Summary of Contents for EOS FL 2000 K
- Page 1 Installation and User's Guide FL 2000 K / FL 2001 K FL 2001 K FL 2000 K IP x4 Druck-Nr. 29342615en /33.06...
- Page 2 Important Notes Installation Installation inside the cabin unit Improperly installed hardware can To facilitate this, it is necessary to cut a present a fire hazard! Please read this rectangular opening of 670 x 280 mm into installation guide thoroughly. It is especially important to consider the ceiling of the cabin for the small colored applicable dimensions and observe...
- Page 3 Installation Release the quick release fastener screws colored light unit angle bracket (illust. 2) and open the stillage. cabin ceiling wooden frame Illust. 6 Illust. 2 Shut the stillage afterwards and tighten the quick release fastener screws (illust 7). Insert the unit bottom-up into the rectangular opening and fix the unit at the lateral angle brackets with each two wooden screws 4 x 25 (illustr.
- Page 4 Installation Installation on the cabin wall You may only install the unit on the cabin 500 mm (FL 2000) wall in areas 2 and 3 inside the cabin 1100 mm (Illust. 8). (FL 2001) mounting bracket Area 4 Area 1 Area 3 Illust.
- Page 5 = yellow = green = blue Wiring diagram for type FL 2000 K / FL 2001 K with control unit 45 FL 4 special-purpose fluorescent lamps 4 fluorescent lamp ballasts à 20 W (40 W) 4 starters S 10 5-80 W...
- Page 6 90 degrees. Shut the stillage afterwards and tighten the quick release fastener screws Performance data FL 2000 K 4 special-purpose fluorescent lights, 18 W each voltage: 230 V AC N 50 Hz power consumption: 80 W...
- Page 7 Effect of the colors The emotional effects of the colors are GREEN is the color of nature. Green light perceived through the eyes. From there soothes and inspires at the same time and the color rays are relayed by a series of helps recuperation and regeneration.
- Page 8 Direct warranty processing with our service department is in this case not possible. Equipment start-up date: Stamp and signature of the authorized Service address: electrician: EOS-WERKE Günther GmbH Adofl-Weiß-Straße 43 35759 Driedorf, Germany Tel. +49 (0)2775 82-0 Fax +49 (0)2775 82-431 servicecenter@eos-werke.de www.eos-werke.de...
