Quick Start Guide
90W Notebook
Power Adaptor
LNP90W10
1 1
Safety
• Your Adapter is not a toy. Keep it away from children. Make sure that all
persons who operate your Adapter read and follow this guide.
• Using your Adapter with non-approved accessories may result in
serious fatal injury and/or property damage.
• Never attempt to use your Adapter to power any devices that require
more than 90W of continuous power.
• Your Adapter is suitable for use only with notebook computers. Do not
use your Adapter with other electronic devices may result in serious
injury and/or property damage.
• For energy saving and safety, disconnect the input power to your
Adapter when it is not in use.
• Your Adapter may become hot during operation. Ensure to provide
ventilation and refrain from placing items on or around your Adapter
during operation. Maintain at least 5cm around the top and sides of
your Adapter. Never operate your Adapter inside a closed or con ned
space such as a glove compartment, console or airline seat pocket.
• When operating your Adapter, regularly check that all connections are
rmly connected. Loose connections can generate harmful heat that
can damage your Adapter or attached notebook computer.
• Do not operate your Adapter near a heat source, heat vent, or in direct
sunlight. Your Adapter should be used in temperatures between 0-40˚C.
• Do not use this adapter LNP90W10 with your notebook if :
• The power requirement is greater than 90W. (For example, the voltage
setting matches, but your notebook requires more amperage).
• Make sure that your notebook's input voltage is between 18VDC -
20VDC before use.
• Keep your Adapter dry. Direct contact of your Adapter to moisture may
lead to electrical shock, causing serious of fatal injury and/or property
damage. Consult a quali ed technician for a complete safety evaluation
before resuming use of your Adapter when it has come into direct
contact with moisture.
• Inspect your Adapter and cables for damage and wear before use. Do
not use or attempt to repair your Adapter and/or cables. Consult a
quali ed technician for a complete safety evaluation if in doubt.
2 2
Unpacking
Remove all items from the packaging. Retain the packaging. If you
dispose of it please do so according to local regulations.
The following items are included:
Main unit Mains Cable x 1
9 9 11 11 12 12
2 2 3 3 4 4 6 6 8 8
TIP02 TIP03 TIP04 TIP06 TIP08 TIP09 TIP11 TIP12
Adapter tips x 8
If items are missing, or damaged please contact Partmaster (UK only).
Tel: 0344 800 3456 for assistance.
