Installation
and
Service
Manual
Read ALL
INSTRUCTIONS
carefully.
Eramco • PO Box 519 • Royse City, TX 75189-0519 • 1-972-635-9565
This manual is copyright protected by ERAMCO. Any reproduction of this manual, in part or full, without the written permission of ERAMCO,
constitutes a violation of the U.S. copyright laws and is subject to prosecution.
©Printed in the U.S. by the Graphics Productions Department of ERAMCO, 1998.
Air Cleaners
Series 3000
Part No. 775-0299-497 Rev. 1C
Advertisement
Table of Contents
Related Manuals for Eramco Dust Free 3000 Series
Summary of Contents for Eramco Dust Free 3000 Series
-
Page 1: Air Cleaners
Part No. 775-0299-497 Rev. 1C This manual is copyright protected by ERAMCO. Any reproduction of this manual, in part or full, without the written permission of ERAMCO, constitutes a violation of the U.S. copyright laws and is subject to prosecution. -
Page 2: Performance Overview
PERFORMANCE OVERVIEW The Series 3000 air purifier is designed to remove airborne particulates and/or gases and odors from the air that passes through it. It is a modular unit where the filter housing and blower housing are in separate cabinets that are then assemble in the field. The air volume with clean filters wil range from 3000 - 4800 CFM depending on the filter configuration and ducting. -
Page 3: Unit Location
UNIT LOCATION The Eramco air cleaners should be suspended from the ceiling at a height of 15 feet or less above the floor. Position units as shown in the following illustrations. If you need additional installation advise contact the distributor/dealer from whom you purchased the equipment. Call the factory if the distributor/dealer is not available. - Page 4 INSTALLATION UNPACKING Upon receipt, immediately inspect the carton for damage during transit. Signs of rough handling may indicate internal damage in the air cleaner. Carefully unpack the unit and examine it for concealed shipping damage. If the unit is damaged, contact the carrier to file a claim. PREPARATION Carefully read the entire manual before starting installation.
- Page 5 INSTALLATION Verify that the electrical service is the correct voltage, current capacity and phase as listed on the unit nameplate. Refer to the wiring diagram and verify that the motor and the control transformer are wired correctly. Install an electrical disconnect to ensure safe servicing of the unit and emergency shut down. Check electrical code for location and type of disconnect required.
-
Page 6: Fan Shaft Position Adjustment
INSTALLATION BELT TENSION 3. Check the blower fan for proper (1" Maximum) alignment. The fan should be centered in the housing. The belt should be tightened so that you can push down on the belt with one finger depressing the belt one inch in the center between the pulleys (Fig. -
Page 7: Fan Rotation
INSTALLATION FAN ROTATION Fan rotation is toward the cutoff point or clockwise viewed from the pulley end of the blower shaft (Fig. 4). PULLEY ALIGNMENT Proper pulley alignment is necessary to prevent PULLEY ALIGNMENT excess wear of the fan belt and pulleys. To adjust, remove the two 1/4"... -
Page 8: Roof Mount
INSTALLATION ROOF MOUNT The unit should be supported on beams or pads that are high enough so that water on the roof cannot rise to the bottom of the unit. If 4"x4" timers are used, be sure that they are both long enough to support the weight and oriented so as to transfer the weight of the unit to the roof and the underlying support structure. -
Page 9: Maintenance
MAINTENANCE Filters must be replaced with filters of the same size, type, and efficiency rating in order to maintain the performance of the unit. Incorrect filters can lead to premature motor failure and will void the manufacturer's warranty. Check with the distributor or manufacturer to determine the exact filter configuration for the specific installation. -
Page 10: Replacement Parts List
REPLACEMENT PARTS LIST Part No. Description Hogs hair washable pre-filter (Set of 2). 6" 30/40% pleated pre-filter (Box of 4). Spark arresting pre-filter, metal mesh (Set of 2). Disposable synthetic fiber pre-filter (Box of 12). Oil impinger pre-filter (Set of 2). 30/40% Duo Cube particle filter (Set of 2).
