Summary of Contents for Hudy Quick-Tweak Station
- Page 2 • Universal station fi ts all 1/10 on-road cars; the fi xed base plate can ends additionally hand ground for precision fitment into bearings be moved along the center axle to shorten the Quick-Tweak Station for measuring 1/12 cars as well •...
- Page 3 ➊ Before you check & correct the tweak of the car, make sure that DETAIL you are working on perfectly fl at surface. For best results use the ultra-fl at HUDY Set-up Board (#108201) and HUDY Set-Up board decal (#108211). 1/10 cars approximately 260mm...
- Page 4 PIVOTING base plate. • For touring cars (or other cars with fully-independent suspension), tweak #109370 HUDY alu set-up wheels for rubber tires for better checking of tweak. For 1/10 electric foam-tired touring cars and pan cars, we adjustments are typically made using shock spring preload.
- Page 5 With their long and distinguished history for #109305 coming up with unique ideas and innovations, HUDY is the leader in the RC Universal Set-up System all 1/10 nitro & electric touring cars tool and set-up industry… there simply is no better.
- Page 6 HUDY Quick Downstop Gauge Tool 1.0 ~ 6.5mm Ultra-fi ne Droop Gauge Step increment: 0.2mm » #107750 HUDY Ultimate Tweak Station HUDY Quick Camber Gauge for 1/10 Touring Cars 1.5°, 2°, 2.5° (included only in All-In-One Set-up Solution #108255) » » »...
