Summary of Contents for RC4WD LiPo JST Plug Charger

  • Page 2: Recommended Tools

    Recommended Tools Hex Drivers (1.5mm and 2mm) 1/18 Gelande II Scale RTR Truck...

  • Page 3: Warranty

    This warranty lasts 30 days after arrival for original purchaser. In the event of a defect under this warranty, RC4WD will, at our discretion, replace the product, provided our inspection indicates that an original defect exists. RC4WD reserves the right to replace any product which is no longer available with a product of comparable value and function.

  • Page 4: Specifications

    5. Always unplug the battery from the charger immediately upon completion of charging. CAUTION: Overcharging a battery may cause a fire. SPECIFICATIONS Model RC4WD LiPo JST Plug Charger Input 110-240V~50/60Hz Output 7.4V This charger is designed to charge only 7.4V 850mAh 2S LiPo Battery.
  • Page 5 Failure to follow instructions associated with this symbol risks injury or even death! Avoid battery liquid contact with skin and clothing. If contact occurs, remove contaminated clothing and wash skin thoroughly with water. Before Use: Read and understand the battery and charger operating instructions before recharging. NEVER place a battery into water.
  • Page 6 LED will flash when the battery is low. Indicator Replace immediately Step 2. Receiver and Servo Connection Step 3. Installing the Batteries Remove the battery cover and install 4 new RC4WD AA batteries in the transmitter. Replace the battery cover. Motor ON/OFF Batt Bind...
  • Page 7 XR2 Micro Radio Step 4. Binding the Transmitter and Receiver Turn on the receiver power. Press the SW switch. Turn on the transmitter. The receiver’s LED should start flashing. When the LED on the receiver becomes solid, the binding process is completed. Step 6.
  • Page 8 1/18 Gelande II Scale RTR Truck Electronic Manual This is a step-by-step overview of your new truck's electrical items and how they connect. 1. Outcry II ESC (Z-E0078) 2. Connect the power cable with JST connector to power socket 1/18 Gelande II Scale RTR Truck...
  • Page 9 3. Connect motor to motor plug 4. Connect servo to servo plug 1/18 Gelande II Scale RTR Truck...
  • Page 10 5. Shows the battery (Z-E0080) connected to the ESC 6. This final step shows all the items as they are connected on the truck 1/18 Gelande II Scale RTR Truck...
  • Page 11 Rock Body Remove the battery cover and install 4 new Use the 2mm Hex Drivers, remove the four RC4WD AA batteries in the transmitter. screws from the underside of the truck. Replace the battery cover. Warning: LED will flash when the battery is low.
  • Page 12 Step 6. Turn on the transmitter Step 7. install the Battery Install your new RC4WD 850 mAh battery pack using the included velcro strap. Step 9. Turn the switch to ON Step 8. Plug in Battery 1/18 Gelande II Scale RTR Truck...
  • Page 13 Step 11. Reinstall the body Step 10. Transmitter Adjustments Get familiar with the steering and throttle. Steering Wheel Throttle Trigger 1/18 Gelande II Scale RTR Truck...

  • Page 14: Replacement Parts

    Replacement Parts RC4WD 7.4V 850mAh 2S LiPo Battery (Z-E0080) Rock Crusher 1.0" Micro Crawler Tires (Z-T0027) 2-in-1 Micro ESC + Receiver for XR2 Micro Radio (Z-E0078) 9G Analog Metal Gear Micro Servo (Z-E0077) RC4WD 1/18 Black Rock Body Set (Z-B0113) Stamped Steel 1.0"...
  • Page 15 Body Remove the battery cover and install 4 new Use the 2mm Hex Drivers, remove the four RC4WD AA batteries in the transmitter. screws from the underside of the truck. Replace the battery cover. Warning: LED will flash when the battery is low.
  • Page 16 Step 6. Turn on the transmitter Step 7. install the Battery Install your new RC4WD 850 mAh battery pack using the included velcro strap. Step 9. Turn the switch to ON Step 8. Plug in Battery 1/18 Gelande II Scale RTR Truck...
  • Page 17 Step 11. Reinstall the body Step 10. Transmitter Adjustments Get familiar with the steering and throttle. Steering Wheel Throttle Trigger 1/18 Gelande II Scale RTR Truck...
  • Page 18 Replacement Parts RC4WD 7.4V 850mAh 2S LiPo Battery (Z-E0080) Dirt Grabber 1.0" Micro Crawler Tires (Z-T00142) 2-in-1 Micro ESC + Receiver for XR2 Micro Radio (Z-E0078) 9G Analog Metal Gear Micro Servo (Z-E0077) RC4WD 1/18 Black Rock Body Set (Z-B0113) Stamped Steel 1.0"...
  • Page 19 Step 4. Installing the Batteries Step 5. Remove RC4WD D90 Body Remove the battery cover and install 4 new Use the 2mm Hex Drivers, remove the four RC4WD AA batteries in the transmitter.
  • Page 20 Step 6. Turn on the transmitter Step 7. install the Battery Install your new RC4WD 850 mAh battery pack using the included velcro strap. Step 9. Turn the switch to ON Step 8. Plug in Battery 1/18 Gelande II Scale RTR Truck...
  • Page 21 Step 10. Transmitter Adjustments Get familiar with the steering and throttle. Steering Wheel Throttle Trigger Go create an adventure and share it with us. Make sure to use @rc4wd on Facebook and hashtag #rc4wd on Instagram. 1/18 Gelande II Scale RTR Truck...
  • Page 22 Replacement Parts RC4WD 7.4V 850mAh 2S LiPo Battery (Z-E0080) Rock Crusher 1.0" Micro Crawler Tires (Z-T0027) 2-in-1 Micro ESC + Receiver for XR2 Micro Radio (Z-E0078) 9G Analog Metal Gear Micro Servo (Z-E0077) RC4WD 1/18 Blackjack Body Set (Z-B0126) Stamped Steel 1.0" Stock Beadlock Wheels (Chrome) (Z-W0263) Punisher Shafts 1/18 (42mm - 50mm / 1.57"...

  • Page 23: Optional Parts

    Rok Lox 1.0" Micro Comp Tires (Z-T0028) Rage 1.0" Beadlock Wheels (Z-W0061) RC4WD Mickey Thompson Baja Claw TTC 1.0" Micro Crawler Tires (Z-T0067) RC4WD Interco Super Swamper TSL/Bogger 1.0" Micro Crawler Tires (Z-T0069) Chubby Mini 3 TON Scale Jack Stands (Z-S0731)
  • Page 24 618 Blossom Hill Rd. Ste. 201 San Jose, CA 95123 100-0034 Web: www.rc4wd.com - Email: support@rc4wd.com...
