Prestige Faux Woods Operation Instructions

Operation Instructions for 2" Motorized Horizontal Blinds - Tilt System
Battery Installation
(Blind)
1. Prior to installing the blind into
the window, remove the batteries
(4 AA Lithium) from their
packaging.
2. The batteries should align as
shown on the diagram inside the
battery holder.
3. Attach battery pack to connector
and insert battery pack into head rail.
NOTE: If mounting the battery pack
external to head rail is preferred,
contact dealer/distributor for battery
pack extension connector
1. Locate female connector on top of motor and insert Satellite Eye
(included) into connector. (Fig. A)
Satellite eye may already be connected by fabricator
2. Install the blind into the window.
3. Attach the valance to the blind.
Attaching Satellite Eye to Valance
4a. Attach included foam tape to front of satellite eye. (Fig. B)
Place satellite eye as close as possible to corner of valance and attach
to inside of valance. (Fig. C)
(If desired, snap off plastic tab Screwport)
Attaching Satellite Eye to Top Treatment
4b. When using a fabric top treatment, attach a safety pin to the
screwport then to drapery making certain that the eye is visible or
attach to the wall or window seal with a small screw. (not included) An
additional 10" satellite eye is available for installations requiring a longer
cord. Contact dealer/distributor to order.
195 Raritan Center Parkway, Edison, NJ 08818-0551
LITHIUM LITHIUM
LITHIUM LITHIUM
Satellite Eye Installation
Prestige Window Fashions
Battery Installation
(Remote Transmitter)
1. Using a philips screwdriver, remove
the screw located towards the bottom
of the remote control face.
2. Install 3 AA alkaline
batteries into bottom half of
remote control. The battery
orientation is shown in the bottom of the remote case.
CAUTION: Do not use lithium batteries in remote control.
3. Place front edge of the
top cover under the lip
of the cap and slide the
cover forward to the stop.
4. Squeeze the housings together and insert the screw to
secure remote control.
Fig. A
Fig. B
Tab/Screwport
Fig. C
Tel: 732-225-2330 www.prestige.com
Valance
Rev. 2 7/05
