  • Page 1 Pool Entry System In Pool Deck Stairs Owner's Guide and Warranty 365-2020...

  • Page 2: Safety Precautions

    SAFETY PRECAUTIONS FIG. 2 READ AND FOLLOW ALL INSTRUCTIONS Failure to follow important safety instructions and precautions may result in serious personal injury. 1. The Stair Entry System must be installed in accordance with these instructions. 2. NEVER JUMP OR DIVE from the platform or steps. The Stair Entry System is for sitting, standing, and entering or exiting the pool only.
  • Page 3 FIG. 4 FIG. 3 Turn the assembly upright. Locate two (2) handrails and attach them to the stairs using four (4) 1/4” x 1-3/4” long screws. Tighten securely. NOTE: If your pool is not filled with water, moving the stair assembly into the pool will be easier if you attach the handrails after the stairs are inside the pool.
  • Page 4 FIG. 5B - 48” TALL POOLS Lift the stair assembly into the pool being careful not to Recheck the staircase and platform position in relation to contact and/or damage the pool liner with the handrail ends the pool wall and make any final adjustments to its location if they are already installed (see NOTE above).

  • Page 5: Repair And Maintenance

    Attach Staircase/Platform Assembly To Pool Attach Platform Facing to Platform Frame 48” Tall Pools Only - See Fig. 5B Due to differences in deck construction, fasteners for Fasten the platform facing to the platform using three (3) 1/4” securing the platform to your deck are not provided. screws and washers.

  • Page 6: Exploded Assembly

    EXPLODED ASSEMBLY 8” X 16” X 2” THICK CONCRETE BLOCK WALL CAPSTONES (NOT PROVIDED) In Pool Stair Entry System - Deck *Model ___________ *(write model number here) ITEM # PART NO. QTY. DESCRIPTION Stair Pack *(write pack number here) *__________ 349-1048 Inside Stairs 349-1039...

  • Page 7: Five Year Limited Warranty

    In Pool Stair Entry System FIVE YEAR LIMITED WARRANTY TERMS AND CONDITIONS Retain this warranty along with your sales receipt and/or proof of purchase. 1. Hoffinger Industries is the warrantor of this product. 2. This warranty is extended to the original purchaser (consumer) only. 3.
  • Page 8 Change of Design: Hoffinger Industries expressly reserves the right to change or modify the design and construction of any product in due course of our manufacturing procedures, without incurring any obligation or liability to furnish or install such changes or modifications on products previously or subsequently sold. HOFFINGER INDUSTRIES •...
