battery 9. Network Connection: Wi-Fi 10. Settings 14. On-board applications 17. Setting up a bootable SD card 18. Connecting to PC 19.
Page 3: Important Information
Android, or run any of our samples (included with Kinoma Studio) on your Kinoma Create. Our team is ready to support you as you work with your Kinoma Create. The best way to get answers to your questions is to post on the Kinoma Forum (http://forum.kinoma.com/).
Page 4 Kinoma Create Front Removable sensor cover 16 pins configurable for: • 5V or 3.3V power • Ground • Digital input/output • Analog input • I2C • PWM • Serial Speaker microSD slot Microphone USB 2.0 including USB On-The-Go Color screen...
Page 5 Kinoma Create Back Stand Holes Stand Dowels Reset 50 pins for: • 3.3V power • Ground • Digital input/output • Analog input • I2C • PWM • Serial Removable access panel...
Page 6: First Run
Kinoma Create First Run Remove back cover and pull out battery contact shield. Begin charging device with supplied charger. (Note: Kinoma Create uses special charging circuitry and requires a sensing charger to correctly charge the battery. Only use the provided charger, since other chargers may not charge the battery).
Page 7 Kinoma Create First Run Press the power button on the back of Kinoma Create. Kinoma Create typically takes 35 seconds to boot up. Use the Wi-Fi app to add your Kinoma Create to your network..
Page 8 Kinoma Create First Run Set the time zone for your device.
Page 9 If powered up, and in hibernate mode, a short press wakes up Reset device button. Use paper clip or similar to reach reset button and perform a hard reset. This screen shows during boot up. Kinoma Create typically takes 35 seconds to start.
Page 10: Charging Internal Battery
Charging internal battery Kinoma Create uses special charging circuitry and requires a sensing charger to correctly charge the battery. Only use the provided charger, since other char- gers may not charge the battery...
Page 11: Network Connection: Wi-Fi
Clicking the “Select network” button displays a list of available networks. Select a network and enter password if necessary. Kinoma Create remem- bers the last configured Wi-Fi network. A er connecting to a network the device IP address is shown on the...
Page 12: Settings
Settings The Settings app on Kinoma Create allows for setting attributes, updating device and viewing device information. If updates are available an UPDATE notification will appear. Tap to update.
Page 13 Settings Name: Set Device name if needed. This is the name that this Kinoma Create will use for network connections, including debugging in the Kinoma Studio IDE. Time zone: It is important to set the local timezone for apps that use time and date based APIs.
Page 14 Kinoma Create. Note: Built-in apps, such as Wi-Fi and Settings cannot be deleted. Debugging: Kinoma Create can be set to allow debugging over Wi-Fi and require a password to debug. Kinoma So ware: Shows the current...
Page 15 Setup SD card: Format and partition an SD to become a bootable file system Clear Caches: Allows clearing of Kinoma Studio App, Cookie and HTTP caches MAC Address: Shows the MAC address of this Kinoma Create. The MAC address is the unique id of the device.
Page 16 On Board Apps Battery: Shows current charge status on the tile and chargingand usage history in the app view. File Sharing App: Allows mouning your Kinoma Create on your PC (Windows and Mac). File Sharing implements the WebDAV protocol...
Page 17 3.3 or 5 volts. Input pins will handle up to 3.3v. Files: Files app provides simple view and management functionality for files on Kinoma Create. It can display PNG and JPEG images, MPEG-4 files, and the first 8KB of text based files. Individual files can be deleted.
Page 18 On Board Apps Logs: Presents information about the operation of Kinoma Create. Kinoma Create logs PinMux settings, Settings, system events and Wi-Fi configurations. Developers can add new logs or data to existing logs. Samples: Shows current contents from the Kinoma GitHub Samples repository.
Page 19: Setting Up A Bootable Sd Card
Setting up a bootable SD card Install an SD card and you can set it up as a bootable volume. As part of the setup process, the latest Kinoma Create setup image will downloaded. Kinoma Create will start from a bootable SD card if present.
Page 20: Connecting To Pc
Connecting to a PC You can connect your Kinoma Create to your PC via either Micro USB or Mini USB to power it. If you connect via the Mini USB Port, you can access the serial console.
Page 21: Using Hardware Pins (Front Pins)
Using Hardware Pins (Front) Front Pins: The 16 front facing pins can be targeted by the Front Pins app to support Digital, Analog In, and I2C connections. Power can be supplied at 3.3 or 5 volts. Input pins will handle up to 3.3v.
Page 22: Using Hardware Pins (Rear Pins)
Using Hardware Pins (Rear) Rear Pins: The 50 pins accessible behind the rear access panel have dedicated functionality to support Digital, Analog Input, PWM, I2C, and Serial connections. Power can be supplied at 3.3 or 5 volts. Input pins will handle up to 3.3v. For more information on coding with the hardware pins visit kinoma.com/create...
Page 23: Kinoma Create Stand
Kinoma Create Stand Kinoma create includes an adjustable stand. Use the dowels in the rear in the stand holes to set the stand to the angle desired.
Page 24: Fcc Statement
FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Page 25 FCC Radiation Exposure Statement This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.
Page 26 Canada Statement This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
Page 27 Canada Statement (continued) This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. Cet émetteur ne doit pas être Co-placé ou ne fonctionnant en même temps qu'aucune autre antenne ou émetteur.
Page 28 Marvell, Kinoma, and the M logo are registered trademarks of Marvell and/or its a iliates. Other names and brands may be claimed as the property of others. Kinoma Create incorporates open source so ware; details are at http://kinoma.com/create/opensource/. Hardware design files provided under Creative Commons Attribution 4.0 International License.
