Digital Tension Meter User Manual
Summary
1.1 Usage
Digital tension meter is a kind of tension testing equipment which is easy portable and lower
power,it's characteristic is small size,light weight,easy to carry,wide scope of application,high
precision and so on .Apply to relay contact pressure,electronic switch ,micro auto-phone equipment
and armature pressure and so on .
1.2 Product features
Portable：light weight,small size,easy to carry,operation by one hand.
1.2.1
Digital display：LCD display and easy for reading.
1.2.2
Units switch：It has five units:N,Kg,Lb,Oz,g and can switch into each other.
1.2.3
1.2.4 Automatic show down when no operation and lower power.
1.2.5 Ultra-low standby power and long use time.
1.2.6 It can be used more than 100 thousand times continuous.
1.3 Product Specifications
ATL-1
Model
1N
0.1Kg
0.21Lb
Max. Load
3.6Oz
100g
Load
Division
Value
Precision
Power
1 / 6
ATL-2
ATL-3
2N
3N
0.2Kg
0.3Kg
0.41Lb
0.62Lb
7.2Oz
10.8Oz
200g
300g
0.001N
0.0001kg
0.0001Lb
0.001Oz
0. 1g
AAA battery*4
ATL-5
5N
0.5Kg
1.03Lb
18Oz
500g
±0.5%
ATL-10
ATL-20
10N
20N
1Kg
2Kg
2.07Lb
4.14Lb
36Oz
72Oz
1000g
2000g
0.01N
0.001kg
0.001Lb
0.01Oz
1kg
Advertisement
Table of Contents
Summary of Contents for Aliyiqi ATL-1
- Page 1 Units switch：It has five units:N,Kg,Lb,Oz,g and can switch into each other. 1.2.3 1.2.4 Automatic show down when no operation and lower power. 1.2.5 Ultra-low standby power and long use time. 1.2.6 It can be used more than 100 thousand times continuous. 1.3 Product Specifications ATL-1 ATL-2 ATL-3 ATL-5 ATL-10 ATL-20 Model 0.1Kg...
- Page 2 ≥100 hours Use life 128mm*66mm*28mm Dimension About 145g Net weight 1.4 The components and significance The Whole Product Structure 2.1 Outline Structure 2 / 6...
- Page 3 3 / 6...
- Page 4 （To test dental arch wire tension force） ：Press this button,power on /off. 2.1.1 ON/OFF SET：Enter into setting menu via this button. 2.1.2 UNIT/▽：Press this button to switch units in measuring interface ,it can move down when in 2.1.3 setting interface. ZERO：In measuring interface,press this button to clear the screen.
- Page 5 ：Press“SET”key enter into lower limit value setting， 3.2.2 （LODT）Lower limit value setting Press“ ”and“ ”to adjust the number,choose the number you need,Press“SET”key to save and enter into next function .As the picture shows:： ： you can choose minute from 1 to 100,you can 3.2.3 （OFFT）...
- Page 6 the direction of force must always be vertical. 3.3.5 Schematic diagram of the test: Attentions: 4.1 Daily maintenance and repair 4.1.1 Storage and use in a dry environment. 4.1.2 Do not overload. Note：Do not use the volatile chemicals to clean the instrument such as volatile agent,diluent and alcohol. ...
