Page 1: Table Of Contents
Newfoundland and Labrador Front Panel Features and Definitions Canada A1W 5A1 Back Panel Features and Definitions CD Transport Mechanism Operation Tel: 709 834 8244 Fax: 709 834 8246 Integris CDP R-676 Remote Control info@aurumacoustics.com Menu – Optional User-Settings Specifications www.aurumacoustics.com Warranty...
Page 2: Integris Cdp
Ideally the Integris CDP should be placed on a top shelf or where a 2. Reach around the sides of the unit and lift straight generous clearance exists.
Page 3: Front Panel Features And Definitions
FRONT PANEL FEATURES AND DEFINITIONS 1 STANDBY SELECTOR 11 CD TIME 2 STANDBY LED 12 MENU 3 VACUUM FLUORESCENT DISPLAY 13 VOLUME UP 4 DISPLAY DIMMER 14 VOLUME DOWN 5 CD PLAY 15 BALANCE LEFT 6 CD STOP 16 BALANCE RIGHT 7 CD PAUSE 17 INPUT SCROLL FORWARD 8 CD SCAN/SKIP REVERSE...
Page 4 The STANDBY button changes the Standby mode from Standby to Operate. DISPLAY Settings 100 % In Standby, the Integris CDP is in a partial sleep mode as 75 % an alternative to turning its power fully off via the rear 50 % panel mains switch.
Page 5 8. CD Scan/Skip Reverse (REV) TIME Settings 9. CD Scan/Skip Forward (FF) Elapsed track time Remaining track time These buttons enable two functions during CD playback: Elapsed total CD time • Track Skip – Apply a momentary contact of Remaining total CD time approximately ¼...
Page 6 17. Input Scroll Forward (INPUT +) 18. Input Scroll Reverse (INPUT -) Single presses of the VOL buttons will result in changes The Integris CDP has a total of 11 source Input options relative to the Volume setting range: including the integral CD transport:...
Page 7: Back Panel Features And Definitions
Back Panel Features and Definitions MAINS POWER INLET DIGITAL INPUT S/PDIF 2 POWER SWITCH DIGITAL INPUT BNC MAINS POWER FUSE -1/4 A DIGITAL INPUT AES /EBU VOLTAGE SELECTOR DIGITAL INPUT TOSLINK UNBALANCED INPUT 1 DIGITAL OUTPUT S/PDIF UNBALANCED INPUT 2 DIGITAL OUTPUT TOSLINK UNBALANCED INPUT 3 BALANCED OUTPUT...
Page 8 Do not connect power until you are certain of the correct voltage setting. 1-4 Mains Power Panel The Integris CDP is designed for use with all major AC 5-9. Analog Preamp Inputs power systems. The unit has built-in RFI filtering for The analog preamplifier section of the Integris CDP has superior performance.
Page 9 applied. The internal CD transport is available from these Non-PCM signals are not accommodated: these outputs at the standard sampling rate of 16 bit/44.1kHz. include DSD and other one-bit formats as well as compressed formats such as MP-3 and Dolby 15.
Page 10 Cardas Audio, provide a very high level of performance in most situations. 19-20. Upgrade Potential Aurum Acoustics has designed the Integris CDP to be modular, expandable, and upgradeable. The internal digital and analog systems are designed for possible upgrades and enhancements.
Page 11: Cd Transport Mechanism Operation
The internal CD transport is designed to deliver the finest performance possible from the CD format. It uses the robust and accurate top-loading Philips CDPro-2M transport and laser module on an Aurum Acoustics- designed mechanical isolation system. The transport module is secured to a massive machined aluminum transport-tray for inertial stability.
Page 12 The VFD will show the general parameters of the CD 5. Disc Removal including number of tracks and total disc time as per the First ensure the transport has stopped. This can be graphic below. This is also the default display mode for verified by confirming the default Stop mode display.
Page 13: Integris Cdp R-676 Remote Control
Integris CDP R-676 Remote Control Overview The Integris CDP R-676 remote control handset was developed in conjunction with Logitech Harmony, a leader in multi-function remote control solutions. Aurum Acoustics has programmed the remote with a command set tailored for easy control of the Integris CDP.
Page 14 Depending upon the initial power and standby status of The remote will provide a Replace Battery message after the Integris CDP, the remote and main unit could be in the operating voltage drops to a critical level. From this opposite modes. To synchronize them, if the remote is...
Page 15 Pause mode. buttons have been over-marked with X. These buttons are not assigned to any commands for the Integris CDP. They are available for use with other devices the user Track Entry Examples may load into the remote.
Page 16 Aurum Acoustics R676 Remote – Keys and Features...
Page 17: Menu - Optional User-Settings
MENU ─ Optional User Settings How to Navigate the User-Interface The Integris CDP has several programmable features that can provide extra utility and value to many users. The The MENU button is located on the front-panel within the product is fully useable without ever entering into the preamp’s volume and balance control cluster.
Page 18 Setting Input Names EDIT UNBALANCED 2 The default names of the Inputs match the rear panel markings. Users may prefer to personalize the names to >█NBALANCED 2< more closely match their input device by creating a new name up to 12 characters in length. In the following example the UNBALANCED 2 input name is changed to FLASHING CURSOR FM TUNER.
Page 19 Setting Analog Input Levels 4. Scroll ►RIGHT to the appropriate input. Notice that the Each analog input can be adjusted by +/- 12dB in name change is retained from the previous example. 0. 5dB increments. This enables closer matching of levels among Input devices so there is less volume control ANALOG LEVELS disparity among Inputs.
Page 20 Theatre Processor (HTP). A user seeking to 4. Scroll ►RIGHT to the appropriate input. maximize the fidelity of CD playback should connect the Integris CDP directly to the power VOLUME BYPASS amplifier for the L/R loudspeaker pair. The L/R analog signals from the HTP would be <...
Page 21 Saving and Resetting Preferences 2. Scroll ►RIGHT to navigate to PREFERENCES. User settings are soft-saved unless the Preference Save routine to hard-save data is used. Soft-save settings are SETUP MENU stored in a volatile memory that will be lost if mains power is turned off or fails.
Page 22 Preferences Reset: Restore Factory Settings: PREFERENCES RESET returns settings to those previously This option restores all settings to the factory defaults. It saved by the PREFERENCES SAVE operation above. Any wipes out all previous soft-save and hard-save settings. soft-save settings will be discarded and the last hard-save settings will be restored.
Page 23: Specifications
Specifications Maximum Analog Signal Levels Outputs driven from internal CD – for discs encoded to Dimensions and Weight 0dBfs and volume control set to +20dBu: Front panel width 483mm 19.0” Unbalanced 7.75 Vrms Main body width 458mm 18.0” Balanced 15.5 Vrms Depth 355mm 14.0”...
Page 24: Warranty
The product must not have been altered or improperly serviced. The serial number must not be altered or Aurum Acoustics warrants the Integris CDP to be free of removed. Do not submit the product to any unauthorized manufacturing defects in material and workmanship for service personnel.
