Nat 3110-000 Installation And Operation Manual

NAT Part #: 3110-000
Document #: SM3110\3110-000\810-0
This supplement contains installation and operation information that is unique to the
3110-000 Audio Control Panel. Installation and operation information common to the
3110-100 base unit can be found in the Installation and Operation section of the
SM3110 Installation and Service Manual.
1 Description
The 3110-000 is identical to the 3110-100 with the following exceptions.
a) Changes to the faceplate can be found by comparing figure 1 to figure 2.
COM1 COM2 COM3
NAV1 NAV2 DME1
INPH V BOTH ID ST
Figure 1: 3110-100
b) The COM3, HF, and CAB knobs, push-button switches, and indicators are
not installed on the front panel.
c) The ADF2 knob is not installed on the front panel.
Sep 16, 2005
ENG-FORM: 810-0105.DOT
CONFIDENTIAL AND PROPRIETARY TO NORTHERN AIRBORNE TECHNOLOGY LTD.
INSTALLATION AND OPERATION
MANUAL SUPPLEMENT
HF CAB PA
DME2 MKR ADF1 ADF2
VOX MUTE SPKR HDPH
Description: Audio Control Panel
Rev: 1.00
COM1 COM2
NAV1 NAV2 DME1 DME2
INPH V BOTH ID ST VOX
Figure 2: 3110-000
PA
MKR ADF1
MUTE SPKR HDPH
Page 1 of 2
