This manual contains installation, operation, and programming instructions for the
ST OP
STOP! If you prefer to program with SmartPro, refer to manual number 920-0451-00.
Contents:
Introduction, Fusing Considerations, Warnings..................................2
Installation & Mounting....................................................................3-4
Maintenance.......................................................................................5
Warning Signal Modules.................................................................5-6
3 Level Modes of Operation...............................................5
Selecting Flash Patterns....................................................6
IMPORTANT!
Read all instructions before installing and using. Installer: This manual must be delivered to the end user of this equipment.
INSTALLATION & OPERATION MANUAL
Sirennet SNLBL10 47" LED Lightbar.
Traffic Arrow Functions........................................................................7
Takedown and Alley Light Modules......................................................8
Steady Burn Setting.............................................................................9
Diagnostic Testing, Harness Wiring Guide.........................................10
Notes.................................................................................................11
Warranty............................................................................................12
Page 1 of 12
Advertisement
Table of Contents
Summary of Contents for Sirennet SNLBL10
-
Page 1: Table Of Contents
INSTALLATION & OPERATION MANUAL This manual contains installation, operation, and programming instructions for the Sirennet SNLBL10 47" LED Lightbar. ST OP STOP! If you prefer to program with SmartPro, refer to manual number 920-0451-00. Contents: Introduction, Fusing Considerations, Warnings........2 Traffic Arrow Functions................7 Installation &... -
Page 2: Introduction, Fusing Considerations, Warnings
Introduction: The Sirennet SNLBL10 Lightbar is a light bar that is approximately 2” high, yet delivers unobstructed 360° warning and more signal power and versatility than any other light bar of its size through the use of state-of-the-art optics. The low profile and aerodynamic lines reduce air drag, which results in fuel savings and stability at high speeds. This light bar has a strong extruded internal frame, shock-resistant polycarbonate lenses, and warning signals that exceed SAE standards. -
Page 3: Installation & Mounting
Installation and Mounting Unpacking and Pre-Installtion: Carefully remove the light bar and place it on a flat surface, taking care not to scratch the lenses or damage the cable coming out of the bottom. Examine the unit for transit damage, broken lamps, etc. Report any damage to the carrier and keep the shipping carton. Standard light bars are built to operate on 12 volt D.C. negative ground (earth) vehicles. If you have an electrical system other than 12 volt D.C. negative ground (earth), and have not ordered a specially wired light bar, contact the factory for instructions. - Page 4 The special hooks are stainless steel and should be saved and reused. Mounting kit parts are available to permit remounting on vehicles of different design or make. Consult the Sirennet team for detailed information.
-
Page 5: Maintenance
Maintenance Lens Cleaning: Use plain water and a soft cloth, or lens polish and a very soft paper towel or facial tissue. Because plastic scratches easily, cleaning is recommended only when necessary (about every six months). Do not subject the lenses to car washes that use brushes, as these will scratch the lenses. Pry Up to Lens Removal (Clips): Twist to Lift... -
Page 6: Selecting Flash Patterns
Select Flash Patterns STEP 1: Power-up the light bar. Select the desired 3-Level mode to configure by applying +power to the appropriate wire in the 16 conductor cable (see Table 1). STEP 2: Continue applying +power to the wire(s) from Step 1. Enter Flash Pattern Selection Mode by applying +power to the BLK/RED wire in the 16 conductor cable. NOTE: The BLK/RED wire must be connected to +power during Flash Pattern Selection Mode and must be removed from +power when flash rate selection is completed. -
Page 7: Traffic Arrow Functions
Traffic Arrow Functions: Selecting the Traffic Arrow Sequence and Warning Flash Patterns: This lightbar is designed to offer user selectable traffic directing flash sequences. Each of the Traffic Arrow functions (LEFT, CENTER-OUT, RIGHT) can be configured individually for unique sequences and flash rates. This allows the greatest flexibility when controlling the various light bar configurations available. The lightbar will come from the factory with Building Fast (Mode 1) as the default for LEFT, CENTER- OUT and RIGHT. If it is desired to change the sequence for any of the functions, follow the configuration procedure below. STEP 1: Power-up the light bar. Apply +power to the appropriate wire for the Traffic Arrow function that you wish to configure (LEFT - RED, CENTER- OUT - RED and ORG, RIGHT - ORG). -
Page 8: Takedown And Alley Light Modules
Takedown and Alley Light Modules: Selecting the Takedown and Alley Module Flash Rates: The Takedown and Alley Lights can be programmed to flash at different rates when the Takedown Flash or Alley Flash input wires are activated. NOTE: The Takedown Steady-Burn and the Alley Steady-Burn functions will override the Takedown and Alley lighthead flashing in any of the 3-Level modes of operation. STEP 1: Power-up the light bar. Select the Takedown Flash Mode (BLK) or the Alley Flash Mode (BLU/WHT) by applying +power to the appropriate wire. -
Page 9: Steady Burn Setting
Steady Burn Setting The Steady Burn feature allows up to two (2) of the lightbar's light heads to be designated to operate in Steady Burn mode. The Steady Burn light heads are always connected to connectors P9 & P10. The Steady Burn outputs are enabled by the 3-Level control inputs. The lightbar may be configured so that Steady Burn light heads are on when either L1, L2 or L3 are active (JP1 position);... -
Page 10: Diagnostic Testing, Harness Wiring Guide
Lightbar Diagnostic Testing: STEP 1: Apply power to the two main heavy gauge power wires (Red and Black). STEP 2: Apply +12VDC to the Black/Red trigger wire. The lightbar will cycle through lighting up each and every light module so that you can verify that it is functioning properly. -
Page 11: Notes
Notes: Page 11 of 12... -
Page 12: Warranty
Manufacturer Limited Warranty Policy: Manufacturer warrants that on the date of purchase this product will conform to Manufacturer’s specifications for this product (which are available from the Manufacturer upon request). This Limited Warranty extends for Sixty (60) months from the date of purchase. DAMAGE TO PARTS OR PRODUCTS RESULTING FROM TAMPERING, ACCIDENT, ABUSE, MISUSE, NEGLIGENCE, UNAPPROVED MODIFICATIONS, FIRE OR OTHER HAZARD;...
