Summary of Contents for Southern MS555200TX
- Page 1 MS555200TX Porter Gaming/Media Console For assistance with assembly, contact: Espresso Finish Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com Assembly Instructions www.seidal.com PO#:...
- Page 2 Porter Gaming/Media Console Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
- Page 3 Quantity Quantity Quantity of 1 of 1 of 1 Left Side panel Right Side panel Support Leg Quantity Quantity Quantity of 1 of 1 of 1 Top Panel Left Door Right Door Quantity Quantity Quantity of 2 of 1 of 1 Side Back Panel Upper Middle Back Panel Lower Middle Back Panel...
- Page 4 Quantity Quantity Quantity of 2 of 2 Of 41 ∮5/32’’x3/4’’L ∮1/8’’x1/2’’L Bolt Magnet Screw Quantity Quantity Quantity of 4 of 8 of 8 ∮5/32’’x1/2’’L Handle Bolt Shelf Pin Quantity Quantity Quantity of 20 of 4 of 4 ∮5/32”x 1”L ∮1/8”x5/8”L Screw Bracket Screw...
- Page 5 Porter Gaming/Media Console Assembly Instructions ( 1 ) ( 2 ) Insert cam locks (2) into holes on middle fixed shelves (M). Screw cam bolts (1) into holes on left Please do not over tighten cam bolts. middle panel (K) and right middle Please stop when you feel tight"...
- Page 6 Attach magnets (9) to predrilled holes on fixed shelves (N) and (O) with screws (10), then fasten them. Insert cam locks (2) into left fixed shelf (N) and right fixed shelf (O). Screw cam bolts (1) into holes on assembled. Attach left fixed shelf (N) and right fixed shelf (O) to assembled unit by inserting cam bolts (1) into...
- Page 7 Insert wood dowels (3) into holes on assembled unit as shown. Attach top panel (S) to assembled unit with bolts (6). Tighten by rotating bolts (6) clockwise with Allen wrench (20). Insert the shelf pins (13) into desired holes of inner side panels (P) and (Q) and middle panels (K) and (L).
- Page 8 Attach left door (T) to left side panel (P) and right door (U) to right side panel (Q). Attach metal knob (7) to doors (T) and (U) with bolts (8). Figure 7 Attach drawer side panels (B) and (C) to drawer back panel (E) using screws (14).
- Page 9 Attach lower drawer back panel (G) to lower drawer bottom (F) by inserting small wood dowels (5) into corresponding holes until the panels meet. Then use screws (14) to connect them together. Tighten screws (14) with Phillips screwdriver. Attach lower drawer side panels (H) and (I) to assembled unit by inserting small wood dowels (5) into corresponding holes until all the panels meet.
- Page 10 Insert drawers into assembled unit as shown. Make sure all slides glide smoothly in and out. Note: There is a lever located on the male slide for bottom drawer slide. Push the lever to the either side in order to detach the male slide from the female slide.
- Page 11 Move this item close to the wall brackets (15) and tie in all brackets (15) together with plastic strap (19) as shown in diagram. Anti-tipping hardware must be used for this product to avoid tipping and injury. Figure 13 Now your multicolor apothecary console/TV stand is ready to use.
- Page 12 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
- Page 13 This unit contains a permanent warning sticker located on underside of top shelf or inside drawer. Do not allow children under 16 years to move the cart. Model: MS555200TX MULTICOLOR APOTHECARY CONSOLE/TV STAND Southern Enterprises, Inc...
