Summary of Contents for Audio Test Solutions MSAT -PSTN

  • Page 2: Table Of Contents

    Contents 1. FEATURES ........................3 2. EQUIPMENT DESCRIPTION ................. 3 3. INSTALLATION ......................5 4. OPERATION ........................5 5. TROUBLESHOOTING ....................7 6. SPECIFICATIONS ......................8 Ligado Networks www.ligado.com...

  • Page 3: Features

    1. FEATURES Telephone Foreign Exchange Subscriber (FXS) Service:  RJ-11 port for standard or cordless analog telephones  RJ-45 port for MSAT-G2 handset  Ringer Equivalence (REN) = 3 Note: Fax machines, dial-up modems and other non-telephone devices will not operate with this device.
  • Page 4 Back Panel:  Optional +12VDC Port: Optional power connection (2-pin)   Local/MSAT toggle switch: Local mode only used for software upgrades RS-232 Serial Port: Used for software upgrades Rear Panel Front Panel LED Indicators (see figure 3):  POWER: Lights up when the unit is powered up. Unit receives power from the MSAT-G2 radio through the RJ-45 handset port ...

  • Page 5: Installation

    3. INSTALLATION:  Remove MSAT-G2 Handset (RJ-45 plug) from the Transceiver Unit (TU)  Connect one end of the supplied inter-connect cable to the MSAT PORT of the MSAT-PSTN Interface. Connect the opposite end to the Handset Port of the MSAT-G2 Radio If 12 VDC power is connected to the MSAT-G2 radio the “POWER”...
  • Page 6 Once the call is completed the user simply hangs up. The “HOOK” LED on the  front panel of the MSAT-PSTN interface will turn off Receiving Calls: The telephone will ring normally when a call is received. The “RING” LED on the ...

  • Page 7: Troubleshooting

    Receiving Two-way radio PTT Call:  A double ring sequence is heard generated by the telephone for incoming Two- way radio (PTT) calls (ring-ring pause) Pick-up the telephone to hear active talkers then press the ‘#’ key to PTT when ...

  • Page 8: Specifications

    SPECIFICATIONS Power and Size Voltage / Current / 11V. 18V DC / 200mA DC @ +12V/DC Temperature F to 104 F (-20 C to 40 Voltage obtained from the MSAT-G2 radio when interfaced with the included 12" RJ-45 CAT-5 cable Size/Weight 136.5 mm deep x 168.2mm width x 25.4mm high 5-3/8"...
  • Page 9 10802 Parkridge Boulevard Reston, VA 20191 TEL: (877) 678-2920 FAX: (703) 390-2770 www.ligado.com Mailing Address: Audio Test Solutions, Inc. 4890 Vandaveer Road Billings, MT 59101 Shipping Address: Audio Test Solutions, Inc. 350 S. Billings Blvd, Suite 1C Billings, MT 59101...
