NUVITA BOTTLEWARMER 1160
EN
INTRODUCTION
Congratulations on your purchase of this bottle warmer that can be used
everywhere because it operates with HOME power and CAR power. The large
size makes it possible to heat bottles up to 8 cm wide and it is possible to
heat with water (home) or dry (car).
Operation is simple: just turn the knob to position 3 and the bottle warmer
starts and it will take around 6-7 minutes to heat the drink. To maintain
the temperature turn the knob to position 2. Before you start using this
appliance, please read the instruction manual and retain it for future
reference.
DESCRIPTION
2
1
3
4
1.
CAR LED light (12 VDC)
2.
Heating element.
3.
HOME LED light (230 VAC)
4.
Control knob
5.
HOME and CAR selector
6.
CAR power cable connector
7.
HOME power cable connector
8.
Lid
9.
Container for jelly
10.
Car power cable
11.
Home power cable
MANOPOLA DI CONTROLLO
1. Heating element is OFF
2. Temperature
maintenance
1.
During the preparation of the drink, or when not using the appliance, ensure that the
control knob is in position 1.
2.
If after heating, the drink is not consumed immediately, turn the control knob in the
position 2, in this way is maintained the temperature.
3.
To proceed to the rapid heating of the drink, turn the knob to position 3.
The following are indicative of the times of heating.
Heating time requested up to ~40°C
Drink
Environment (~20 °C)
160ml bottle
6':20"
250ml bottle
12':00
The values shown in the table are purely indicative and should be considered only as
an example because many factors can increase or decrease the heating time.
HOW TO USE
To use the appliance please follow here below instruction:
Home:
When using the bottle warmer at home always and only use it with water.
Do not use in "dry" condition (without water) as you risk damaging the
bottle.
NOTE
1.
Please check if the power selector in the back side of the appliance
is in HOME position.
2.
Please turn the control knob (4) to position
3.
Connect the home power cable (11) to the appliance and fit it
in a compatible power outlet
When HOME power is selected, the CAR power connector is
covered and not accessible.
NOTE
4.
Pour water in the heater (2) making sure not to cross the MAX level. Usually from 40 ml.
to 80 ml. are enough and it depends on the size of the bottle.
5.
Put the bottle in the warmer and turn the control know to position
. The HOME LED will light and the heating phase is started.
5
7
6
8
6.
After 5 - 7 minutes, check the temperature of the drink by pouring some drops on the
back of his hand and then give the bottle to the baby.
9
7.
When you finish to use the appliance, please turn the control knob
to position
10
11
During the heating phase the HOME LED will lights on and off several times.
Wait 5 - 7 minutes and check the temperature of the drink by pouring a few
NOTE
drops on the back of the hand.
Car:
1.
Please check if the power selector in the back side of the appliance
is in CAR position.
2.
Please turn the control knob (4) to position
3. Warm operation
3.
Connect the CAR power cable (10) to the appliance and fit it
in the CAR lighter outlet.
4.
Put the bottle in the warmer, without water and turn the control knob to
position .
Refrigerator (~ 6°C)
7':30"
5.
After 10 - 15 minutes, check the temperature of the drink by pouring some drops on
the back of his hand and then give the bottle to the baby.
15':00"
6.
When you finish to use the appliance, please turn the control knob to
position
and disconnect the power cable from the main power.
.
and disconnect the power cable from the main power.
During the heating phase the CAR LED will lights on and off several times.
Wait 10 - 15 minutes and check the temperature of the drink by pouring a
few drops on the back of the hand.
NOTE
CLEANING AND MAINTENANCE
To ensure proper operation it is recommended to clean periodically the
appliance. Here below there are some guidelines on how to clean the bottle
warmer:
1.
Unplug from main power and allow the device has cooled.
2.
Pour any remaining water, if any, and clean the heating element with a soft
and clean cloth.
3.
Clean the external side with a soft, clean cloth dampened with water.
To reduce sediment deposits will recommend using filtered water or
previously boiled. For efficient operation it is recommended to remove any
sediment of limestone every 4 weeks using white wine vinegar.
Descale the warmer using a mix of 50ml household vinegar and 100ml cold
water, pouring the solution into the warmer. Leave the solution to work until
the lime scale has been removed; do not operate the warmer during this time.
Empty the warmer, rinse it out thoroughly and finally dry it with a cloth.
NOTE
Descale the warmer approximately every four weeks.
WARNINGS
If you use small electric appliances or electronic devices, especially if children
are present, it is important to follow carefully the safety precautions listed
below:
1.
Do not leave the appliance unattended during operation and / or in the
presence of children.
2.
Use the appliance on a flat surface and secured to prevent tipping or the
leakage of water boiling inside.
3.
After use, disconnect the appliance from the main power and let it cool.
4.
Do not use the appliance in water or in places with high humidity
(Example: bathing or swimming).
5.
Do not place the product near a bathtub or wells.
6.
Do not place the device near and / or soak in water and / or other similar
liquids.
7.
If dropped in water or similar liquids, not groped to recover the device
without first unplugging the power cord from the main power outlet.
8.
Before each use, carefully check that the device, the power cord and
power outlet does not have suffered damage.
9.
Do not activate the appliance if:
- The power cord or plug is damaged or tampered.
- The appliance is dropped or visibly damaged.
- The appliance was immersed in water or similar liquids.
10.
This device is intended for internal use. Do not use outdoors or in the
presence of substances, sprays, aerosols or medical devices for the
administration of oxygen.
11.
This device is not suitable for use in environments where there are
mixtures of flammable anesthetics, oxygen or nitrous oxide.
12.
Do not modify the power cord or plug. Use appropriate adapters and / or
converters comply with standards.
13.
Make sure the device is not exposed to direct sunlight or excessive heat.
14.
Inside the machine there are no spare parts, consumables and / or
replaceable parts independently, so they groped any repairs.
15.
Make sure that the power cord is not a hindrance and danger to persons
and to ensure in particular that does not touch or appears to be in close
proximity to surfaces at high temperature, such as the kitchen stove or
radiators for heating of the house.
16.
This appliance is not intended to be used by people, including children
with physical disabilities, sensory and mental disabilities, or lack of
experience or knowledge unless they are properly educated and trained
to use the device by a competent person and responsible for their safety.
