- Page 1 Premier HD HD2200 High Definition Downconverter Installation & Operator’s Manual © November 2000 Snell & Wilcox Ltd, Durford Mill, Petersfield, Hampshire, GU31 5AZ, United Kingdom. Tel: +44(0) 1730 821188. Fax: +44(0) 1730 82119 HD22OP271100 Version 1 Issue 1...
-
Page 2: Safety Warnings
SECTION 0 Explanation of Safety Symbols This symbol refers the user to important information contained in the accompanying literature. Refer to manual. This symbol indicates that hazardous voltages are present inside. No user serviceable parts inside. This unit should only be serviced by trained personnel. Safety Warnings Servicing instructions, where given are for use by qualified service personnel only. - Page 3 SECTION 0 Power cable supplied for countries other than the USA The equipment is normally shipped with a power cable with a standard IEC moulded free socket on one end and a standard IEC moulded plug on the other. If you are required to remove the moulded mains supply plug, dispose of the plug immediately in a safe manner.
-
Page 4: Packing List
SECTION 0 Packing List The unit is supplied in a dedicated packing carton provided by the manufacturer and should not be accepted if delivered in inferior or unauthorised materials. Carefully unpack the carton and check for any shipping damage or shortages. Any shortages or damage should be reported to the supplier immediately. Enclosures: HD2200 High Definition Downconverter HD2200 Installation &... - Page 5 SECTION 0 Manufacturers Notice Copyright protection claimed includes all forms and matters of copyrightable material and information now allowed by statutory or judicial law or hereinafter granted, including without limitation, material generated from the software programs which are displayed on the screen such as icons, screen display looks etc. Reproduction or disassembly of embedded computer programs or algorithms is prohibited.
-
Page 6: Table Of Contents
SECTION 0 Table of Contents SECTION Introduction Description..........................1.1 Features..........................1.2 Specifications ........................2.1 Installation Unpacking the HD2200 ......................3.1 Power Connections......................3.1 Opening the Front Panel ....................3.2 Connections........................3.3 Switching On........................3.7 Operation General Operating Principles .....................4.1 General Operating Information ...................4.2 Input ............................4.4 Convert ..........................4.6 Display ..........................4.9 Reference ...........................4.12 Output ..........................4.14 Audio...........................4.16... - Page 7 SECTION 0 Manual Revision Record Date Version No. Issue No. Change Comments 271100 First Issue HD22OP271100 Version 1 Issue 1...
-
Page 8: Description
HD2200 SECTION 1 Description The HD2200 has built-in test pattern generators, The Premier HD2200 is a compact unit that can aspect ratio conversion, colour space convert any high definition input to any standard conversion, can genlock to SD and HD references definition output. -
Page 9: Features
HD2200 SECTION 1 Features •= Compact interface from HD to SD •= All current SMPTE 292M HD standards supported •= Aspect ratio conversion •= Digital colour space conversion •= Blanking for input and output •= Auto 2:2/3:2 film sequence detect •= Selectable conversion modes (auto, optimise, interpolate, synchronise) •=... -
Page 10: Technical Profile
HD2200 SECTION 2 Technical Profile Features Power Signal Inputs Serial Digital 1 x BNC HDTV 10-bit serial digital Mains Supply 115/230 V AC 50/60 Hz, input at 1.48GHz – SMPTE292 Automatic Voltage Selection 1997 and embedded audio Power Consumption Max. 250 W SMPTE 299M. -
Page 11: Installation
HD2200 SECTION 3 Installation UNPACKING THE HD2200 The unit is packed in a single carton. The contents of the carton are as follows: 1 HD2200 unit 1 Power cable 2 Spare a.c. power fuses 3.15 A (T) 1 HD2200 Installation and Operating Manual 1 Generic Power Supply Installation Manual Unpack the carton carefully and check for any shortages or shipping damage. -
Page 12: Opening The Front Panel
HD2200 SECTION 3 Environment Although ruggedly constructed to meet the normal environmental requirements, it is important that there is a free flow of air at the front, left-hand side (looking from the front) and rear to dissipate the heat produced during operation. Installations should be designed to allow for this. -
Page 13: Connections
HD2200 SECTION 3 CONNECTIONS All the connectors are mounted on the rear panel of the unit and are appropriately annotated. HDSDI Input Loop-through HD serial digital input (IN and LOOP). Genlock Reference External HD trisync or SD bi-sync analog reference signals may be connected to either (REF A or REF B) of these two loop-through BNC connectors. - Page 14 HD2200 SECTION 3 Composite Output composite output option downconverter has not yet been implemented. RollCall The unit can be controlled via RollCall using this BNC connector. Control can be also provided from an external source via an RS-422 9-way D-type connector.
- Page 15 HD2200 SECTION 3 The General Purpose Interfaces (GPI’s) are Note. For interlaced output standards the polling occurs at field rate and for progressive output accessed via a 25 way D type female connector. In the table GPI refers to inputs and GPO refers to standards it occurs at frame rate.
- Page 16 HD2200 SECTION 3 LED INDICATIONS HDSDI TX Lock = Red LED = Green LED = Yellow LED HDSDI RX CRC Errors HDSDI Loss HDSDI RX Lock RollCall Address Top 4 Bits Bottom 4 Bits Comms FPGA Programmed Boot Failure Analogue Reference A Heartbeat Slave Cpu Message TX Genlock...
-
Page 17: Switching On
HD2200 SECTION 3 SWITCHING ON Open the front panel. Check that power is connected to the HD2200. Set the power switch on the front of the power unit(s) to ON (I). The opening alphanumeric display will appear on the front panel. Close the front panel. Initialising HD22OP271100 Version 1 Issue 1... -
Page 18: Operation
HD2200 SECTION 4 Operation GENERAL OPERATING PRINCIPLES The HD2200 may be operated as follows: All operational parameters and selections may be made by pressing dedicated push buttons and 1. By using the front panel controls selecting items from a system of menus displayed in the window. -
Page 19: General Operating Information
HD2200 SECTION 4 Display Window GENERAL OPERATING INFORMATION Display Window The control window displays all selection menus sub-menus and unit status information. Home Display An example of unit status is shown in this case indicating that the unit is set to accept a 750 progressive signal (720 active lines) at 59.94Hz 750(720)/59p frame rate and the output signal is selected to be... - Page 20 HD2200 SECTION 4 Display Buttons Pressing the button adjacent to the required item makes a selection; the text will become highlighted (reversed text) when active. Spinwheel The spinwheel allows selections to be made from the menu. In the example above, rotating the spinwheel clockwise will select the next input standard (the scroll bar shows that there are more standards to select –...
-
Page 21: Input
HD2200 SECTION 4 INPUT The options on loss of signal are: The following menu items are all related to the input signal selection and control. Input The incoming signal will be displayed whenever possible. Black The output will cut to black When the required option is highlighted, press the lower right-hand button adjacent to Select to... - Page 22 HD2200 SECTION 4 MATRIX Allows the colorimetry on the input signal to be set. The colour correction options are: Auto Automatically selects the colorimetry most appropriate for the output video standard. REC 601 Colorimetry to REC 601 requirements is applied. SMPTE 240 Colorimetry to SMPTE 240 requirements is applied.
-
Page 23: Convert
HD2200 SECTION 4 Auto Selects Synchronise mode when CONVERT the input and output field rates are The following menus relate to the conversion from the same and optimise mode when the input signal to the output signal. they are different. MODE Optimise The unit operates as... - Page 24 HD2200 SECTION 4 FILM CONTROL Note, the window is applied to the HD2200 input When selected the menu shown below is video so it is advisable to have all of the input displayed. video visible when making the adjustment. For example, by selecting a full height display (see DISPLAY-PRESETS menu).
- Page 25 HD2200 SECTION 4 EXTERNAL Controls the interpretation of external film mode flag. The options are: The flag indicates that the current field is new. Repeat The flag indicates the current field is a repeat FILM APERTURE The film option is used to select the filters when in film processing modes.
-
Page 26: Display
HD2200 SECTION 4 DISPLAY This menu is used to control the size, shape and position of the output picture. Anamorphic PRESETS This allows selection of the preset display sizes. The options are: Anamorphic This setting retains all picture information from the input and passes it to fill the output image regardless of the aspect ratio conversion. - Page 27 HD2200 SECTION 4 that if trigger mode is selected then adjusting the picture size, shape or Allows the picture size, shape and position to be position from the front or remote adjusted to meet custom requirements. control panel will have no effect unless trigger command...
- Page 28 HD2200 SECTION 4 UPDATE Sets the rate at which the transition is updated. The update rate options are: F1 and F2 If the output is of interlaced or segmented frame type the picture parameters are updated every field. If the output is progressive the picture parameters are updated at frame rate.
-
Page 29: Reference
HD2200 SECTION 4 REFERENCE The user can force the reference standard to the This menu is used to control the genlocking required value or select Auto. The full range of functions of the HD2200. references is as follows: Auto The HD2200 measures the selected reference signal and automatically chooses the reference... - Page 30 HD2200 SECTION 4 To select each of the parameters, press the lower left hand button adjacent to >>>. The options are: Horizontal Timing Adjusts horizontal genlock timing. Range is zero to one output line in steps of one output pixel. Vertical Timing Adjusts vertical...
-
Page 31: Output
HD2200 SECTION 4 HORIZONTAL DE-RING OUTPUT The following menu items are all related to the output signal standard and control. Controls the de-ringing filters for both luminance and chrominance. Options are: STANDARD None This allows selection of the output video standard. The standards are named using the following Minimum de-ring convention: total number of lines, (active lines),... - Page 32 HD2200 SECTION 4 The gain controls have a range of ±6dB with a Left Adjusts the left-hand edge of output preset value of 0dB. The options are: blanking. A setting of 1 indicates that no output pixels that are normally visible Master All 3 channels adjusted simultaneously should be blanked, 2 causes the first...
-
Page 33: Audio
HD2200 SECTION 4 AUDIO (Optional) AES/EMBEDDED This menu is used to control all the HD2200 This determines the source of the output. functions related to the audio processing blocks. Note that if this option is not fitted the display will show the words “Feature not fitted”... - Page 34 HD2200 SECTION 4 DELAY MODE MANUAL DELAY Used to control the delay applied to the audio as it This allows the user to apply a manual offset to the passes through the machine. The audio delay audio delay setting. This offset can be positive or applied comprises two components;...
-
Page 35: Memory
HD2200 SECTION 4 MEMORY This menu is used to store and recall the various system Memories. There eight system memories available. Each memory contains a complete record of the machine settings (including the display memory settings). STORE Stores the system settings in the memory selected. -
Page 36: Utils
HD2200 SECTION 4 UTILS FREEZE Controls the various utility functions the HD2200 Used to control the HD2200 picture freeze provides. The menu functions are shown below: function. Pressing the top right-hand button manually toggles between freeze and no freeze. PATTERN Used to control the internal test pattern generator. -
Page 37: Setup
HD2200 SECTION 4 SETUP (Config) LOG NAME Provides additional machine setup items. f the HD2200 is attached to a RollCall=network with a logging device, information about various parameters can be made available to the logging device. ROLLCALL Allows the unit name and logging information to be set. - Page 38 HD2200 SECTION 4 Select the parameter to be changed using the front The indications are: panel knob. Pressing the bottom right-hand button PSU1 adjacent to ‘Select ’ toggles the status of the PSU2 selected parameter. Enabled parameters will be marked. HIO board VTI board VERSION...
-
Page 39: Menu Structure
HD2200 SECTION 4 MENU STRUCTURE Input Reference SOURCE Enable Auto Standard Active Ext Ref Ref A Loss Matrix Timing Ref B etc. ON LOSS... HORIZONTAL TIMING Input 0 px Black VERTICAL TIMING 0 ln INPUT STD EXT REFERENCE STD Auto Auto 1125(1035)/30i 1125(1035)/30i... - Page 40 HD2200 SECTION 4 Memory Output SYSTEM MEMORY Standard Store Memory 1 Recall Active Control Memory 2 Matrix Factory Memory 3 etc. This will reset user- defined settings! Please Vert Enh confirm operation. Horz Enh Proc Amp Horz DeR LUMA CHROMA Utils None None...
- Page 41 HD2200 SECTION 4 Audio I/P Grp. Del Mode O/P Grp. Man Del AES/Emb. O/P 1 SOURCE O/P 1 O/P 2 AES I/P 1 O/P 3 O/P 4 AES I/P 2 AES I/P 3 etc. CH A/B CH A/B CH C/D Group 1 Group 2 Group 3...
- Page 42 HD2200 SECTION 4 OPERATING THE HD2200 FROM AN ACTIVE CONTROL PANEL ROLLCALL REMOTE CONTROL SYSTEM The Menu Structure (See Menu Structure diagrams on previous pages) All operational parameters and selections are made using a system of menus displayed in two LCD windows.
