(151) AP619A BUILT-IN ELECTRIC PUMP ENGLISH 4.875" X 7.25" 07/28/2015
FIG (3)
6. Lie down on the airbed to test the firmness.
7. If the sleeping surface is too hard, adjust the firmness
by turning the control dial counterclockwise gradually
until air starts to exit through the air passage. See
Fig (6). Turn the control dial fully clockwise when the
desired firmness is achieved. See Fig (7). If the airbed
becomes too soft repeat step #3 thru #7 as necessary.
8. Disconnect the AC line cord from the wall socket,
place it inside the cord compartment and close the
cover. Make sure the power cords are free of twist,
kink and knot.
IMPORTANT NOTE
Proper inflation of the airbed.
The ambient temperatures of air have an effect on the airbed internal pressure. At low
ambient temperature the air will contract within the airbed and the airbed will feel softer:
add air as necessary. At high ambient temperature the air within the airbed will expand
significantly and the airbed will become hard and may burst: release air to avoid damage
to the airbed or to soften the feel. Do not expose the airbed to extreme temperatures (hot
or cold).
Stretching is a natural characteristic of new vinyl. During initial use, the airbed may become
soft and require additional inflation to maintain desired firmness. This is normal for the first
few days of use.
Dimensions shown are approximate and will vary due to the vinyl temperature and the air
temperature.
In no event shall Intex, their authorized agents or employees be liable for damages
(such as pin holes) to the airbed caused by negligence, ordinary wear and tear,
abuse and carelessness, or external forces.
DEFLATION
1. Open line cord compartment cover. See Fig (1).
2. Plug in the AC line cord into an AC electrical outlet. See Fig (2).
3. Turn the control dial counterclockwise until arrow points to deflation mark (
Fig (8).
FIG (8)
FIG (9)
READ AND SAVE THESE INSTRUCTIONS
Page 3
151
151
FIG (4)
FIG (5)
FIG (6)
FIG (7)
). See
FIG (10)
(151) AP619A BUILT-IN ELECTRIC PUMP ENGLISH 4.875" X 7.25" 07/28/2015
4. Press "I" to switch ON. See Fig (4).
5. When the airbed is completely deflated, begin rolling the airbed from the foot of
the airbed towards the head of the airbed where the pump is located. See Fig (9).
6. When all air is removed from the airbed, press "O" to switch OFF. See Fig (5).
7. Turn the control dial fully clockwise. See Fig (10).
8. Disconnect the AC line cord from the wall socket, place it inside the cord compart
ment and close the cover. Make sure the power cords are free of twist, kink and
knot.
INFLATION OPTION
1. If electrical power is not available then a conventional foot
or manually operated air pump can be connected to the
control dial valve for inflation. See Fig (11).
2. Turn the control dial clockwise until arrow points to the
inflation mark (
).
3. Insert air pump nozzle to the control dial valve to inflate the
airbed.
IMPORTANT
Inflate only with a low pressure inflator. Do not over inflate. Fill with cold air only.
STORAGE INSTRUCTIONS
1. Deflate the airbed following the "DEFLATION" instructions.
2. Turn the control dial counterclockwise until arrow points to deflation mark (
Fig (8).
3. Make sure the airbed is clean and dry.
4. Lay bed flat with sleeping surface facing upwards and follow the folding steps on Figs
(12 - 16). Fold the airbed loosely and avoid sharp bends, corners and creases which can
damage the airbed.
FIG (12)
INTEX
INTEX
FIG (15)
5. Turn the control dial fully clockwise. See Fig (10).
6. Place the airbed inside the storage bag and store in a dry, cool storage location.
INTEX
INTEX
INTEX
©2015 Intex Marketing Ltd. - Intex Development Co. Ltd. - Intex Trading Ltd.- Intex Recreation Corp.
All rights reserved/Tous droits réservés/Todos los derechos reservados/Alle Rechte vorbehalten. Printed in China/Imprimé en Chine/Impreso
en China/Gedruckt in China.
®™ Trademarks used in some countries of the world under license from/®™ Marques utilisées dans certains pays sous licence de/Marcas registradas
utilizadas en algunos países del mundo bajo licencia de/Warenzeichen verwendet in einigen Ländern der Welt in Lizenz von/Intex Marketing Ltd. to/à/
a/an Intex Trading Ltd., Intex Development Co. Ltd., G.P.O Box 28829, Hong Kong & Intex Recreation Corp., P.O. Box 1440, Long Beach, CA
90801 • Distributed in the European Union by/Distribué dans l'Union Européenne par/Distribuido en la unión Europea por/Vertrieb in der Europäischen
Union durch/Intex Trading B.V., Venneveld 9, 4705 RR Roosendaal – The Netherlands
www.intexcorp.com
READ AND SAVE THESE INSTRUCTIONS
Page 4
151
151
FIG (11)
). See
FIG (14)
FIG (13)
INTEX
INTEX
FIG (16)
INTEX
INTEX
INTEX
Consumer Service 1-800-234-6839\
