Hotron HR80-WL Setup Instructions

HR80-WL
Thank you for purchasing the dual purpose HR80-WL Wireless Digital Door Key / Digital Touch Pad.
COMPOSITION & SPECIFICATIONS
The number of programmable personal entry codes (passwords)

GENERAL INFORMATION

Screw bolt for
disassembling
/assembling
3M double sided tape
DIMENSION
Hotron Ltd. 26 Dublin Street, Carlow, Ireland.
HR80-WL Setup Instructions
Wireless Digital Door Key main body
Wireless receiver (HR80-RX)
Wireless remote control (FT-240) (optional)
3M double-sided adhesive tape
Battery
User's Manual
Transmission frequency
Battery
Operating temperature
Dimensions (HR80-WL)
International Protection
Upper case
Battery
Lower case
<Precaution for Installation>
Please make sure that you
press firmly down the red
plate after attaching the lower case.
Water proof pad (Silicone rubber)
(When assembling the product,
the water proof pad should not be twisted)
Tel: +353 (0)59 914 0345
Disassembling the upper case
Unfasten the screw bolt,
and use a flat blade (⊖)screwdriver
to disassemble it,
as shown in the figure below.
Water proof pad (Silicone rubber)
Between outside gaps
150
Fax: +353 (0)59 914 0543 Email: info@hotron.com
HOTRON LTD.
1
1
1
1
4 X 1.5V AAA size
1 copy
FM 433.92MHz
4 X 1.5V AAA size
-20℃~50℃
20
150×41×20mm
IP54 (water proof)
unit : m/m
Web: www.hotron.com
