Page 2: Table Of Contents
Contents Features ............... 3 Picture Zoom ..........17 Accessories ............3 Store ............17 Introduction ............4 Reset ............17 Preparation ............4 Sound Menu ............ 17 Safety Precautions ..........4 Volume ............17 Power Source ..........4 Equalizer ............. 18 Power Cord ............ - Page 3 Teletext ............... 23 Tips ..............24 Screen Care ........... 24 Image Persistence .......... 24 No Power ............24 Poor Picture ............ 24 No Picture ............25 Sound ............. 25 Remote Control ..........25 Input Sources ..........25 Appendix: AV and HDMI Signal Compatibility ..26 Specifications .............
-
Page 4: Features
Features Accessories • HD TV: It has one HDMI connector for digital video and audio. This connection is also designed to accept high definition signals. • On Screen Display (OSD): Controlling the TV is very easy by its menu driven system. -/-- SOURCE EXIT... -
Page 5: Introduction
Safety Precautions Introduction Please read the following recommended Thank you for choosing this safety precautions carefully for your safety. product. This manual will guide you for the proper operation of your Power Source TV. Before operating the TV, please The TV set should be operated only from a read this manual throughly. -
Page 6: Cleaning
Cleaning Servicing Before cleaning, unplug the Please refer all servicing to TV set from the wall outlet. qualified personnel. Do not Do not use liquid or aerosol remove the cover yourself as cleaners. Use soft and dry this may result in an electric shock. -
Page 7: Headphone Volume
Headphone Volume Excessive sound pressure from earphones and headphones can cause hearing loss. Installation To prevent injury, this device must be securely attached to the wall in accordance with the installation instructions when mounted to the wall (if the option is available). LCD Screen The LCD panel is a very high technology product with about a million thin film... -
Page 8: Overview Of The Remote Control
Overview of the Remote Control Standby Direct programme External source Info Programme up / Programme down Okay/Freeze picture Cursor buttons Menu -/-- SOURCE EXIT Picture INFO I-II Sound P/CH Time Teletext Mix/no function Expand/Image size MENU TV/DTV Previous programme Picture mode selection Reveal Index page Update/No function... -
Page 9: Lcd Tv And Operating Buttons
LCD TV and Operating Buttons FRONT VIEW Standby button TV/AV button TV/AV MENU button MENU TV/AV Program Up/ MENU P/CH P/CH Program Down buttons Volume Up/ Volume Down buttons SIDE VIEW REAR VIEW English - 8 - ENG-22784W-MB30-1055UK-1HDMI-YPBPR-SPDIF-LOUT-CVBS-WO PC-WO SVHS-50130255.p65 02.07.2008, 17:00... -
Page 10: Viewing The Connections
Viewing the Connections Headphone jack is used for connecting an external headphone to the system. Connect to the HEADPHONE jack to listen to the TV from headphones (optional). Audio Inputs are used for connecting audio signals of external devices. Connect the audio cable between the AUDIO INPUTS on the TV and the AUDIO OUTPUT jacks on your device. - Page 11 S/PDIF Out is used for transferring digital audio signals. Use an RCA cable to transfer audio signals to a device that has S/PDIF input. This connector is for service use only. . Audio Line Outs output audio signals to an external device such as an optional sound system.
-
Page 12: Power Connection
Power Connection IMPORTANT: The TV set is designed to operate on 220-240V AC, 50 Hz. • After unpacking, allow the TV set to reach the ambient room temperature before you connect the set to the mains. • Plug the power cable to the mains socket outlet. Aerial Connection •... -
Page 13: Connecting To A Dvd Player
Connecting to a DVD Player If you want to connect a DVD player to your LCD TV, you can use connectors of the TV set. DVD players may have different connectors. Please refer to your DVD player’s instruction book for additional information. -
Page 14: Using Side Connectors
Using Side Connectors You can connect a range of optional equipment to your LCD TV. Possible connections are shown below. Note that cables shown in the illustration are not supplied. • For connecting a camcorder, connect to the VIDEO IN socket and the AUDIO SOCKETS. Do not connect the camcoder to VIDEO IN socket at the same time since it can cause noise in the picture. -
Page 15: Inserting Batteries In The Remote Control Handset
Inserting Batteries in the Operating Range for the Remote Control Handset Remote Control • Remove the battery cover located on the back • Point the top of the remote control toward of the handset by gently pulling backwards the LCD TV's remote sensor LED while from the indicated part. -
Page 16: Switching The Tv On/Off
To Switch the TV Off Switching the TV On/Off • Press the button on the remote control or To Switch the TV On STANDBY button on the TV, so the TV will • Connect the power cord to the 220-240V AC, switch to standby mode. -
Page 17: Navigating The Menu System
AV Mode Navigating the Menu System • Press the TV/AV button at the control panel For Navigation on the the TV to switch your TV to AV modes. Operation with the Remote Control • The remote control of your TV is designed to For Displaying MENU TV/DTV... -
Page 18: Menu System
Menu System is noisy, use Noise Reduction setting to reduce the noise amount. Picture Menu Press button to select Noise Reduction. Press to choose from one of these options: Low, Medium, High or Off. PICTURE Picture Zoom Mode Cinema Picture Zoom setting enables you to select Contrast... -
Page 19: Equalizer
Equalizer button to increase headphone volume level. Press button to decrease headphone Press button to select Equalizer. Press volume level. Headphone volume level can button to view Equalizer submenu: be adjusted between 0 and 63. Store Press button to select Store. -
Page 20: Sleep Timer
Sleep Timer PC Audio In Press button to select Sleep Timer. This setting controls the PC audio signal. button to set the Sleep Timer. Press button to select PC Audio In. button to set PC Audio In to TV, , The timer can be programmed between Off EXT-1, EXT-2, FAV, YPbPr Audio or PC Audio. -
Page 21: Txt Language
TXT Language Fine Tune Press button to select TXT Language. Press button to select Fine Tune. Press button to change Teletext button to adjust the tuning. Language to West, East, Cyrillic, Turk/Gre, Search Arabic or Persian. Press button to select Search. Use Install Menu button to start programme searching. -
Page 22: Name
programme list and the programmes below shift one line up. APS (Auto Programming System) When you press the BLUE button for APS, Auto Programming System menu will appear on the screen: Program Table lists the channels that are stored in the memory. By moving the cursor in four directions, you can reach 20 programmes in the same page. -
Page 23: Displaying Tv Information
Displaying TV Information Programme Number, Programme Name, Sound Indicator and Zoom Mode information SOURCE : TV are displayed on the screen when a new programme is entered or button is pressed. Mute Function Press button to disable sound. Mute indicator will be displayed in the upper side of the screen. -
Page 24: Panoramic
when you want to change the ZOOM mode, change to another ZOOM mode manually. 16:9 This uniformly stretches the left and right sides Subtitle of a normal picture (4:3 aspect ratio) to fill the This zooms up the wide picture (16:9 aspect wide TV screen. -
Page 25: Tips
Reveal Tips Shows hidden information (e.g. solutions of Screen Care games). Clean the screen with a slightly damp, soft Hold cloth. Do not use abrasive solvents as they may damage the coating layer of the TV Holds a text page when convenient. Press again to screen. -
Page 26: No Picture
No Picture Is the aerial connected properly? Are the plugs connected tightly to the aerial socket? Is the aerial cable damaged? Are suitable plugs used to connect the aerial? If you are in doubt, consult your dealer. No Picture means that your TV is not receiving a transmission. -
Page 27: Appendix: Av And Hdmi Signal Compatibility
Appendix: AV and HDMI Signal Compatibility SUPPORTED SIGNALS SOURCE AVAILABLE PAL 50/60 EXT-1 NTSC 60 (SCART 1) RGB 50 RGB 60 PAL 50/60 EXT-2 NTSC 60 (SCART-2) RGB 50 RGB 60 PAL 50/60 EXT-3 NTSC 60 (SIDE AV) 480I 60Hz 480P 60Hz 576I... -
Page 28: Specifications
Specifications TV BROADCASTING PAL/SECAM B/G D/K K' I/I' L/L' RECEIVING CHANNELS VHF (BAND I/III) UHF (BAND U) CABLE TV (S1-S20/ S21-S41) NUMBER OF PRESET CHANNELS CHANNEL INDICATOR On Screen Display RF AERIAL INPUT 75 Ohm (unbalanced) OPERATING VOLTAGE 220-240V AC, 50 Hz. AUDIO German+Nicam AUDIO OUTPUT POWER (W... -
Page 29: Pin Specifications
Pin Specifications HDMI connector pin specifications Input signal Input signal TMDS Data2+ TMDS Clock Shield TMDS Data2 Shield TMDS Clock- TMDS Data 2- TMDS Data 1+ Reserved (N.C. on device) TMDS Data1 Shield TMDS Data1- TMDS Data0+ DDC/CED Ground TMDS Data0 Shield +5V Power TMDS Data0- Hot Plug Detect... -
Page 30: Important Instruction
Important Instruction For your own safety read following instruction carefully before attempting to connect this unit to the mains supply. MAINS (AC) OPERATION The wires in the mains lead are coloured in accordance with the following code : GREEN FUSE &...
