- Page 1 SEC-DVR200 4CH HARDDISK RECORDER ANLEITUNG MANUAL MODE D’EMPLOI GEBRUIKSAANWIJZING MANUALE MANUAL DE USO HASZNÁLATI ÚTMUTATÓ KÄYTTÖOHJE NÁVOD K POUŽITÍ BRUKSANVISNING...
-
Page 2: Installing Harddisk
Installing harddisk: 1. Remove the cover by unscrewing the 4 screws at the bottom of the recorder. 2. Connect the power cord and data cable to harddisk. Use supplied screws to fix the harddisk to the chassis the recorder. 3. Replace the cover. -
Page 3: Operation
Connections: 1. Connect the video output of the recorder to the input of a monitor or 2. Connect the cameras to the video input of the recorder. 3. Connect the AC/DC adapter to the 12V connection of the recorder. Operation: 1. -
Page 4: Recorder Setup
Recorder setup: Press “ Menu” into setup menu, use “ Up” and “ Down” to select item, press “ Select” to modify setting and “ Menu” to confirm and exit. MAIN MENU CAMERA SELECT 1234 RECORD SELECT 1234 RECORD MODE EACH RECORD FRAMERATE VIDEO QUALITY... -
Page 5: Overview Menu
Overview menu: Camera Select Record Select Record Mode Auto Record Record Frame Rate Video Quality Password Setup Record Schedule Sub Menu Password Change Hard Drive Setup Picture Setup Motion Setup Restore Factory Default Time Setup Camera select: The recorder can display 4 cameras in one picture (Quad Mode). -
Page 6: Video Quality
In this mode, when the recorder is in watching or recording mode, press “QUAD” button over 3 seconds to make each channel video enlarge to full screen and then display in quad mode in sequence again and again. The recorder will not change its status until a key is pressed. Quad Mode Record all 4 channel video in quad mode. -
Page 7: Record Schedule
“-” = No record “T” = Continue (system default) “A” = Motion triggered Up = Move the cursor Down = Move the cursor Select = Select method RECORD SCHEDULE TTTAAATTTTTTAAAATT ＞ ＜ │ │ │ │ │ │ │ │ │ 0 3 6 9 12 15 18 21 24 PRESS（UP，DOWN）. -
Page 8: Sub Menu/Password Change
Sub menu/password change: System default password: press six times “ CH1” button. All keys can be used as password key except “ Menu” key, which is used for confirming and exit. CURRENT PASSWORD :…… PASSWORD :…… CONFIRM PASSWORD :…… Sub menu/picture setup: Set every channel with the desired settings HUE: 0-99... -
Page 9: Time Setup
Sub menu/time setup: Press Up and Down to move the cursor and press Select to modify. Press Menu to save and exit. TIME SETUP ∨ 2008/01/18 08:30:00 PRESS(UP,DOWN), THEN(SELECT) PRESS(MENU) TO EXIT Hard drive set-up: HARD DISK SETUP ＞OVERWRITE ENABLED [YES] HDD SIZE 120042MB... -
Page 10: Hdd Format
OVERWRITE ENABLED: YES, continues recording and overwrite previous recording when hard disk is full. NO, the recording session stops when hard disk is full. HDD SIZE: It shows the size of the primary hard disk installed in the recorder. HDD USED: It shows the space used on the first hard disk drive for recording and the percent of the used hard disk. - Page 11 MOTION RECORD DURATION: The number indicates how long motioned recording lasts after the movements in front of the camera. MOTION ALARM DURATION: The number indicates how long motioned display on the screen “MOTION”. MOTION DETECTION SETUP: First setup video record method by Motion Triggered. See record ＞...
- Page 12 Restore factory default: Press EDIT button to set factory settings. Note: pressing the EDIT button will immediately restore all settings. PAL/NTSC setting: Set the jumper on the PCB to PAL or NTSC NTSC/PAL Select Recording: Press “Record” to start recording. The recorder will display information on screen.
- Page 13 On screen information: 1. Hard Disk Usage Ration 2. Recording Symbol 3. Channel Names 4. Mode: (QUAD or EACH) 5. Status: (REC, Play, FF1, FF2, FF3, REW, PAUSE) 6. Harddisk Info: ([M] Master disk [S] Slave disk) 7. Record Schedule: (T) Continuous (A) Motion (－) No Record 8.
-
Page 14: Stop Recording
Stop recording: Press “Stop” and the recorder will ask for the password (if password is enabled) Playback: Press Play, the recorder will playback the last recorded data that hasn’t been playback yet. Press Menu, the recorder will list all recorded files. Last recorded file will be at top of the list, press “... -
Page 15: Specifications
Recover lost data: Power error will cause data lost and the recorder will ask for ‘recover data’ please press “ Select” to proceed. Restore recording process: When power error happen during recording process, system will automatically restore recording process after power reconnected. Specifications: ITEM DESCRIPTION... -
Page 16: Safety Precautions
Safety precautions: To reduce risk of electric shock, this product should ONLY be opened by an authorized technician when service is required. Disconnect the product from mains and other equipment if a problem should occur. Do not expose the product to water or moisture. Warranty: No guarantee or liability can be accepted for any changes and modifications of the product or damage caused due to incorrect use of...
