TRUST 120BM WIRELESS BABY TELEVISION
Instructions when using for the first time
Installation and positioning
1.
2.
1

Introduction

This instruction manual is for users of the TRUST 120BM WIRELESS BABY
TELEVISION. This device can be used as an observation system for your baby. This
device works using radio frequencies and, therefore, does not require any cables.
Advantages:
Transmits wireless audio and video signals detected by the camera.
The 2.4 GHz FM signal passes through walls, floors and ceilings.
Can be extended with the Trust 100 series security cameras (see
www.trust.com).
2

Safety

Carefully read the following instructions before use.
1.
Do not use this device in a damp environment, such as a bathroom, damp
basement, swimming pool, etc.
2.
Never insert objects into the holes on the outside of this device, because
you may touch live components. This may cause a fire or give you an
electric shock.
3.
Do not try to repair this device yourself. If you open or remove the casing,
you may accidentally touch live components. There are also other risks if
you open or remove the casing.
4.
Position the device so that the cables cannot be damaged.
CE 0678
5.
This device operates at a frequency of 2.434 ~ 2.473 GHz. It has been
approved according to the European R&TTE guidelines and meets the
essential requirements and other relevant conditions of Directive
1999/5/EC. This device may be used in all EU countries.
6.
The following limitations are applicable for certain countries.
- Spain -> only channels 2 and 3 may be used.
- France -> only channel 2 may be used if the device is used outdoors.
(All three channels may be used if the device is used indoors.)
7.
There may be limitations for the use of this device outside of the EU. If this
device is used outside of the EU, check whether this device meets local
regulations. Frequency: 2.434 ~ 2.473 GHz, Bandwidth: 16 MHz, Capacity:
10 mW.
8.
The IR LEDs on the camera are not harmful to babies and will not disturb
them.
Chapter
!
(3)
U K
(4)
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 120BM and is the answer not in the manual?

Questions and answers

Summary of Contents for Trust 120BM

  • Page 1 Extending Introduction This instruction manual is for users of the TRUST 120BM WIRELESS BABY TELEVISION. This device can be used as an observation system for your baby. This device works using radio frequencies and, therefore, does not require any cables.
  • Page 2 TRUST 120BM WIRELESS BABY TELEVISION Installation Components The connections and switches on the monitor are specified in table 1 and figure 1. Item Description Purpose 13.5 V DC 1000 mA connector Connect the adapter here. Channel selection switches Selects the channel.
  • Page 3 TRUST 120BM WIRELESS BABY TELEVISION Inserting the batteries (optional) If you do not want to or cannot use an adapter for the camera or monitor, you can also use batteries. These are optional and must, therefore, be bought separately. Use either AA or C size batteries.
  • Page 4 (signal). A maximum of 3 camera can be connected to the monitor. There is no limit to the number of receivers which can be added to the system. This baby monitor is ideal for use with other TRUST CONVENIENCE products. See the Trust website (www.trust.com) for more information.
  • Page 5: Technical Information

    TRUST 120BM WIRELESS BABY TELEVISION Technical information Description Response Wireless technology [RF, IR, … + RF / 2.434 ~ 2.473 GHz frequency] 2. 434 / 2. 453 / 2. 473 Frequency per channel [GHz] [1 / 2 / 3] Optical module [CCD / CMOS / ...] CMOS ¼”...
  • Page 6: Troubleshooting

    TRUST 120BM WIRELESS BABY TELEVISION Troubleshooting Problem Cause Possible solution No image on Only audio was selected. Turn switch G (see figure 1) off. monitor. The batteries have been Reinsert the batteries. inserted incorrectly. Camera and /or monitor Replace the batteries.
  • Page 7 Trust products. You will also have the chance of winning some spectacular prizes. If you still have problems after trying these solutions, please contact one of the Trust Customer Care Centers. You can find more information at the back of this instruction manual.
