BPN-DE340SS-WB
i StarUSA - Powered by iStarUSA Group
727 Phillips Drive City of Industry, CA 91748
Introduction:
BPN-DE340SS-WB is iStarUSA 's new generation tray-less hot-swap hard drive
cage. It features the latest transfer rate technology of 6.0 Gb/s (SATA I/II/III). It
also comes with adjustable fans speed control and ultra-quiet cooling fans. By
popular demand, the LED display lights features the new blue light to show
drive activity. Heat dissipation is enhanced by the full aluminum construction
and an 80mm fan. The metal key locks help secure your hard drives and
prevent unauthorized access. Converting three standard 5.25" drive bays into
four usable hard drive slots, it is economically designed to maximize your
investment.
Features:
• Aluminum frame; light weight and durable design
• Support SAS I/II, SATA I/II/III 3.5" hard drives
• Data transfer rate up to 6.0 Gb/s
• Integrative shaping aluminum design for quickest heat dissipation
• Metal key lock mechanism for security
• Removable fan cover for easy maintenance
• Cooling fan (80x80x20mm), detachable, easy service & with
high/low speed selections
• LED for Power & HDD access
• Support hot-swap & RAID configuration (need an additional RAID controller)
3.5"Hard Drive Cage
User's Manual
United States of America
Tel: 1-626-303-8885
Toll-Free: 1-888-989-1189
Email: sales@istarusa.com
Specifications:
Hot Swap
Cooling Fan
Standard Drive Bays
Dimension (W x H x D)
Material
HDD Interface
Weight
Cable
Order Information:
Model Number:
Color:
BPN-DE340SS-WB
Wooden
Hardware Information: Front View
D1
D2
D3
D4
D5
D-1
Power LED, power on: LED indicates blue.
Power o : LED no indication.
D-2 ~ D-5
HDD LED, power on, LED indicates blue.
Purple blinking for HDD access.
D-6
Safety lock, the safety lock safeguards the hard disk in the
correct position and prevents unauthorized access.
BPN-DE340SS-WB
4x3.5"HDD
1x80mm
5.25" Drive: 3
145mm x 125mm x 197.9mm
5.71" x 4.92" x 7.79"
Aluminum Design with Conductive
Dissipation Grooves
SAS I/II, SATA I/II/III
3.75 lbs/ 1.70kg
SATA Cable Included (4pcs)
UPC Code:
846813034623
D6
