MicroLogix™ 1100 Replacement Battery
(Catalog Number 1763-BA)
Lithium batteries are primary (not rechargeable) cells that give extended memory support for
Rockwell Automation products.
Inside...............................................................................................page
For More Information................................................................................3
Safety Considerations...............................................................................4
Storing Lithium Batteries..........................................................................5
Transporting Lithium Batteries ................................................................5
Exporting to Foreign Countries .................................................................6
Lithium Battery Disposal ..........................................................................6
Overheated Batteries ...............................................................................8
In Case of a Lithium Fire ..........................................................................9
Hazards to Personnel ...............................................................................9
Lithium Battery Installation ....................................................................10
Installing Lithium Battery (1763-BA).......................................................11
Installation Instructions
Advertisement
Table of Contents
Related Manuals for AB Quality MicroLogix 1100
Summary of Contents for AB Quality MicroLogix 1100
-
Page 1: Table Of Contents
Installation Instructions MicroLogix™ 1100 Replacement Battery (Catalog Number 1763-BA) Lithium batteries are primary (not rechargeable) cells that give extended memory support for Rockwell Automation products. Inside…....................page For More Information................3 Safety Considerations................4 Storing Lithium Batteries................5 Transporting Lithium Batteries ..............5 Exporting to Foreign Countries ..............6 Lithium Battery Disposal ................6 Overheated Batteries ................8 In Case of a Lithium Fire ................9... - Page 2 MicroLogix™ 1100 Replacement Battery Important User Information Solid state equipment has operational characteristics differing from those of electromechanical equipment. Safety Guidelines for the Application, Installation and Maintenance of Solid State Controls (Publication SGI-1.1 available from your local Rockwell Automation sales office or online at http://www.ab.com/manuals/gi) describes some important differences between solid state equipment and hard-wired electromechanical devices.
-
Page 3: For More Information
MicroLogix™ 1100 Replacement Battery For More Information Related Publications If you need to replace the 1763-BA battery in your MicroLogix 1100 controller, refer to the ™ MicroLogix 1100 Programmable Controllers User Manual, publication 1763-UM001A-EN-P. ™ How to Get More Information If you would like a manual, you can: •... -
Page 4: Safety Considerations
MicroLogix™ 1100 Replacement Battery Safety Considerations Failure to follow the guidelines in this document may result in damaged ATTENTION equipment and/or personal injury. Use the battery for its intended application only. Do not: IMPORTANT • charge the battery • open, puncture or crush the battery •... -
Page 5: Storing Lithium Batteries
MicroLogix™ 1100 Replacement Battery Storing Lithium Batteries • Store in a cool, dry environment typically 20° to 25° C (68° to 77° F) with 40-60% relative humidity. Regularly monitor the temperature and humidity of the storage area. • Use a first-in/first-out system for handling stored batteries. •... -
Page 6: Exporting To Foreign Countries
MicroLogix™ 1100 Replacement Battery Shipment of depleted batteries for disposal may be subject to specific regulation of the countries involved or to regulations endorsed by those countries, such as the IATA Restricted Articles Regulations of the International Air Transport Association, Geneva, Switzerland. Do not ship lithium batteries on passenger aircraft. - Page 7 MicroLogix™ 1100 Replacement Battery For a lithium battery product safety data sheet, contact the manufacturer: Sanyo Energy Corporation Tadarand US Battery Division 600 Supreme Drive 2 Seaview Blvd. Bensenville, IL 60106 Port Washington, NY 11050 Collect batteries for disposal carefully to prevent short circuiting, compacting, or destroying the battery case.
-
Page 8: Overheated Batteries
MicroLogix™ 1100 Replacement Battery Disposal of Damaged and/or Leaking Batteries If the batteries are badly damaged and/or leaking, evacuate all personnel ATTENTION from the immediate area. You must wear protective clothing (protective eyewear, clothes, safety shield, and self-contained breathing apparatus). Do not: •... -
Page 9: In Case Of A Lithium Fire
MicroLogix™ 1100 Replacement Battery In Case of a Lithium Fire Do not use water or carbon dioxide (CO ) fire extinguishers in a lithium ATTENTION battery fire. Lithium reacts with these substances. If lithium is burning: • avoid exposure to toxic fumes from burning lithium •... -
Page 10: Lithium Battery Installation
MicroLogix™ 1100 Replacement Battery Lithium Battery Installation Battery Connector Replaceable Battery Wire Guide Retainer Clips Wire Guide Replaceable Battery Battery Connector Retainer Clips Publication 1763-IN003A-EN-P - August 2005... -
Page 11: Installing Lithium Battery (1763-Ba)
MicroLogix™ 1100 Replacement Battery Installing Lithium Battery (1763-BA) For battery installation or replacement do the following: When the controller’s Battery Low indicator is lit, check whether the IMPORTANT battery wire connector is connected correctly or replace the replaceable battery with a new one immediately. When the indicator turns on, it means that either the battery wire connector is disconnected, or the battery will last for at most 2 weeks if it is connected. -
Page 12: Publication 1763-In003A-En-P - August
Allen-Bradley is a registered trademark of Rockwell Automation, Inc. SLC and MicroLogix are trademarks of Rockwell Automation, Inc. Publication 1763-IN003A-EN-P - August 2005 PN 40071-206-01 Copyright © 2007 Rockwell Automation, Inc. All rights reserved. Printed in Singapore. ´H'¶1-206-01*¨...
