Samsung SGH-S105 Service Manual

Samsung SGH-S105 Service Manual

Gprs gsm telephone
Hide thumbs Also See for SGH-S105:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
SERVICE
GPRS GSM TELEPHONE
GPRS GSM TELEPHONE
SGH-S105
Manual
1.
2.
Exploded Views and Parts List
3.
Electrical Parts List
4.
5.
6.
CONTENTS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SGH-S105 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung SGH-S105

Summary of Contents for Samsung SGH-S105

  • Page 1 GPRS GSM TELEPHONE SGH-S105 Manual SERVICE GPRS GSM TELEPHONE CONTENTS Specification Exploded Views and Parts List Electrical Parts List Block Diagrams PCB Diagrams Flow Chart of Troubleshooting and Circuit Diagrams...

  • Page 2: Specification

    - 1 0 0 d B m - 1 0 0 d B m TD M A M u x C el l 최 대 반경 3 5 K m 3 5 Km 2 K m SAMSUNG Proprietary-Contents may change without notice...

  • Page 3: Gsm Tx Power Class

    6 ± 4 dBm 4 ± 4 dBm 4 ± 4 dBm 7 ± 3 dBm 5 ± 3 dBm 2 ± 5 dBm 2 ± 5 dBm 0 ± 5 dBm 0 ± 5 dBm SAMSUNG Proprietary-Contents may change without notice...

  • Page 4: Cellular Phone Exploded View

    2. SGH-S105 Exploded View and its Parts List 2-1. Cellular phone Exploded View SAMSUNG Proprietary-Contents may change without notice...
  • Page 5 SGH-S105 Exploded view and its Part list 2. Cellular phone Parts list Location Description SEC CODE Remark DUAL WINDOW LCD GH72-04715A FOLDER UPPER GH75-02275A GH07-00179A MOTOR 3101-001295 SPEAKER 3001-001297 FOLDER LOWER GH75-02079A SCREW 6001-001478 SCREW CAP GH74-02036A WINDOW LCD GH72-04716A...
  • Page 6 SGH-S105 Exploded view and its Part list 3. Test Jig (GH80-00865A) 3-1. RF Test Cable 3-2. Test Cable 3-3. Serial Cable (GH39-00093A) (GH39-00165A) 3-4. Power Supply Cable 3-5. DATA CABLE (GH39-00152A) SAMSUNG Proprietary-Contents may change without notice...
  • Page 7 3. SGH-S105 MAIN Electrical Parts List Level SEC Code Design LOC Descriptions PBA MAIN-SGHS100;SGH-S100,XEF,FRAN, GH92-01302A - -,-,-,-,-,- RMO-CONTACT RUBBER;SGH-A300,SI GH73-00801A - RUBBER,3X4XT0.8,BLK MPR-PCB EMI SPONGE;SGH-S100,SHIELD GH74-03124A - SPONGE,7X3XT2,- PCB-SGHS100;SGH-S100,FR-4,6L,-,1.00 GH41-00303A - T,100X158,-,3,- NPR-ANT GH71-00434A ANT1 CONTACT;SCH-X210,ST,T0.2,-,- C-CERAMIC,CHIP;0.047nF,5%,50V,NP0,TP, 2203-000995 C1000,C1004,C1006 1005 C-CERAMIC,CHIP;100nF,10%,10V,X5R,TP,...
  • Page 8 C-CERAMIC,CHIP;100nF,+80-20%,16V,Y5V, 2203-005061 C408,C412,C417,C512 TP,1005 2404-001151 C409 C-TA,CHIP;33UF,20%,6.3V,LZ,TP,3216 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,10 2203-000438 C413,C415,C801,C802 05,- C-CERAMIC,CHIP;0.082nF,5%,50V,NP0,TP, 2203-001239 C427 1005 2007-007771 C428,R104,R105,R106 R-CHIP;0OHM,5%,1/16W,DA,TP,1005 C-CERAMIC,CHIP;100nF,+80-20%,16V,Y5V, 2203-005061 C513,C516,C517,C518 TP,1005 C-CERAMIC,CHIP;100nF,+80-20%,16V,Y5V, 2203-005061 C519,C612,C711 TP,1005 C-CERAMIC,CHIP;220nF,+80-20%,10V,Y5V, 2203-005496 C601,C602,C709 TP,1005 C-CERAMIC,CHIP;10nF,10%,16V,X7R,TP,1 2203-000254 C603,C604,C605,C606 005,- SAMSUNG Proprietary-Contents may change without notice...
  • Page 9 2203-000233 C920,C924,C925 C-CERAMIC,CHIP;0.047nF,5%,50V,NP0,TP, 2203-000995 C922 1005 CONNECTOR-CARD 3709-001187 CN100 EDGE;6P,2.54MM,SMD-A,- CONNECTOR-COAXIAL;-,-,50MOHM,50OH 3705-001248 CN1001 M,0.3DB CONNECTOR-HEADER;BOX,30P,2R,0.5MM, 3711-004289 CN200 SMD-S,AUF CONNECTOR-HEADER;BOX,20P,2R,0.5mm, 3711-004623 CN201 SMD-S,AUF CONNECTOR-SOCKET;24P,1R,0.5MM,SMD 3710-001545 CN302 -A,AUF 3722-001842 CN401 JACK-PHONE;4P,2.3PI,AU,BLK,- 1405-001082 D202,D203,D204,ZD300 VARISTOR;5.6V,20A,1x0.5x0.6mm,TP 0406-001152 D301 DIODE-TVS;SD05,6/-/-/,350W,SOD-323 SAMSUNG Proprietary-Contents may change without notice...
  • Page 10 2801-004116 OSC601 BK,12.5FF,65KOH OSCILLATOR-VCTCXO;13MHZ,3PPM,10KO 2809-001260 OSC801 HM//10PF,TP,3V,- TR-DIGITAL;RN1104,NPN,100MW,47K/47K, 0504-000168 Q100 SSM,TP TR-POWER;ZXT13P20DE6,PNP,1100MW,S 0502-001201 Q101 OT-23-6,TP,300-90 TR-SMALL 0501-000225 Q400 SIGNAL;2SC4617,NPN,200mW,EM3,TP,120 TR-DIGITAL;RN1102,NPN,100MW,10K/10K, 0504-000167 Q700,Q701,Q702 SSM,TP 2007-001319 R100 R-CHIP;1.2Kohm,5%,1/16W,DA,TP,1005 2007-007311 R1000 R-CHIP;22Kohm,1%,1/16W,DA,TP,1005 2007-007142 R1001,R111,R611 R-CHIP;10Kohm,1%,1/16W,DA,TP,1005 2007-007309 R1002 R-CHIP;12Kohm,1%,1/16W,DA,TP,1005 SAMSUNG Proprietary-Contents may change without notice...
  • Page 11 R-CHIP;510ohm,5%,1/16W,DA,TP,1005 2007-000162 R714 R-CHIP;100Kohm,5%,1/16W,DA,TP,1005 2007-002797 R801,R802 R-CHIP;560ohm,5%,1/16W,DA,TP,1005 2007-007771 R803,R901 R-CHIP;0OHM,5%,1/16W,DA,TP,1005 1203-002568 U100 IC-VOLTAGE REGULATOR;PSC2006,MLCC, 1209-001379 U1000 IC-ETC, LINEAR;HD155173ANPEL,-,16P,- 1201-001864 U1001 IC-POWER AMP;08123,-,8P,13.75X8MM, CONNECTOR-HEADER;BOX,14P,2R,0.5mm, 3711-004621 U1002 SMD-S,AUF IC-BATTERY;1734,SOT-23,6P,150MIL,PLA 1203-002127 U101 STIC,4.7/5.3V, TR-ARRAY;UMH9N,NPN,2,150MW,SC-88,T 0506-001052 U102 P,68- SAMSUNG Proprietary-Contents may change without notice...
  • Page 12 A,108P, TR-DIGITAL;BCR10PN,NPN/PNP,250mW,10 0504-001042 U701,U702,U703 K/10K, IC-CMOS LOGIC;7S04,INVERTER,SOT-353, 0801-002345 U801 5P,49MIL,SINGL IC-INTERFACE;SI4201-BM,MLP,20P,4X4M 1205-002185 U900 M,-,3V,-,-20TO+ IC-TRANSCEIVER;SI4200-BM,MLP,32P,5X5 1205-002184 U901 MM,-,3V,-,-20T IC-PLL/SYNTHESISER;SI4133T-BM,MLP,28 1209-001434 U902 P,5X5MM,-,3V,- 1405-001082 ZD302,ZD303,ZD309 VARISTOR;5.6V,20A,1x0.5x0.6mm,TP 0406-001084 ZD305,ZD311 DIODE-TVS;SMF05,6/-/-V,200W,- 1405-001082 ZD310,ZD401,ZD402 VARISTOR;5.6V,20A,1x0.5x0.6mm,TP 1405-001082 ZD404,ZD405 VARISTOR;5.6V,20A,1x0.5x0.6mm,TP SAMSUNG Proprietary-Contents may change without notice...
  • Page 13 SGH-S105 Electrical Parts List SAMSUNG Proprietary-Contents may change without notice...

  • Page 14: Block Diagrams

    4. SGH-S105 Block Diagrams 1. RF Solution Block Diagram SAMSUNG Proprietary-Contents may change without notice...
  • Page 15 SGH-S105 Block Diagrams 2. Base Band Solution Block Diagram SAMSUNG Proprietary-Contents may change without notice...

  • Page 16: Pcb Diagrams

    5. SGH-S105 PCB Diagrams 1. Main PCB Top Diagram SAMSUNG Proprietary-Contents may change without notice...
  • Page 17 SGH-S105 PCB Diagrams 2. Main PCB Bottom Diagram SAMSUNG Proprietary-Contents may change without notice...

  • Page 18: Flow Chart Of Troubleshooting And Circuit Diagrams

    6.SGH-S105 Flow Chart of Troubleshooting and Circuit Diagrams 1. Power ON SAMSUNG Proprietary-Contents may change without notice...

  • Page 19: Sim Part

    SGH-S105 Flow Chart of Troubleshooting and Circuit Diagrams 2. Initial 3. Sim Part SAMSUNG Proprietary-Contents may change without notice...

  • Page 20: Charging Part

    SGH-S105 Flow Chart of Troubleshooting and Circuit Diagrams 4. Charging Part 5. Microphone Part SAMSUNG Proprietary-Contents may change without notice...

  • Page 21: Speaker Part

    SGH-S105 Flow Chart of Troubleshooting and Circuit Diagrams 6. Speaker Part SAMSUNG Proprietary-Contents may change without notice...

  • Page 22: Pcs Transmitter

    SGH-S105 Flow Chart of Troubleshooting and Circuit Diagrams 7. PCS Transmitter SAMSUNG Proprietary-Contents may change without notice...

  • Page 23: Pcs Receiver

    SGH-S105 Flow Chart of Troubleshooting and Circuit Diagrams 8. PCS Receiver SAMSUNG Proprietary-Contents may change without notice...

  • Page 24: Back Light

    SGH-S105 Flow Chart of Troubleshooting and Circuit Diagrams 9. Back Light 10. Alert Tone SAMSUNG Proprietary-Contents may change without notice...

  • Page 25: Gsm Receiver

    SGH-S105 Flow Chart of Troubleshooting and Circuit Diagrams 11. GSM Receiver SAMSUNG Proprietary-Contents may change without notice...

  • Page 26: Gsm Transmitter

    SGH-S105 Flow Chart of Troubleshooting and Circuit Diagrams 12. GSM Transmitter SAMSUNG Proprietary-Contents may change without notice...

  • Page 27: Dcs Receiver

    SGH-S105 Flow Chart of Troubleshooting and Circuit Diagrams 13. DCS Receiver SAMSUNG Proprietary-Contents may change without notice 6-10...

  • Page 28: Dcs Transmitter

    SGH-S105 Flow Chart of Troubleshooting and Circuit Diagrams 14. DCS Transmitter SAMSUNG Proprietary-Contents may change without notice 6-11...
  • Page 29 SGH-S105 Flow Chart of Troubleshooting and Circuit Diagrams MEMO SAMSUNG Proprietary-Contents may change without notice 6-12...
  • Page 30 SGH-S105 Flow Chart of Troubleshooting and Circuit Diagrams 15. Power Circuit Diagram SAMSUNG Proprietary-Contents may change without notice 6-13...
  • Page 31 SGH-S105 Flow Chart of Troubleshooting and Circuit Diagrams 16. LCD & KEYPAD & EMI FILTER & JTAG & IRDA Connector Circuit Diagram SAMSUNG Proprietary-Contents may change without notice 6-14...
  • Page 32 SGH-S105 Flow Chart of Troubleshooting and Circuit Diagrams 17. I/F Connector Circuit Diagram SAMSUNG Proprietary-Contents may change without notice 6-15...
  • Page 33 SGH-S105 Flow Chart of Troubleshooting and Circuit Diagrams 18. Audio Circuit Diagram SAMSUNG Proprietary-Contents may change without notice 6-16...
  • Page 34 SGH-S105 Flow Chart of Troubleshooting and Circuit Diagrams 19. Memory & Buzzer Circuit Diagram SAMSUNG Proprietary-Contents may change without notice 6-17...
  • Page 35 SGH-S105 Flow Chart of Troubleshooting and Circuit Diagrams 20. Trident Circuit Diagram SAMSUNG Proprietary-Contents may change without notice 6-18...
  • Page 36 SGH-S105 Flow Chart of Troubleshooting and Circuit Diagrams 21. CSP1089 Circuit Diagram SAMSUNG Proprietary-Contents may change without notice 6-19...
  • Page 37 SGH-S105 Flow Chart of Troubleshooting and Circuit Diagrams 22. X-TAL(13 MHz) & SIM Circuit Diagram SAMSUNG Proprietary-Contents may change without notice 6-20...
  • Page 38 SGH-S105 Flow Chart of Troubleshooting and Circuit Diagrams 23. Bright3 Circuit Diagram SAMSUNG Proprietary-Contents may change without notice 6-21...
  • Page 39 SGH-S105 Flow Chart of Troubleshooting and Circuit Diagrams 24. Transmitter & Receiver Circuit Diagram SAMSUNG Proprietary-Contents may change without notice 6-22...
  • Page 40 ELECTRONICS ⓒ Samsung Electronics Co.,Ltd. October. 2002 Printed in Korea. Code No.: GH68-03259A BASIC.
