Summary of Contents for digitalview HD-3000
- Page 1 HD/SD-SDI to HDMI adaptor board HD-3000 Manual Specifications subject to change without notice 1 of 15 © Digital View Ltd – Doc Ver 1.01: 7 July, 2017 Page...
-
Page 2: Table Of Contents
Table of Contents Introduction Connectors, Pin outs & Jumpers Board Dimensions Signal Support Mode Table Specification Warranty, Caution & Limitation of Liability, Trademarks Contact details Revision History Specifications subject to change without notice 2 of 15 © Digital View Ltd – Doc Ver 1.01: 7 July, 2017 Page... -
Page 3: Introduction
Dual channels input port supported. HD-3000 supports Path A (HD-SDI input from J1 port convert to output HDMI at HDMI1/HDMI1A port) and Path B (HD-SDI input from J2 port convert to output HDMI at HDMI2/HDMI2A port). See Figure below : c. - Page 4 g. Status LEDs on board : The definition of the LED1, LED2, LED3, LED4 are : Description LED1 / LED2 Green LED on : Signal detected Green LED Blinking : No signal detected LED3 / LED 4 Green LED on : Signal output Green LED off : No signal output Specifications subject to change without notice 4 of 15...
-
Page 5: Connectors, Pinouts & Jumpers
2. CONNECTORS, PINOUTS & JUMPERS The various connectors are: Summary: Connectors Description Type / Use SD/HD-SDI 1 Input BNC connector SD/HD-SDI 2 Input BNC connector SD/HD-SDI 1 re-clock loop through output BNC connector SD/HD-SDI 2 re-clock loop through output BNC connector RS-232 &... - Page 6 Description Type / Use HDMI2 HDMI 2 Output HDMI connector HDMI1A Alternate HDMI 1 Output JST BM20B-SRDS (Matching type : JST SHDR-20V-S-B) HDMI2A Alternate HDMI 2 Output JST BM20B-SRDS (Matching type : JST SHDR-20V-S-B) Power Input (Alternate) Molex 43650-0200 compatible (Matching connector type : Molex 43645-0200 compatible) (Matching power cable : P/N 426013800-3) Power Input...
- Page 7 Summary : PinOuts : CN1 – RS-232 & I C control : JST B6B-XH-A (Matching type : XHP-6) SYMBOL DESCRIPTION SCLK I2C_SCLK SDATA I2C_SDATA RS-232 Tx data Ground RS-232 Rx data CN4 – External I/O connector : Hirose DF13-6P-1.25DSA (Matching type : Hirose DF13-8S-1.25C) SYMBOL DESCRIPTION 3.3V output...
- Page 8 SYMBOL DESCRIPTION RXC- TMDS Data C- RX0+ TMDS Data 0+ RX0- TMDS Data 0- RX1+ TMDS Data 1+ RX1- TMDS Data 1- RX2+ TMDS Data 2+ RX2- TMDS Data 2- Ground Ground MSTR2_SCL Reserved MSTR2_SDA Reserved DDC_5V +5V power supply for DDC (optional) Hot plug detection DDC_SCL DDC serial clock...
- Page 9 SYMBOL DESCRIPTION RX2- TMDS Data 2- Ground Ground MSTR2_SCL Reserved MSTR2_SDA Reserved DDC_5V +5V power supply for DDC (optional) Hot plug detection DDC_SCL DDC serial clock DDC_SDA DDC Data VCC1 VCC 5V output VCC2 VCC 5V output S1 – Alternate power on/off switch connector (Matching type : XHP-2) SYMBOL DESCRIPTION...
-
Page 10: Board Dimensions
Ready-made 3D Pro-E (SLDPRT) drawing files - Save time and effort for your system volumetric analysis design. Includes jpg file previews. Please go to download at http://www.digitalview.com/accessories/hd-3000 The maximum thickness of the adaptor board is 18mm (measured from bottom of PCB to top of components, excluding the BNC connectors. -
Page 11: Signal Support Mode Table
4. SIGNAL SUPPORT MODE TABLE Mode 576i50 (PAL) 480i60 (NTSC) 720p60 (4:2:2) 720p59.94 (4:2:2) 720p50 (4:2:2) 720p30 (4:2:2) 720p29.97 (4:2:2) 720p25 (4:2:2) 1035i60 (4:2:2) 1035i59.94 (4:2:2) 1080p30 (4:2:2) 1080p29.97 (4:2:2) 1080p25 (4:2:2) 1080p24 (4:2:2) 1080p23.98 (4:2:2) 1080psf30 (4:2:2) 1080psf25 (4:2:2) 1080psf24 (4:2:2) 1080psf23.98 (4:2:2) 1080i60 (4:2:2) -
Page 12: Specification
5. Specification Supported serial interface standard SMPTE 292M, 259M-C, 424M, 425M (Level A) Supported video mode 576i50 (PAL) 480i60 (NTSC) 720p60 (4:2:2) 720p59.94 (4:2:2) 720p50 (4:2:2) 720p30 (4:2:2) 720p29.97 (4:2:2) 720p25 (4:2:2) 1035i60 (4:2:2) 1035i59.94 (4:2:2) 1080p30 (4:2:2) 1080p29.97 (4:2:2) 1080p25 (4:2:2) 1080p24 (4:2:2) 1080p23.98 (4:2:2) -
Page 13: Limitation Of Liability
TRADEMARKS The following are trademarks of Digital View Ltd: Digital View • HD-3000 • Specifications subject to change without notice 13 of 15 © Digital View Ltd – Doc Ver 1.01: 7 July, 2017... -
Page 14: Contact Details
Digital View has offices in Asia, Europe and USA : Digital View Inc. 18440 Technology Drive Building 130 Morgan Hill, California, 95037 Tel: (1) 408-782 7773 Fax: (1) 408-782 7883 Sales: ussales@digitalview.com EUROPE Digital View Ltd. 6 Marylebone Passage, London, W1W 8EX, Tel: +44-(0)20-7631-2150 Fax: Fax: +44-(0)20-7631-2156 Sales: uksales@digitalview.com... -
Page 15: Revision History
Revision History Date Rev No. Page Summary 30 Sept 2016 1.00 First Issue version. 7 July 2017 1.01 - Correct pin definition of CN1 pin 1 & 2 - Update new Digital View HK office address - Add document revision history section Specifications subject to change without notice 15 of 15 ©...
