ZigBee Power Plug ZPLUG User Manual Révision 4.0 Document : UM_ZPLUG_20090903_001_04_00 S.A. au capital de 167 200 € R.C.S. Saint Brieuc TGI 450 570 767 Siège social : 3 Rue Thomas Edison 22300 Lannion France Tél. : +33 (0) 2 96 48 68 18 – Fax : +33 (0) 2 96 48 19 11... -
Page 2: Warranty
In order to invoke the warranty, the buyer must immediately send written notice to CLEODE of the flaws that it attributes to the device. It must enable CLEODE to have access to the device to observe these defects and repair them. The warranty provided by CLEODE is strictly limited to the equipment provided and shall only have for effect the replacement or repair, at CLEODE’s expense, on its own premises, of all devices or parts that are not... -
Page 3: Table Of Contents
User Manual – ZPLUG ABLE OF CONTENT WARRANTY ............................2 REFERENCE DOCUMENTS ......................6 INTRODUCTION ........................... 7 ZPLUG P ....................... 7 RESENTATION ........................... 7 OPYRIGHT ZPLUG DESCRIPTION ....................... 8 II.1 ......................8 EE PRESENTATION II.2 DESCRIPTION OF THE AVAILABLE INFORMATION ............ 8 II.2.1... - Page 4 User Manual – ZPLUG IST OF FIGURES Figure 1 : ZPLUG presentation ....................7 UM_ZPLUG_20090903_001_04_00.doc CLEODE Page 4 sur 14...
- Page 5 User Manual – ZPLUG ABLE OF REVISIONS Version Authors(s) Version description Date CLEODE Initial version 03/09/2009 CLEODE Validated document 08/09/2009 CLEODE Add Technical features chapter 24/09/2009 CLEODE Validated document 24/09/2009 CLEODE Updated for the new design 07/09/2011 CLEODE Validated document...
-
Page 6: Reference Documents
User Manual – ZPLUG EFERENCE DOCUMENTS N° Document Description ZigBee_Cluster_Library_Public Zigbee Cluster Library specification ZigBee_Home_Automation_Profile Home Automation profile specification ZigBee_Specification ZigBee Specification ZigBee_Smart_Energy_Profile Zigbee Smart Energy profile specification UM_ZPLUG_20090903_001_04_00.doc CLEODE Page 6 sur 14... -
Page 7: Iintroduction
I.1 ZPLUG P RESENTATION The ZigBee™ AC 220V plug ZPLUG™ is a module the user can plug on directly in standard 220VAC outlets (C, E or F type) for 3500W max appliance. It is able to monitor how much electricity an appliance plugged into it is using. -
Page 8: Zplug Description
For more detail on the data exchange between device and network, see documents [1], [2], [3] and [4]. The ZPLUG embedded the router functionality with amplified signal up to + 20 dBm. This means that the ZPLUG is able to extend the ZigBee Network. -
Page 9: Ii.2.2 Clusters Description
IdentifyTime the LED of the object is going to flash during the time specified by this value. Attribute Attribute ID IdentifyTime 0x0000 Cluster Groups: This cluster allows to storing the name of the groups to which Zplug belongs. Attribute Attribute ID NameSupport 0x0000 UM_ZPLUG_20090903_001_04_00.doc CLEODE... - Page 10 User Manual – ZPLUG Cluster Scenes: This cluster allows to managing the scene of which is a part Zplug. Attribute Attribute ID SceneCount 0x0000 CurrentScene 0x0001 CurrentGroup 0x0002 SceneValid 0x0003 NameSupport 0x0004 On/Off cluster: This cluster is used to switching the device between On and Off states.
-
Page 11: Installation And Working
By pressing on the present button in facade, By sending a command on ZPLUG by the connection ZigBee. When the output of the ZPLUG is fed, the LED of the ZPLUG is lit in red otherwise it is put out. -
Page 12: Technical Features
User Manual – ZPLUG IV T ECHNICAL FEATURES Weight 150 g Power Supply 220V French standard Accuracy Measurement ±1 % of full scale Commutation Up to 16A on 220V Transmission range 300 m outdoor 90 m indoor Output Power Up to + 20dBm 16 channels ZigBee™... -
Page 13: Repair And Maintenance
User Manual – ZPLUG EPAIR AND MAINTENANCE Defective equipments shall be first reported to the CLEODE support team in order to be assigned an RMA number. Be prepared to state your name, company and the serial number of the defective item to the support personnel. - Page 14 User Manual – ZPLUG CLEODE S.A. Technical Support Division 3 Rue Thomas Edison 22300 Lannion France Phone : +33 (0) 2 96 48 68 18 Fax : +33 (0) 2 96 48 19 11 E-mail : support@cleode.com Web : http://www.cleode.com UM_ZPLUG_20090903_001_04_00.doc...
