Emerson EVC510 User Manual

In the box
SmartCam
USB Cable
User Guide
EVC510
Reset Pin
Downloading SmartCam Pro app Setting up the camera
Open the App Store or Google Play store on your device and search
for "SmartCam Pro", then download and install the app.
The SmartCam Pro app is compatible with:
Before proceeding, make sure your
• iOS 6.0 and later
device is connected to a Wi-Fi
• Android 2.2 and later
network.
SmartCam Pro
1. After installing SmartCam Pro,
launch the app and tap "Add a
camera."
2. Select "Set up camera."
Location of controls
1
5
8GB
Micro SD card
2
3
User Guide
EVC510 4
User Guide
FRONT
1 5
LED indicator
2 6
Adaptor Camera
3 Microphone 7
4 8
Magnet base
Metal base Anchors & screws
Camera list
Add a camera
3. Make sure the blue LED indicator is
blinking rapidly before connecting.
If it is not, reset your camera (see
"Reset camera").
Setup
4. The name of the Wi-Fi network will
automatically be filled in. Enter the
Set up camera
Wi-Fi password or leave it blank if
there is none, then tap "Next."
Set up a new camera, or relocate an existing
camera to a new Wi-Fi network.
Reconnect your camera
Connect or search for an existing camera.
Inserting Micro SD card
Insert the included 8GB Micro SD card into your SmartCam's Micro
SD card slot. (SmartCam supports up to 32GB of storage.)
6
7
8
Micro SD card
BACK
Micro SD card slot
Speaker
Keep your camera unplugged when inserting or ejecting a
Reset button
Micro SD card.
Micro USB port
Connecting
Is the blue indicator light flashing rapidly? Connecting to Wi-Fi...
5. Wait for your camera to connect to
the Wi-Fi network. If your camera
fails to connect, reset the camera
and repeat all the steps.
2%
No Yes
Connect camera to Wi-Fi
6. After a successful connection, you
will be prompted to create a name
Enter the Wi-Fi name and password that Please name the camera and create a
and password for your camera.
your device is connected to. password.
Wi-Fi name Camera name: Camera 1
Your password must meet the
following requirements:
Wi-Fi password Password:
••••••••
Password must be at least 8 characters
and include an uppercase letter, a
lowercase letter, and a number.
- At least 8 characters long
- Contain a number
Confirm
password:
- Contain an uppercase letter
- Contain a lowercase letter
Next Finish
FRONT
Installing camera Reset camera
1. Plug the USB cable into the back of the camera. 1. Insert the reset pin into the reset button on the back of the camera
as shown below.
2. Attach the other end of the cable into the included adaptor to
connect to a power outlet, or plug the USB cable directly into a 2. Press and hold the pin down for 5 seconds.
computer.
3. Wait for the camera to reboot and for the LED indicator to start
blinking rapidly.
SmartCam
Adaptor
USB cable
Power outlet
3. Wait 30 seconds for the camera to boot up.
4. Camera must be reset after it starts up for the first time (see "Reset
camera" on the right). If this is not the first time booting the camera,
skip this step.
App features
Camera list Live camera feed
A preview of your SmartCam will appear on the home screen. View and hear your SmartCam's live camera feed directly from your
device. The Live camera feed can be viewed from several connected
Refresh all the camera previews at once
devices simultaneously.
Camera list
Camera list
Camera 1
Refresh, edit, or remove a camera.
Camera 2
Tap the preview screen to view
the live camera feed.
Take snapshots
Record videos
If your camera is disconnected, reconnect the camera and wait Rotate your device to view your camera in landscape mode.
for the blue LED indicator to remain constant.
Reset pin
Live camera feed
Camera 1
Tap to change resolution
Status: Online
Condition: Good
HD 1280X720
Display: 1280X720 HD
SD 640X360
Local album
Recording history
Access camera settings
View Recording history &
Local albums
Use camera microphone
