  • Page 1: Color Monitor

    COLOR MONITOR SyncMaster 570PTFT SyncMaster 570P (RN15P**) SERVICE Manual COLOR MONITOR CONTENTS 1. Precautions 2. Product Specifications 3. Disassembly & Reassembly 4. Troubleshooting 5. Exploded View & Parts List 6. Electrical Parts List 7. Block Diagram AUTO AUTO EXIT EXIT...

  • Page 2: Precautions

    Appliances), and Underwriters Laboratories (UL characteristics as the recommended replacement part Publication UL1410, 59.7). might create shock, fire and / or other hazards. Product safety is under review continuously and new instructions are issued whenever appropriate. SyncMaster 570PTFT / 570P Plus TFT...

  • Page 3: Servicing Precautions

    “anti-static” a carpeted floor can generate enough static can generate electrical charges sufficient to damage electricity to damage an ESD. ESDs. SyncMaster 570PTFT / 570P Plus TFT...

  • Page 4: Product Specifications

    • Headphone: Max 50mW output (3.5-pi jack) • Speaker: Internal semi Dome (16ohm x 2) • SyncMaster 570PTFT/570P Plus TFT complies with SWEDAC (MPR II) recommendations for reduced electromagnetic fields. • Designs and specifications are subject to change without prior notice.

  • Page 5: Pin Assignments

    DDC Data DDC Data H-Sync H/V-Sync Not Used V-Sync Not Used Not Used DDC Clock DDC Clock DDC Clock RCA Video Signal Cable Connector S-Video Signal Cable Connector Composite Separate Pin No. Pin No. CHK_Video SyncMaster 570PTFT / 570P Plus TFT...

  • Page 6: Timing Chart

    O : Frame time total P : Vertical sync width C : Back porch D : Active time Q : Back porch R : Active time E : Front porch S : Front porch SyncMaster 570PTFT / 570P Plus TFT...
  • Page 7 O : Frame time total P : Vertical sync width C : Back porch D : Active time Q : Back porch R : Active time E : Front porch S : Front porch SyncMaster 570PTFT / 570P Plus TFT...

  • Page 8: Disassembly & Reassembly

    2. Remove the 4 screws on the hinge assembly. 1. Remove 5 screws from the Stand Rear 3. Remove the 4 screws on the Stand Rear 2. Remove 4 screws from the Stand Bottom. SyncMaster 570PTFT / 570P Plus TFT...
  • Page 9 Stand Bottom. 8. Remove the 5 stopper hings from the Bracket Bottom. 9. Remove the Stand Base from the Stand Assembly. 3-2 Replacement Order of Lamp Assemblies - RN15PSS (Samsung Panel) SyncMaster 570PTFT / 570P Plus TFT...
  • Page 10 3 Disassembly and Reassembly SyncMaster 570PTFT / 570P Plus TFT...
  • Page 11 3 Disassembly and Reassembly 3-4 Reassembly Reassembly procedures are in the reverse order of Disassembly procedures. SyncMaster 570PTFT / 570P Plus TFT...

  • Page 12: Troubleshooting

    Does proper DC 12 V appear at Check DC Adaptor. DC jack connected to CN102? Does proper DC 5 V appear at Check FT101 and IC104. Pin 4 of IC104? Check IC101 and IC103. SyncMaster 570PTFT / 570P Plus TFT...
  • Page 13 Replace IC501 or check its Do the sync pulses appear at Do the sync pulses appear at Pins related circuit. FT509? 30, 31 and 32 of IC501? Replace IC501 or check its related circuit. Replace LCD Panel SyncMaster 570PTFT / 570P Plus TFT...
  • Page 14 CH1 FREQ= 15.6 kHz CH1 RMS = 48.0 kHz IC501 #31 IC501 #32 IC541 #5 IC161 #6 CH1 FREQ= 65.1 MHz CH1 RMS = 2.0 V CH1 RMS = 2.0 V CH1 RMS = 2.0 V SyncMaster 570PTFT / 570P Plus TFT...
  • Page 15 4 Troubleshooting Memo SyncMaster 570PTFT / 570P Plus TFT...

  • Page 16: Exploded View & Parts List

    5 Exploded View and Parts List 5-1 Multimedia Pivot-base RN15PSS (SAMSUNG PANEL) SyncMaster 570PTFT / 570P Plus TFT...
  • Page 17 5 Exploded View & Parts List 5-2 Multimedia-base RN15PSS (SAMSUNG PANEL) SyncMaster 570PTFT / 570P Plus TFT...
  • Page 18 5 Exploded View & Parts List 5-3 Pivot-base RN15PSS (SAMSUNG PANEL) SyncMaster 570PTFT / 570P Plus TFT...
  • Page 19 5 Exploded View & Parts List 5-4 Simple-base RN15PSS (SAMSUNG PANEL) SyncMaster 570PTFT / 570P Plus TFT...
  • Page 20 5 Exploded View & Parts List 5-5 Wire frame-base RN15PSS (SAMSUNG PANEL) SyncMaster 570PTFT / 570P Plus TFT...
  • Page 21 5 Exploded View & Parts List Memo SyncMaster 570PTFT / 570P Plus TFT...

  • Page 22: Electrical Parts List

    C-AL,SMD 10uF,20%,16V,WT,TP,4.3x4.3x5.4 C154 2203-000389 C-CERAMIC,CHIP 0.015nF,5%,50V,NP0,TP,201 C155 2203-000389 C-CERAMIC,CHIP 0.015nF,5%,50V,NP0,TP,201 C156 2203-000389 C-CERAMIC,CHIP 0.015nF,5%,50V,NP0,TP,201 C161 2402-000170 C-AL,SMD 1uF,20%,50V,GP,TP,4.3x4.3x5.4 C162 2402-000170 C-AL,SMD 1uF,20%,50V,GP,TP,4.3x4.3x5.4 C169 2203-000204 C-CERAMIC,CHIP 100nF,10%,25V,X7R,TP,2012 C170 2203-000204 C-CERAMIC,CHIP 100nF,10%,25V,X7R,TP,2012 C171 2203-000260 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,2012 SyncMaster 570PTFT / 570P Plus TFT...
  • Page 23 C-AL,SMD 10uF,20%,16V,WT,TP,4.3x4.3x5.4 C292 2203-000204 C-CERAMIC,CHIP 100nF,10%,25V,X7R,TP,2012 C293 2203-000204 C-CERAMIC,CHIP 100nF,10%,25V,X7R,TP,2012 C294 2203-000204 C-CERAMIC,CHIP 100nF,10%,25V,X7R,TP,2012 C295 2402-000108 C-AL,SMD 10uF,20%,16V,WT,TP,4.3x4.3x5.4 C296 2203-000204 C-CERAMIC,CHIP 100nF,10%,25V,X7R,TP,2012 C297 2203-000204 C-CERAMIC,CHIP 100nF,10%,25V,X7R,TP,2012 C298 2203-000204 C-CERAMIC,CHIP 100nF,10%,25V,X7R,TP,2012 C299 2203-000204 C-CERAMIC,CHIP 100nF,10%,25V,X7R,TP,2012 SyncMaster 570PTFT / 570P Plus TFT...
  • Page 24 C-AL,SMD 10uF,20%,16V,WT,TP,4.3x4.3x5.4 C502 2203-000455 C-CERAMIC,CHIP 1nF,5%,50V,NP0,TP,2012 C509 2402-000108 C-AL,SMD 10uF,20%,16V,WT,TP,4.3x4.3x5.4 C510 2203-000455 C-CERAMIC,CHIP 1nF,5%,50V,NP0,TP,2012 C511 2402-000108 C-AL,SMD 10uF,20%,16V,WT,TP,4.3x4.3x5.4 C512 2203-000455 C-CERAMIC,CHIP 1nF,5%,50V,NP0,TP,2012 C541 2402-000170 C-AL,SMD 1uF,20%,50V,GP,TP,4.3x4.3x5.4, C542 2402-000168 C-AL,SMD 100uF,20%,16V,GP,TP,8.3x8.3x6.3 C546 2402-000170 C-AL,SMD 1uF,20%,50V,GP,TP,4.3x4.3x5.4, SyncMaster 570PTFT / 570P Plus TFT...
  • Page 25 CORE-FERRITEBEAD AB,4.5x1.6x1.6mm FT104 3301-001145 CORE-FERRITEBEAD AB,4.5x1.6x1.6mm FT111 2901-001114 FILTER-EMISMD 25VDC,2.0ADC,100nF,3.2x FT121 2901-001114 FILTER-EMISMD 25VDC,2.0ADC,100nF,3.2x FT131 2901-001114 FILTER-EMISMD 25VDC,2.0ADC,100nF,3.2x FT141 2901-001114 FILTER-EMISMD 25VDC,2.0ADC,100nF,3.2x FT146 2901-001114 FILTER-EMISMD 25VDC,2.0ADC,100nF,3.2x FT151 2901-001114 FILTER-EMISMD 25VDC,2.0ADC,100nF,3.2x FT171 2901-001114 FILTER-EMISMD 25VDC,2.0ADC,100nF,3.2x SyncMaster 570PTFT / 570P Plus TFT...
  • Page 26 IC-FLASHMEMORY 29W400,512KX8OR256KX16BIT IC501 1205-001740 IC-TRANSMITTER DS90C385,TSSOP,56P,240MIL IC601 1002-001177 IC-D/ACONVERTER AD5301B,8BIT,SOT-23,6P,6 IC603 1001-001109 IC-ANALOGSWITCH FST3125M,BUSSWITCH&CMOS, JP381 2007-000029 R-CHIP 0OHM,5%,1/10W,DA,TP,2012 JP382 2007-000029 R-CHIP 0OHM,5%,1/10W,DA,TP,2012 JP384 2007-000029 R-CHIP 0OHM,5%,1/10W,DA,TP,2012 L199 2703-001070 INDUCTOR-SMD 100uH,10%,4.5x3.2x3.2mm L299 2703-001070 INDUCTOR-SMD 100uH,10%,4.5x3.2x3.2mm SyncMaster 570PTFT / 570P Plus TFT...
  • Page 27 R-CHIP 47OHM,5%,1/10W,DA,TP,2012 R147 2007-000300 R-CHIP 10KOHM,5%,1/10W,DA,TP,2012 R150 2007-000872 R-CHIP 4.7KOHM,5%,1/10W,DA,TP,2012 R151 2007-001166 R-CHIP 75OHM,5%,1/10W,DA,TP,2012 R152 2007-001166 R-CHIP 75OHM,5%,1/10W,DA,TP,2012 R153 2007-001166 R-CHIP 75OHM,5%,1/10W,DA,TP,2012 R154 2007-000300 R-CHIP 10KOHM,5%,1/10W,DA,TP,2012 R156 2007-000947 R-CHIP 47OHM,5%,1/10W,DA,TP,2012 R158 2007-000947 R-CHIP 47OHM,5%,1/10W,DA,TP,2012 SyncMaster 570PTFT / 570P Plus TFT...
  • Page 28 R-CHIP 47OHM,5%,1/10W,DA,TP,2012 R308 2007-000947 R-CHIP 47OHM,5%,1/10W,DA,TP,2012 R309 2007-000468 R-CHIP 1KOHM,5%,1/10W,DA,TP,2012 R310 2007-000468 R-CHIP 1KOHM,5%,1/10W,DA,TP,2012 R321 2007-000300 R-CHIP 10KOHM,5%,1/10W,DA,TP,2012 R322 2007-000300 R-CHIP 10KOHM,5%,1/10W,DA,TP,2012 R323 2007-000300 R-CHIP 10KOHM,5%,1/10W,DA,TP,2012 R324 2007-000300 R-CHIP 10KOHM,5%,1/10W,DA,TP,2012 R406 2007-000686 R-CHIP 3.3KOHM,5%,1/10W,DA,TP,2012 SyncMaster 570PTFT / 570P Plus TFT...
  • Page 29 2801-003804 CRYSTAL-SMD 24.576MHZ,30PPM,28-AAN,20PF Others Loc. No. Code No. Description Specification BN07-00005A LCD-PANNEL LTM150XS-L02,331.3*257.9*15.9,TN VERTICAL STRIPE,0.297*0.297 P/CORD BH39-10307X CBF-POWER/CORD DET,H05VV-F,250V/6A,IVY,1830MM S/CABLE BN39-00030A CBF-SIGNAL DETACHABLE,1830MM,15P/15P,2990,D-SUB-MALE PROCESS-PBA UNIT BN94-00014F ASSY,PCB-ST RN15PS-XGA1/0000,EDC,EUROPE B/D ASS’Y CODE BN98-00005G ASSY,PCB/MAIN-ST RN15PSS-XGA1/0000,EDC,EUROPE SyncMaster 570PTFT / 570P Plus TFT...

  • Page 30: Block Diagram

    7 Block Diagram SyncMaster 570PTFT / 570P Plus TFT...
  • Page 31 7 Block Diagrams Memo SyncMaster 570PTFT / 570P Plus TFT...

  • Page 32: Wiring Diagram

    5: PORTC (3) 12: GND 6: PORTC (4) 7: PORTC (5) CN102 CN101 Function 1: RED 2: GREEN 3: BLUE 4 ~ 8: GND 9: N.C 10: SELF-TEST 11: GND 12: DDC_DATA 13: H_SYNC 14: V_SYNC 15: DDC_CLK SyncMaster 570PTFT/570P Plus TFT...

  • Page 33: Schematic Diagrams

    +3.3V_A +3.3V_B +3.3V_P +3.3V +3.3V +3.3V +3.3V +3.3V_P GRE(7:0) GRO(7:0) CHK_DSUB GGE(7:0) +5V_IN GREF GCOAST GBLKSPL GGO(7:0) RESET GHSFOUT ADPDNn GBE(7:0) GBO(7:0) +3.3V +3.3V GCLK GFBK WR0n +3.3V WR1n GSOG ADPDNn +3.3V MCKEXT +5V_IN +3.3V_D DCKEXT SyncMaster 570PTFT/580P Plus TFT...
  • Page 34 IC146 #5 IC102 IC141 #4 CH1 FREQ= 64.8 MHz CH1 RMS = 2.0 V CH1 FREQ= 19.5 MHz IC151 #115 IC151 #117 IC161 #6 CH1 FREQ= 32.4 MHz CH1 FREQ= 48.0 kHz CH1 RMS = 2.0 V SyncMaster 570PTFT/580P Plus TFT...
  • Page 35 9 Schematic Diagrams 9-2 VIDEO DECODER Part Schematic Diagram +5V_A +3.3V_D +3.3V_D CHK_VIDEO +3.3V_D VPEN RESET_V ADPDNn VCLK VFIELD SyncMaster 570PTFT/580P Plus TFT...
  • Page 36 9 Schematic Diagrams IC211 #21 IC211 #26 CH1 FREQ= 13.4 MHz CH1 FREQ= 15.6 kHz SyncMaster 570PTFT/580P Plus TFT...
  • Page 37 RESETn MAINPWB LVDS_EN CHK_SVIDEO GBE(7:0) CHK_VIDEO CHK_DSUB LEDGRN LEDRED ADPDNn LCPWON +3.3V AUXPWON GRO(7:0) VPPEN BOOTWE GGO(7:0) DCLK DENG DRE(7:0) GBO(7:0) DGE(7:0) GFBK GREF GBLKSPL DBE(7:0) GCOAST GHSFOUT VCLK VPEN VFIELD VR(7:0) VG(7:0) VB(7:0) +2.5V +3.3V SyncMaster 570PTFT/580P Plus TFT...
  • Page 38 9 Schematic Diagrams IC301 (CFT301 #3) CH1 FREQ= 64.7 MHz SyncMaster 570PTFT/580P Plus TFT...
  • Page 39 9 Schematic Diagrams 9-4 LVDS Part Schematic Diagram +3.3V +3.3V +3.3V_D LCPWON MAINPWB +5V_IN +5V_D RESET_V RESETn AUXPWON SyncMaster 570PTFT/580P Plus TFT...
  • Page 40 CH1 FREQ= 48.0 kHz CH1 FREQ= 59.8 Hz CH1 RMS = 500 mv CH1 RMS = 48.0 kHz IC501 #31 IC541 #5 IC501 #32 CH1 FREQ= 65.1 MHz CH1 RMS = 2.0 V CH1 RMS = 2.0 V SyncMaster 570PTFT/580P Plus TFT...
  • Page 41 9 Schematic Diagrams 9-5 MEMORY Part Schematic Diagram +5V_IN +3.3V +3.3V ROMWEn BOOTWE ROMWEn ROMOEn +3.3V ROMOEn +5V_IN +5V_IN +3.3V +3.3V PORTC(5:0) LEDRED +3.3V LEDGRN SyncMaster 570PTFT/580P Plus TFT...
  • Page 42 Samsung Electronics Co., Ltd. January 2000 Printed in Korea Code No.: BN68-00098A-01...

This manual is also suitable for:

Syncmaster 570p plus tft

Table of Contents
