Summary of Contents for RVS systems RVS-450C
- Page 2 What’s in the Box? • DVR unit • Suction cup holder • Car Charger • USB cable...
-
Page 3: Table Of Contents
Table of Contents Introduction ....................4 Functions ......................5 Operation ....................6-12 Specifications....................13 Disclaimer ....................14 Warranty.......................15... -
Page 4: Introduction
Please read all of the installation instructions carefully before installing the product. Improper installation will void manufacturer’s warranty. Thank you for choosing our Full HD1080P Parking Mode Car DVR. Please read this user manual carefully before operating the DVR. RVS SYSTEMS... -
Page 5: Functions
Functions Product Image and Feature Identification 8. USB port 9. Microphone 10. Reset 1．Menu 11. ON/OFF 2．Up (Mute On/Off) 12. IR LED 3．REC/Snapshoot 13. Speaker 4．Down (Emergency lock) 14. Lens 5. Mode 15. Charging Indicator 6. HDMI port 16. Screen 7. -
Page 6: Operation
2. To take the Micro SD card out, slightly press the Micro SD card to eject it out. [Note] - Observe the direction to insert the Micro SD card; if the di- rection is reverse, the DVR and the Micro SD card may be damaged. RVS SYSTEMS... - Page 7 Operations - When the Micro SD card is inserted into the DVR, the machine will set the Micro SD card as preset storage unit and the data in the original Micro SD card will be unreadable. - If the Micro SD card is incompatible with the DVR, please insert the card again or replace it for retry.
- Page 8 - Date & Time: Date and time adjustment. - OSD Language: English/Russian/Korean/French/Portuguese/ Chinese, etc. - Light Freq: 50Hz/60Hz - Format: Format the memory card. Select to format the memory card at the first use. - System: Factory Reset / System Info (Version) / Card Info RVS SYSTEMS...
- Page 9 Operations - Delay shutdown: On/Off. As default, 10 sec. off delay is ON, to avoid any improper shutdown command caused by power interruption during recording. Take Video and Set Video Menu 1. Take video After power ON, DVR enters Video Mode as default, with icon displaying at the upper-left corner of screen.
- Page 10 Photos will be stored into memory card automatically. 2. Set Photo Menu During photo mode, press MENU and REC/OK key to enter photo menu settings. - Resolution: 12M/10M/8M/5M/2M - Exposure: EV -2.1/-1.0/0.0/+1.0/+2.1 [Note]: It’s available to switch freely between Video Mode and Photo Mode. RVS SYSTEMS...
- Page 11 Operations Playback Mode 1. Browse Files After the DVR powers ON and enter the VIDEO mode, press the mode key twice to enter the PLAYBACK mode, press the UP/DOWN key to browse the video files or Photo files. [Note] If the File Type (in System Setting) is chosen to be ‘VIDEO’, then only VIDEO files (loop recording files) are available in PLAYBACK mode.
-
Page 12: Operation
During daily operations, improper operation or incorrect memory card probably causes DVR to freeze. Please press the small key RESET on the bottom side of DVR to power OFF the DVR. Power ON DVR manually and DVR will automatically restore the factory defaulted settings. RVS SYSTEMS... -
Page 13: Specifications
Specifications Screen Size........2.7” 960x240 TFT-LCD Lens..........170° A+ classs Glass lens OSD language......English/Russian/Chinese/etc Video Resolution......1080P (30fps)/720P (30fps) Video format........H.264 codec, AVI Photo size........12M/10M/8M/5M/2M Photo format.......JPG Micro-SD card, support from Memory Card....... 4GB-32GB/C6-C10 Microphone/Speaker....Built-In Power Frequency......50Hz/60Hz USB..........USB 2.0 car charger, DC12V-24V Power supply....... -
Page 14: Disclaimer
In no event shall RVS Systems and/or its affiliates have any liability for any losses (whether direct or indi-... -
Page 15: Warranty
RVS Systems, Inc. system after partial failure or use with improper accessories.
