Introduction
The TSS-300 'Poacher Catcher' uses a miniature Passive
Infra-Red Receiver (PIR) to detect the presence of a
warm body moving across the detection range of the
sensor.
If a moving body is detected then Poacher Catcher will
automatically
call
numbers before returning to a monitoring state.
Designed specifically to monitor any area where the
presence of a person is to be detected, Poacher Catcher
has applications in outdoor breeding pens, fisheries,
kennels
and
stables,
surveillance areas, police investigations, meeting rooms,
board rooms and sensitive data processing areas.
Compact size
World-wide compatibility
Virtually maintenance free operation
Rechargeable battery powered
Poacher Catcher TSS-300
User Guide
v4.xx Firmware
one
or
more
pre-programmed
sensitive
or
Features
Poacher Catcher User Guide Rev: 12pv1
bonded
areas,
Page 1
Advertisement
Summary of Contents for templepan TSS-300
-
Page 1: User Guide
Poacher Catcher TSS-300 User Guide v4.xx Firmware Introduction The TSS-300 ‘Poacher Catcher’ uses a miniature Passive Infra-Red Receiver (PIR) to detect the presence of a warm body moving across the detection range of the sensor. If a moving body is detected then Poacher Catcher will... - Page 2 Poacher Catcher Detector Sensor Tube On-Off Control Switch Charger Socket Left is Off Right is On Detector Sensor Tube Walk-Test Indicator Network status: Long flashes = Trying to connect Short flashes = connected Charging Poacher Catcher User Guide Rev:9.1 Page 2...
-
Page 3: Quick Start Setup
Quick Start Setup For normal operation, Poacher Catcher requires no adjustment or settings to be altered. Poacher Catcher should be positioned about 1,5M (5ft) above the ground so that the front face is within line-of-site of the area to be covered. - Page 4 Advanced Setup Notes Poacher Catcher uses a sensitive Passive Infra Red (PIR) to detect the presence of a large body moving across its viewing range. From detection of a body, the first recipient should receive a call within about 1 minute if on battery power and within about 10 seconds if on charge.
- Page 5 Setting the Programmed Phone Numbers The phone number(s) that Poacher Catcher will call when an alert is triggered will probably have been preset for you when you placed your order. The phone numbers for ringing alerts are programmed into Poacher Catcher by sending a text (SMS) message direct to the unit.
- Page 6 Changing The Installed SIM Card Poacher Catcher is normally supplied with a pre-programmed ‘Pay & Go’ SIM card with sufficient credit pre-paid so that the deice is ready to use immediately. Should it become appropriate to change the SIM card for any reason (e.g. to switch to a more suitable network) , the procedure described below must be followed in order to ensure that the new SIM card has the correct information set for Poacher Catcher to function properly.
- Page 7 Notes Regarding Vodafone SIM Cards Depending upon usage, the Poacher Catcher internal SIM card will periodically need topping up with a suitable amount of credit. activated Vodafone Top-Up card will have been included package. To use the Top-Up swipe card, all that needs to be done is to take the card to any retailer displaying the Top-up sign and ask for a top up.
- Page 8 Notes Regarding O2 SIM Cards Depending upon usage, the Poacher Catcher internal SIM card will periodically need topping up with a suitable amount of credit. An activated O2 Top-Up card will have been included in the package. To use the Top-Up swipe card, all that needs to be done is to take the card to any retailer displaying the Top-up sign and ask for a top up.
- Page 9 Notes Regarding Orange / T-Mobile SIM Cards Depending upon usage, the Poacher Catcher internal SIM card will periodically need topping up with a suitable amount of credit. An activated Orange Top-Up card will have been included in the package. To use the Top-Up swipe card, all that needs to be done is to take the card to any retailer displaying the Top-up sign and ask for a top up.
- Page 10 Notes Regarding other provider’s SIM Cards Please refer to your provider’s information if you have an alternative provider’s SIM card installed. Poacher Catcher User Guide Rev:9.1 Page 10...
-
Page 11: Frequently Asked Questions (Faqs)
Make sure that you have programmed an appropriate and correct number into the Poacher Catcher phone-book. If you are in doubt, ask Templepan to check the numbers for you. If the network light only ever flashes slowly, this indicates that no network connection has been made. -
Page 12: Technical Specification
+44 7775 602766 Templepan Security Systems Ltd shall not be liable for any special or consequential damages that result from the use of, the inability to use or the performance of this product, even if Templepan Security Systems Ltd has been advised of the possibility of such damages.
