GC-ATC-810
USB-High Speed Serial Converter
User's Manual
Overview
The GC-ATC-810 device provides a simple and easy way
to connect Universal Serial Bus (USB) and Serial port
interface. With the advantage of USB port, users have the
capability to utilize the peripheral with serial port interface
in an easy to use environment such as plug and play &
hot swap function. This adapter is designed for ideal
connections to Cellular Phone, Digital Camera, Modems
or ISDN terminal adapter with over 1Mbps data transfer
rate.
The USB-high Speed Serial Converter and software
drivers are capable of providing a no-firmware-change
feature that enable USB interface to be transparent to
serial port peripherals with minimum modifications.
Package Content
•
Hardware: USB-High Speed Serial Converter
•
Software: USB-High Speed Serial Converter
driver on CD-ROM
•
User's Manual
Product Features
•
USB Specification Rev. 1.1,2.0 compliant
•
Support the RS232 Serial interface
•
Up to 460Kbps data transfer rate
•
Support remote wake-up and power
management
LED indication
Red LED ----- Data Sending from USB port to RS-232
Serial Port side
Green LED ---- Data Receiving from RS-232 Serial port
side to USB port
System Requirements
•
IBM PC 486DX4-100 MHz CPU or higher or
compatible system
•
Available USB port
•
CD-ROM drive
•
Windows 98. Windows 2000 .Windows XP.Vista
or iMAG
Driver Installation
Follow the steps below to install driver of USB-High
Speed Serial Converter:
1.
Power on your computer and make sure that the USB
port is enabled and working properly.
2.
Plug in the USB-High Speed Serial Converter into the
USB port and run the Add New Hardware Wizard to
assist you in setting up the new device. Click Next to
continue.
3.
Insert the USB-HS Serial Converter software driver
into the CD-ROM drive and click Next to continue.
For Windows 98, click Search for the best driver for
your device and click to search driver from the floppy
drive D:\DRIVER\Win98&Win2000.
4.
Windows will detect the driver (FTDIBUS.INF) and
shows the USB HS SERIAL CONVERTER. Click
Next to continue installation.
5.
Click Next to continue and let Windows copy the
needed files to your hard disk.
6.
When Windows finished installing the software
required for the new USB to Serial Cable, click Finish.
