Summary of Contents for Westinghouse JSG20-10N1
- Page 1 ELECTRIC WATER GAS HEATER HT351F12 Note: Before operating or installing this gas water heater read this manual and follow all safety rules and operating instructions. 2,800 12 L 1/2 ~ 1/2 VOLTAJE CAPACITY CONNECTIONS GAS PRESSURE FREQUENCY...
-
Page 2: Table Of Contents
Thank you for purchasing our large capacity automatic gas water heater. Read this Manual before installing and operating and keep for future reference. CONTENTS • Special Advice --------------------------------------------------------------------------------------------- 3 • Factures ---------------------------------------------------------------------------------------------------- 3 • Model instruction ----------------------------------------------------------------------------------------- 4 • Parts Name ------------------------------------------------------------------------------------------------- 5 •... -
Page 3: Special Advice
SPECIAL ADVICE Since the combustion of the gas will consume a large amount of air and produce Monoxide while the heater working, however, if human inbreathe too much Monoxide it will cause danger or even death. Therefore, the users are requested to install and use this heater strictly according to this manual to avoid Monoxide toxicosis. -
Page 4: Model Instruction
FEATURES • Computer control Electric control system adapts imported computer chip, advanced and reliable. • Multiple safety protection With multiple safety protection like unexpectedly power off, unexpectedly flameout, dry-burning etc., safer for use. • Suitable for four season use Broad adjusting range of heat input makes temperature regulation range much wider. Advanced digital constant temperature technology Adapting the proportional control valve for electricity and gas. -
Page 5: Parts Name
Temperature indicator Hot water outlet Cold water outlet Leakage protection plug Gas inlet Drain valve Fig.1(a) JSG16-8CD super thin model (JSG20-10N1 Flue duct Front cover Fig.1(b) 10KL, 12KL, super thin model Control panel Hot water outlet Water volume knob Flue joint... -
Page 6: Dimension
DIMENSION Fig.2(a) JSG16-8CD super thin model (JSG20-10N1) Fig.2(b) 10KL, 12KL, super thin model Fig.2(c) 10K, 12K, common type (All the figures are just for reference, see the product for real apperance) -
Page 7: Specification
SPECIFICATION JSG23-12KL NG/LPG NPT1/2 NPT1/2 Note: This information above is just for reference, please refer to the maneplate on the heater as final information. -
Page 8: Installation
INSTALLATION Contact the local gas dealers or gas management department for qualified engineer to install the gas water heater (users are recommended not to install by themselves). • Please don’t install the heater in the places where special chemical is used, like the laundry or factory etc., otherwise it will cause the metal rusted, shorten the lifetime of the heater, or even can’t work normally. - Page 9 INSTALLATION • The power of the heater is 120V, 60 Hz/AC, the power socket must have a reliable ground wire, and with a switch is much better . If there is water leakage near the power cord, move it to a suitable place (Fig.
- Page 10 INSTALLATION elbow concrete elbow steight flue elbow concrete aluminum glass glue seal foil aluminum aluminum seal foil seal foil sreight flue sreight flue a. flue installed through the window b. flue on the side of the heater c. flue on the back of the heater Fig.
- Page 11 INSTALLATION wrong installation problem caused correct installation exhaust gas leak into room outdoors adnormal combustion outdoors work abnormally common flue Fig. 14 • The 10K, 12K, very thin model has the flue connection, so it won’t be install the flue. •...
-
Page 12: Using Method
USING METHODS For type A and C 1. Preparation before ignition • Make sure that the gas is used according to the gas stipulated in the label. • Insert the plug, and then switch on the power. • Open the water valve, turn the water valve to get suitable water volume if necessary. •... - Page 13 USING METHODS • Turn off the gas valve and power after every use. Frozen prevention Drain the residual water inside the heater to prevent frozen after every use when the environment temperature is near or under 0ºC, do as followed (Fig. 18) •...
- Page 14 USING METHODS Cautions Handling articles Wrong • Heaters which use NG and TG must use the gas type which the heater is designed to use, different type of gas or the same gas in different place must not be used confusedly. Fig.
-
Page 15: Maintenance
USING METHODS Don’t drink water in the heater The water in the heater is not suitable for drink because it always has storage water. Handle with abnormal conditions In case of abnormal burning (fire back, flame lift, yellow tip or black smoke, etc), smell or noise, or other emergent situations, keep calm and shut off... - Page 16 MAINTENANCE • When you use the multi-function shower, the resistance will be too large, and the water inlet pressure will be too low or the water inlet volume will be too little (below the starting up water volume), it will be flameout or can not be ignite, please choose the suitable shower function. •...
-
Page 17: Trouble Shooting
TROUBLE SHOOTING Problems Solutions Reasons Gas valve not open Open the gas valve or recharge gas Open the valve completely Gas valve half open Air in rubber gas pipe Keep turning on and off the water valve till ignition Contact repairer high Abnormal pressure...
