Summary of Contents for Transmitter Solutions Pulse Mini
-
Page 1: Installation Manual
BEEP OPEN PULSE MINI (COM) INSTALLATION MANUAL... -
Page 2: Specifications
INTRODUCTION The Pulse Mini is a mini single door control panel, can work with any Wiegand 26~37 bits output reader. It uses Atmel microcontroller to assure stable performance, and equips with an infrared remote control for easy operation. The Pulse Mini supports 1,000 users; all user data can be transferred. -
Page 3: Package Inventory
Package Inventory Pulse Mini Infrared Remote Control Diode IN4004 (For relay circuit protection) Self Tapping Screws: 3*25mm Wall Anchors Screw Driver INSTALLATION... - Page 4 Wiring Name Notes The Left Side BEEP Beep/ Buzzer Control Green LED Light Control Wiegand Input Data 1 Wiegand Input Data 0 Negative Pole of DC (9~24V) Power Input Positive Pole of DC (9~24V) Power Input The Right Side OPEN Connect to One Wire of Exit Button Normally Open Relay Output (install diode provided) Negative Pole of Lock...
- Page 5 Connection Diagram Magnetic Lock or Fail-safe Lock Door/Gate Operator or Fail-secure Lock When Use NO/NC/COM Dry Contact Output 1) Remove the Pin Caps on points 1, 2 and points 3, 4 2) Insert one of the Pin Caps on points 1, 3 3) Fix the back cover, and keep the other Pin Cap well Remark:...
- Page 6 Notes: Remote Control: Please use the Infrared Remote Control to program the Pulse Mini. The “IR” on the Pulse Mini is the infrared receiving window, please direct the Remote Control to it. User ID number: Assign a user ID to the access card in order to track it.
- Page 7 Pulse Mini Connected with Keypad Reader: Can be any Keypad Reader with 4Bits, 8Bits (ASCII), 10Bits output format Set the Pulse Mini as below step 1 according to the Wiegand output and PIN output format of the Keypad Reader. PIN(s) can be input/added on either the remote control or the external Keypad Reader, except when the Keypad Reader is 10 digits virtual card number ouput, the PIN(s) can only be input/added through the Keypad Reader.
- Page 8 1. Enter Program Mode 1 (Read Card on External Reader) # 2. Add Card: Using Auto ID (Allows Pulse Mini to assign Card to Repeat Step 2 for additional user cards next available User ID number) 1 (User ID) # (Read Card on External Reader) # 2.
- Page 9 Pulse Mini Connected with Fingerprint Reader: For example: Connect F1 as the fingerprint reader to Pulse Mini, two steps to enroll the valid fingerprint. (1) Add the Fingerprint (A) on F1 (2) Add the same Fingerprint (A) on Pulse Mini as below:...
- Page 10 Delete User Card(s) or PIN(s) by Remote Control Programming Step Keystroke Combination * (Master Code) # 1. Enter Program Mode 2 (User ID ) # 2. Delete User By User ID 2 (Read Card on External Reader) # 2. Delete User – By Card 2 (Input 8/10 digits Card number) # 2.
- Page 11 3. Exit Program Mode User Information Transfer The Pulse Mini supports the User Information Transfer function, and the enrolled user(cards, PINs) can be transferred from one (let's name it Master Unit) to another(let's name it Accept Unit). Maximum 10pcs Accepts Units...
-
Page 12: Connection Diagram
Connection Diagram: Remarks: The Master Units and Accept Units must be Pulse Mini or S1234 -X. The Master Code of the Master Unit and the Accept Unit(s) must be set to the same. Program the transfer operation on Master Unit only. -
Page 13: Warranty
WARRANTY The warranty period of Transmitter Solutions® Pulse Mini Receiver is 24 months. This warranty shall begin on the date the transmitter is manufactured. During the warranty period, the product will be repaired or replaced (at the sole discretion of Transmitter Solutions®) if the product does not operate correctly due to a...
