BCM Advanced Research T-1100 Assembly Manual

Book size pc
Hide thumbs

Advertisement

Quick Links

Download this manual
T1100
Book Size PC
Assembly Guide
BCM Advanced Research

Advertisement

loading

Related Manuals for BCM Advanced Research T-1100

Summary of Contents for BCM Advanced Research T-1100

  • Page 1 T1100 Book Size PC Assembly Guide BCM Advanced Research...

  • Page 2: Chapter 1 Introduction

    SOHO users or PC players. Inside this elegant-designed case, it has a powerful motherboard that has all the functions a user needs. This Assembly Guide will help a user understand the components of T-1100 and lead a user to assemble the system with detailed steps and instructions.
  • Page 3 1-2 Description of The Structure Specification Description Processor Socket 370 for Intel Pentium II/ III, Celeron PPGA/ FCPGA processor, optimized for F.S.B 66/ 100/ 133 MHz System memory Support 2 banks of SDRAM up to 1GB Hard Disk Support Slim 2.5" HDD Dimension 62mm(H) x 272mm(W) x 252mm(D) 3.0 ±0.5kg...
  • Page 4 1-4 Back Panel (Fig. 4) Fig.4 1. PS/2 mouse connector 2. 2 RJ45 Jack for network 3. 3-1xParallel port 4. 4 2xSerial ports 5. Power connector 6. Power voltage setting 7. Power supply 8. PS/2 keyboard connector 9. 2xUSB ports 10.
  • Page 5 1-5 Description of Layout and Component Components (Fig. 5) 1. Power supply 2. CD-ROM cable 3. HDD cable 4. Power/ Audio cable 5. IEEE 1394+ USB cable 6. Motherboard 7. System fan 8. Serial port cable...
  • Page 6 Enlarged view of the system (Fig. 6)

  • Page 7: Chapter 2 Assembly Procedure

    Chapter 2 Assembly Procedure Attention! This procedure is for the users who choose the slim CD-ROM, slim CD-RW, or slim DVD-ROM as the standard equipment. If you don't want to install these disc drives as mentioned above, you can ignore the steps: 2-3, 2-4, 2-10, 2-13, and 2-14. In the following procedure, we just use the term slim CD-ROM to refer to slim CD-RW and slim DVD-ROM.
  • Page 8 Squeeze a small amount of grease on the chip of the CPU and place the CPU fan heatsink on the CPU aligning it with the socket base. Later, attach the fan heatsink clip to the socket. (Fig. 13) Install the fan heatsink cable header to the motherboard connector. (Fig.
  • Page 9 2-11 Screw the slim HDD into the hard disk drive bracket. (Fig. 17) 2-12 Connect the 44-pin IDE Cable to the HDD connector with the correct orientation. (Fig. 18) 2-13 Align the 40-pin IDE cable with the CD-ROM adapter by the ▲...

  • Page 10: Chapter 3 Important Notes

    Chapter 3 Important Notes 3-1. When you connect the HDD cable, please check if the orientation is correct. There is a closed pin on the cable preventing the wrong installation, which means that you will not be able to connect the IDE cable to the slim HDD with the wrong orientation.
  • Page 11 You may connect them with the wrong orientation; hence the slim CD-ROM will not work. The ▲ mark is to help you tell which orientation is correct. (Fig. 25) 3-3. It is very important to align the CPU fan heatsink with the socket base. You should check the installing orientation of the CPU fan heatsink;...
  • Page 12 3-4. Please remember to adjust the voltage setting of the power supply, according to the local voltage, before turning on the system power. The wrong voltage setting may cause damage to T-1100. (Fig. 27) 3-5. Please check if the connecting orientation of the 8-pin CD-ROM power cable is correct.
