First Alert PC910V User Manual

STEP BY STEP GUIDE TO PROGRAMMING
USER'S MANUAL
THIS ALARM
For First Time and When ctivating larm
10 YEAR COMBINATION CARBON MONOXIDE &
SMOKE ALARM WITH VOICE & LOCATION ction:
1. ctivate larm (If the battery
Features:
has not been activated,
• Separate sensors to detect perform Step 8 on page 3).
smoke and CO; the two alarm
systems work independently
• Voice with programmable
location
• Separate audible and
visual signals to indicate
2. Press & Hold Test Button if
alarm levels of smoke or CO
you would like to program the
• Sealed-In Lithium Battery — location or change the location
Sealed-in lithium power supply; of the larm. Release button
no battery replacement after larm responds.
UL STD 217
required over the 10 year CONFORMS TO
ND
3. fter you hear the location of
life of the alarm. UL STD 2034
where you are placing the
Model PC910V
larm, Press & Hold the Test
Button.
M08-0408-004 K1 05/13 Printed in Mexico
Your larm has now been programmed for the location of your choice.
vailable locations:
IMPORT NT! PLE SE RE D C REFULLY ND S VE.
This user's manual contains important information about your
Combination Carbon Monoxide & Smoke larm's operation.
If you are installing this larm for use by others, you must leave
For Reprogramming
this manual—or a copy of it—with the end user.
When it is necessary to reprogram the larm after the unit has been
activated and is in normal operation: Tap the Test button 5 times to
Para el manual del usuario en español,
reset the larm to again access the programming menu.
por favor visite www.firstalert.com.
WH T YOU WILL SEE ND HE R WITH THIS L RM
TABLE OF CONTENTS Under Normal Operations
Voice: Silent
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Fire Safety Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 Power LED: Flashes Green once a minute
Basic Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 Horn: Silent
Step By Step Guide to Programming This larm . . . . . . . . . . . . . . .2
When You Test the larm
What You Will See and Hear With This larm . . . . . . . . . . . . . . .2
Voice: "Testing." "Warning, evacuate smoke in [Location, example:
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3
"Kitchen"]. Evacuate."
Where to Install This larm . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3
Horn: 3 beeps, pause, 3 beeps, voice
Where This larm Should NOT Be Installed . . . . . . . . . . . . . . . .3
Power LED: Flashes Red
How to Install This larm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
If Your Smoke/CO larm Sounds . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Voice: "Warning, evacuate carbon monoxide in [Location, example:
What To Do First–Identify The Type Of larm . . . . . . . . . . . . . . .4
"Kitchen"]. Evacuate."
If the CO larm Sounds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Horn: 4 beeps, pause, 4 beeps, voice
If the Smoke larm Sounds . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
LED: Flashes Red
Using the Silence Features . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5
Weekly Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
If Battery Becomes Low
Regular Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Voice: "Please see manual." Repeated every 5 hours
What You Need To Know bout CO . . . . . . . . . . . . . . . . . . . . . . . .5-6
Horn: chirps once a minute
What is CO? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Power LED: Flashes Green approximately once a minute
Symptoms of CO Poisoning . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Potential Sources of CO in the Home . . . . . . . . . . . . . . . . . . . . .6
If larm is Not Operating Properly
How Can I Protect My Family From CO Poisoning? . . . . . . . . . . . .6
Voice: "Detector error in [Location, example "Kitchen"], please see
Regulatory Information For Smoke/CO larms . . . . . . . . . . . . . .6-7
manual." Repeated every 5 hours
Regulatory Information for CO larms . . . . . . . . . . . . . . . . . . . . .6
Horn: 3 chirps every minute
Regulatory Information for Smoke larms . . . . . . . . . . . . . . . .6-7
LED: Three Green flashes approximately once a minute
Recommended Locations for Smoke larms . . . . . . . . . . . . . .6-7
bout Smoke larms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
larm has reached its End of Life
Special Compliance Considerations . . . . . . . . . . . . . . . . . . . . . . .7-8
Voice: "Detector error in [Location, example "Basement"], please
General Limitations Of Smoke/CO larms . . . . . . . . . . . . . . . . . . . .8
see
Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-10 manual." Repeated every 5 hours
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-10 Horn: 5 chirps every minute
LED: Five Green flashes approximately once a minute
© 2013 BRK Brands, Inc. ll rights reserved.
Distributed by BRK Brands, Inc.
larm Levels of CO are Detected
3901 Liberty Street Road, urora, IL 60504-8122
Voice: "Warning, evacuate carbon monoxide in [Location, example:
Consumer ffairs: (800) 323-9005 • www.firstalert.com
"Kitchen"]. Evacuate." "____ ppm."
Horn: 4 beeps, pause, 4 beeps, voice*
ll BRK ® and First lert ® Smoke larms conform to regulatory
LED: Flashes Red
requirements, including UL217 and are designed to detect particles
*NOTE: If unit goes into CO alarm, the regular 4 beeps-brief pause
of combustion. Smoke particles of varying number and size are
cycle will repeat for four minutes. fter four minutes, the pause will
produced in all fires.
increase to one minute.
Ionization technology is generally more sensitive than photo-
electric technology at detecting small particles, which tend to
Smoke is Detected
be produced in greater amounts by flaming fires, which con-
Voice: "Warning, evacuate smoke in [Location, example: "Kitchen"].
sume combustible materials rapidly and spread quickly. Sources of
Evacuate."
these fires may include paper burning in a wastebasket, or a grease
Horn: 3 beeps, pause, 3 beeps, voice
fire in the kitchen.
LED: Flashes Red
Photoelectric technology is generally more sensitive than
ionization technology at detecting large particles, which tend to
Smoke larm is Silenced
be produced in greater amounts by smoldering fires, which may
Voice: Silent.
smolder for hours before bursting into flame. Sources of these fires may
Horn: Off
include cigarettes burning in couches or bedding.
LED: Flashes Red
For maximum protection, use both types of Smoke larms on each
level and in every bedroom of your home.
INSTALLATION
INTRODUCTION
WHERE TO INSTALL THIS ALARM
FIRE SAFETY TIPS
Minimum coverage for Smoke larms, as recommended by the
Follow safety rules and prevent hazardous situations: 1) Use smoking
National Fire Protection ssociation (NFP ), is one Smoke larm on
materials properly. Never smoke in bed. 2) Keep matches or lighters
every floor, in every sleeping area, and in every bedroom (See
away from children; 3) Store flammable materials in proper containers;
"Regulatory Information For Smoke larms" for details on the NFP
4) Keep electrical appliances in good condition and don't overload
recommendations).
electrical circuits; 5) Keep stoves, barbecue grills, fireplaces and
For CO larms, the National Fire Protection ssociation (NFP )
chimneys grease- and debris-free; 6) Never leave anything cooking
recommends that a CO larm should be centrally located outside of
on the stove unattended; 7) Keep portable heaters and open flames,
each separate sleeping area in the immediate vicinity of the bedrooms.
like candles, away from flammable materials; 8) Don't let rubbish
For added protection, install additional CO larms in each separate
accumulate.
bedroom, and on every level of your home.
Keep alarms clean, and test them weekly. Replace alarms immediately
NOTE: For added protection, install an additional Smoke/CO larm at
if they are not working properly. Smoke larms that do not work cannot
least 15 feet (4.6 meters) away from the furnace or fuel burning heat
alert you to a fire. Keep at least one working fire extinguisher on every
source where possible. In smaller homes or in manufactured homes
floor, and an additional one in the kitchen. Have fire escape ladders or
where this distance cannot be maintained, install the larm as far away
other reliable means of escape from an upper floor in case stairs are
as possible from the furnace or other fuel burning source. Installing the
blocked.
larm closer than 15 feet (4.6 meters) will not harm the larm, but may
increase the frequency of unwanted alarms.
BASIC SAFETY INFORMATION
In general, install combination Smoke and Carbon Monoxide larms:
• On every level of your home, including finished attics and basements.
• Dangers, Warnings, and Cautions alert you to important
• Inside every bedroom, especially if people sleep with the door partly
operating instructions or to potentially hazardous situations.
or completely closed.
Pay special attention to these items.
• In the hall near every sleeping area. If your home has multiple
• This Smoke/CO larm is approved for use in single-family
sleeping areas, install a unit in each. If a hall is more than 40 feet
residences. It is NOT designed for marine or RV use.
(12 meters) long, install a unit at each end.
• t the top of first-to-second floor stairs.
• This combination Smoke/Carbon Monoxide larm has two • t the bottom of the basement stairs.
separate alarms. The CO larm is not designed to detect fire • For additional coverage, install larms in all rooms, halls, and
or any other gas. It will only indicate the presence of carbon storage areas, where temperatures normally remain between 40˚ F
monoxide gas at the sensor. Carbon monoxide gas may be
and 100˚ F (4.4˚ C and 37.8˚ C).
present in other areas. The Smoke larm will only indicate
the presence of smoke that reaches the sensor. The Smoke Recommended Placement
larm is not designed to sense gas, heat or flames.
• This unit will not operate without battery power. The
Smoke/CO larm cannot work until you activate the battery
power pack.
• NEVER ignore any alarm. See "If Your Smoke/CO larm
Sounds" for more information on how to respond to an
alarm. Failure to respond can result in injury or death.
• The Silence Features are for your convenience only and will
not correct a problem. See "Using the Silence Features" for
details. lways check your home for a potential problem
after any alarm. Failure to do so can result in injury or death.
• Test this Smoke/CO larm once a week. If the larm ever fails
to test correctly, have it replaced immediately! If the larm is
In new construction AC and AC/DC smoke alarms MUST
not working properly, it cannot alert you to a problem.
be interconnected to meet NFPA recommendations.
• This product is intended for use in ordinary indoor locations
• When installing on the wall, the top edge of Smoke larms should
of family living units. It is not designed to measure CO levels
be placed between 4 inches (102 mm) and 12 inches (305 mm)
in compliance with Occupational Safety and Health
from the wall/ceiling line. When installing on the ceiling, place the
dministration (OSH ) commercial or industrial standards.
alarm as close to the center as possible.
Individuals with medical conditions that may make them
• In either case, install at least 4 inches (102 mm) from where the
more sensitive to carbon monoxide may consider using
wall and ceiling meet. See " voiding Dead ir Spaces" for more
warning devices which provide audible and visual signals for
information.
carbon monoxide concentrations under 30 ppm. For addi-
tional information on carbon monoxide and your medical NOTE: For any location, make sure no door or other obstruction could
keep carbon monoxide or smoke from reaching the larm. Continued...
condition contact your physician.
1
INST LL TION, Continued
Installing Smoke/CO larms in Mobile Homes
For minimum security install one Smoke/CO larm as close to each
sleeping area as possible. For more security, put one unit in each room.
Many older mobile homes (especially those built before 1978) have little
larm Will Say:
or no insulation. If your mobile home is not well insulated, or if you are
"Welcome, First lert Carbon
unsure of the amount of insulation, it is important to install units on
Monoxide and Smoke larm."
inside walls only.
"No location programmed" if first
time or "[Location, example:
WHERE THIS ALARM SHOULD NOT BE INSTALLED
"Kitchen"] location programmed"
after activating larm. Do NOT locate this Smoke/CO larm:
• In garages, furnace rooms, crawl spaces and unfinished attics.
"To select location, press and
void extremely dusty, dirty or greasy areas.
hold test button now."
• Where combustion particles are produced. Combustion particles
"To save location, press and hold
form when something burns. reas to avoid include poorly ventilated
test button after location is
kitchens, garages, and furnace rooms. Keep units at least 20 feet
heard." larm will speak list of
(6 meters) from the sources of combustion particles (stove, furnace,
locations (see below).
water heater, space heater) if possible. In areas where a 20-foot
(6 meter) distance is not possible – in modular, mobile, or smaller
homes, for example – it is recommended the Smoke larm be
"[Location, example: "Kitchen"]
placed as far from these fuel-burning sources as possible. The
location saved."
placement recommendations are intended to keep these larms at
If no location is chosen: "No a reasonable distance from a fuel-burning source, and thus reduce
location saved."
"unwanted" alarms. Unwanted alarms can occur if a Smoke larm
is placed directly next to a fuel-burning source. Ventilate these
areas as much as possible.
Basement Hallway
• Within 5 feet (1.5 meters) of any cooking appliance. In air streams
Office Child's Bedroom Kitchen Utility Room
near kitchens. ir currents can draw cooking smoke into the smoke
Dining Room Living Room Family Room
sensor and cause unwanted alarms.
Master Bedroom Guest Bedroom No Location
• In extremely humid areas. This larm should be at least 10 feet
(3 meters) from a shower, sauna, humidifier, vaporizer, dishwasher,
laundry room, utility room, or other source of high humidity.
• In direct sunlight.
• In turbulent air, like near ceiling fans or open windows. Blowing air
may prevent CO or smoke from reaching the sensors.
• In areas where temperature is colder than 40˚ F (4.4˚C) or hotter
than 100˚ F (37.8˚C). These areas include non-airconditioned crawl
spaces, unfinished attics, uninsulated or poorly insulated ceilings,
porches, and garages.
• In insect infested areas. Insects can clog the openings to the
sensing chamber.
• Less than 12 inches (305 mm) away from fluorescent lights.
Electrical "noise" can interfere with the sensor.
• In "dead air" spaces. See " voiding Dead ir Spaces".
VOIDING DE D IR SP CES
"Dead air" spaces may prevent smoke from reaching the Smoke/CO
followed by
larm. To avoid dead air spaces, follow installation recommendations
below.
On ceilings, install Smoke/CO larms as close to the center of the
ceiling as possible. If this is not possible, install the Smoke/CO larm
at least 4 inches (102 mm) from the wall or corner.
For wall mounting (if allowed by building codes), the top edge of
Smoke/CO larms should be placed between 4 inches (102 mm) and
12 inches (305 mm) from the wall/ceiling line, below typical "dead air"
spaces.
On a peaked, gabled, or cathedral ceiling, install first Smoke/CO
larm within 3 feet (0.9 meters) of the peak of the ceiling, measured
horizontally. dditional Smoke/CO larms may be required depending
on the length, angle, etc. of the ceiling's slope. Refer to NFP 72 for
details on requirements for sloped or peaked ceilings.
HOW TO INSTALL THIS ALARM
This combination Smoke/CO larm was designed to be mounted on
the ceiling or wall. It is not a tabletop device. You must install this
device on the ceiling or wall as outlined below. Read "Where To Install
This larm" before starting.
CO larm is Silenced
Voice: Silent.
Horn: Off
LED: Flashes Red
Tools you will need: pencil, drill with 3/16" or 5mm drill bit,
flathead screwdriver, hammer.
• Do not install this unit over an electrical junction box. ir
currents around junction boxes can prevent smoke from
reaching the sensing chamber and prevent the unit from
alarming. Only C powered units are intended for installation
over junction boxes.
NOTE: Be sure to mount the product in the orientation specified in
the next steps as this provides the most stability for mounting the
product to the wall or ceiling.
FOLLOW THESE SIMPLE STEPS:
1. Turn alarm upside down so the circular
shape is located in the upper left corner of
the alarm.
2. Slide mounting bracket to the left and lift to
separate it from the base.
3. Hold the mounting bracket against the ceiling
(or wall) so the arrow located on the mounting
plate is pointing to the left. (The circular shape
will now be in upper right-hand corner). Trace
around the insides of the mounting slots.
4. Put the unit where it won't get covered with
dust when you drill the mounting holes.
SUGGESTED AREAS FOR INSTALLING
SMOKE ALARMS, CO ALARMS, AND COMBO UNITS
5. Using a 3/16" (5 mm) drill bit, drill a hole through the center of the
oval outlines you traced in step #3.
KEY:
6. Insert the plastic screw anchors (in the plastic bag with screws) into
the holes. Tap the screw anchors gently with a hammer, if necessary,
SMOKE ALARMS
until they are flush with the ceiling or wall.
SMOKE ALARM WITH
SILENCE FEATURE 7. ttach the mounting bracket to the ceiling or wall.
8. ctivate the battery. Move the activation switch to
CO ALARMS
center position against tab stop. Unit will not mount
BOTH, OR COMBINATION
on mounting bracket unless activated. Once unit is
SMOKE/CO ALARMS
activated, it cannot be turned off.
Suggested locations are based on
NOTE: fter you activate the battery, the power indicator light may
NFPA recommendations (NFPA 72
for Smoke Alarms and NFPA 720 for
flash. (If the unit alarms, the light will blink rapidly, and the horn will
Carbon Monoxide Alarms). Always
refer to national and local codes repeatedly sound 3 beeps, pause, 3 beeps.)
before beginning any installation.
9. ttach the Smoke/CO larm to the
mounting bracket. Line up the arrow
on the back of the unit to the arrow on
the mounting bracket. When the units
are lined up, slide the alarm to the right
until it snaps into place.
NOTE: Once the Smoke/CO larm is
snapped onto the mounting bracket,
you can rotate the Smoke/CO larm to
adjust the alignment.
10. Test the larm. See "Weekly Testing."
2
IF YOUR SMOKE/CO ALARM SOUNDS
WHAT TO DO FIRST–IDENTIFY THE TYPE OF ALARM
Type of larm What You See and Hear
Carbon Monoxide (CO)
Voice: "Warning, evacuate carbon
Horn: 4 beeps, pause, 4 beeps,
LED: Flashes Red
Smoke Voice: "Warning, evacuate smoke
Horn: 3 beeps, pause, 3 beeps,
LED: Flashes Red
IF THE CO ALARM SOUNDS
" L RM-MOVE TO FRESH IR"
If you hear the CO alarm horn and the CO red light is flashing,
move everyone to a source of fresh air.
DO NOT deactivate the larm!
ctuation of your CO larm indicates the presence of carbon
monoxide (CO) which can kill you. In other words, when your CO
larm sounds, you must not ignore it!
IF THE CO L RM SIGN L SOUNDS:
1. Press the Test/Silence button.
2. Call your emergency services, fire department or 911. Write down
the number of your local emergency service here:
____________________________________________________________
3. Immediately move to fresh air—outdoors or by an open door or
window. Do a head count to check that all persons are accounted
for. Do not re-enter the premises, or move away from the open door
or window until the emergency services responder has arrived, the
premises have been aired out, and your CO larm remains in its
normal condition.
4. fter following steps 1-3, if your CO larm reactivates within a
24-hour period, repeat steps 1-3 and call a qualified appliance
technician to investigate for sources of CO from fuel-burning
equipment and appliances, and inspect for proper operation of this
equipment. If problems are identified during this inspection have the
equipment serviced immediately. Note any combustion equipment
not inspected by the technician, and consult the manufacturers'
instructions, or contact the manufacturers directly, for more
information about CO safety and this equipment. Make sure that
motor vehicles are not, and have not, been operating in an attached
garage or adjacent to the residence. Write down the number of a
qualified appliance technician here:
____________________________________________________________
NOTE: qualified appliance technician is defined as "a person, firm,
corporation, or company that either in person or through a representa-
tive, is engaged in and responsible for the installation, testing, servicing,
or replacement of heating, ventilation, air conditioning (HV C) equipment,
combustion appliances and equipment, and/or gas fireplaces or other
decorative combustion equipment."
FTER N L RM
fter the emergency responders arrive, the premises aired out, and
your CO larm remains in its normal condition, you can check what
the highest carbon monoxide level sensed was:
ction: larm Will Say:
P RTS OF THIS SMOKE/CO L RM
1. Press & Hold Test Button "Highest carbon monoxide level
was ___ ppm. Please see manual."
"To clear highest carbon monoxide
1 Test/Silence Button
level, press and hold test button
2 Power/Smoke and CO larm LED
now."
3 Speaker
2. Press & Hold Test Button, if you "Highest carbon monoxide level
would like to clear the highest cleared."
level sensed.
If you would like to keep the larm will say nothing.
highest level in memory, do
not press anything.
1 Mounting bracket
2 Mounting slots
IF THE SMOKE ALARM SOUNDS
RESPONDING TO N L RM
• If the unit alarms and you are not testing the unit, it is warning
you of a potentially dangerous situation that requires your
immediate attention. NEVER ignore any alarm. Ignoring the
alarm may result in injury or death.
• Never remove the batteries from a battery operated Smoke/CO
larm to stop an unwanted alarm (caused by cooking smoke,
etc.). Removing batteries disables the alarm so it cannot sense
smoke, and removes your protection. Instead open a window
or fan the smoke away from the unit. The alarm will reset auto-
matically.
• If the unit alarms get everyone out of the house immediately.
WH T TO DO IN C SE OF FIRE
• Don't panic; stay calm. Follow your family escape plan.
• Get out of the house as quickly as possible. Don't stop to get
dressed or collect anything.
• Feel doors with the back of your hand before opening them. If a
door is cool, open it slowly. Don't open a hot door. Keep doors
and windows closed, unless you must escape through them.
• Cover your nose and mouth with a cloth (preferably damp).
Take short, shallow breaths.
• Meet at your planned meeting place outside your home, and do
a head count to make sure everybody got out safely.
• Call the Fire Department as soon as possible from outside.
Give your address, then your name.
• Never go back inside a burning building for any reason.
• Contact your Fire Department for ideas on making your home
safer.
larms have various limitations. See "General Limitations of
Smoke/CO larms" for details.
USING THE SILENCE FEATURES
Never deactivate the unit to quiet an unwanted alarm. Deactivating
the alarm disables the unit and removes your protection.
The Silence Feature is intended to temporarily silence the horn while
you identify and correct the problem. Do not use the Silence Feature in
emergency situations. It will not correct a CO problem or extinguish a
fire.
The Silence Feature can temporarily quiet an unwanted alarm for several
minutes. You can silence this Smoke/CO larm by pressing the
OFF - ON - DISCHARGE
Test/Silence button on the alarm cover for at least 3-5 seconds.
fter the Test/Silence button is released, the Red LED blinks during the
silence mode.
When the Smoke larm is When the CO larm is Silenced
Silenced
The Smoke larm will remain The CO larm will remain silent
silent for up to 15 minutes, then for up to 4 minutes.
return to normal operation.
fter 4 minutes, if CO levels
If the smoke has not cleared–or
remain potentially dangerous the
continues to increase–the device
horn will start sounding again.
will go back into alarm.
3 4
SILENCING THE LOW BATTERY WARNING
This silence feature can temporarily quiet the low battery warning
"chirp" for up to 8 hours. You can silence the low battery warning
"chirp" by pressing the Test/Silence button on the alarm cover.
Once the low battery warning "chirp" silence feature is activated, the
unit continues to flash the Green light once a minute for 8 hours. fter
8 hours, the low battery "chirp" will resume. Replace the larm as
monoxide in [Location,
soon as possible; this unit will not operate without battery power!
example: "Kitchen"].
Evacuate." "____ ppm."
To deactivate this feature: Press the Test/Silence button again. The
unit will go into Test Mode and the low battery warning will resume
voice (LED flashes and unit sounds "chirp" once a minute).
SILENCING THE END OF LIFE SIGNAL
This silence feature can temporarily quiet the End of Life warning
in [Location, example:
"chirp" for up to 2 days. You can silence the End of Life warning "chirp"
"Kitchen"]. Evacuate."
by pressing the Test/Silence button. The horn will chirp, acknowledging
that the End of Life silence feature has been activated.
voice
fter approximately 2 days, the End of Life "chirp" will resume.
WEEKLY TESTING
• NEVER use an open flame of any kind to test this unit. You
might accidentally damage or set fire to the unit or to your
home. NEVER use vehicle exhaust! Exhaust may cause
permanent damage and voids your warranty.
• DO NOT stand close to the larm when the horn is sounding.
Exposure at close range may be harmful to your hearing.
When testing, step away when horn starts sounding.
It is important to test this unit every week to make sure it is working
properly. Using the test button is the recommended way to test this
Smoke/CO larm.
You can test this Smoke/CO larm by pressing and holding the
Test/Silence button on the larm cover until larm Voice says "Testing"
(typically 3-5 seconds).
During testing, you will see and hear the following sequence:
• The larm Voice will say "Testing." The Horn will sound 3 beeps,
pause, 3 beeps. The larm Voice will say "Warning, evacuate
smoke in [Location, example: "Kitchen"]. Evacuate." The Power
LED flashes Red.
• Next the Horn will sound 4 beeps, pause, 4 beeps. The larm
Voice will say "Warning, evacuate carbon monoxide in [Location,
example: "Kitchen"]. Evacuate." The LED flashes Red.
If the unit does not alarm, make sure it has been activated correctly,
and test again. If the unit still does not alarm, replace it immediately.
REGULAR MAINTENANCE
This unit has been designed to be as maintenance-free as possible, but
there are a few simple things you must do to keep it working properly.
• Test it at least once a week.
• Clean the Smoke/CO larm at least once a month; gently vacuum
the outside of the Smoke/CO larm using your household vacuum's
soft brush attachment. can of clean compressed air (sold at
computer or office supply stores) may also be used. Follow
manufacturer instructions for use. Test the Smoke/CO larm. Never
use water, cleaners or solvents since they may damage the unit.
• If the Smoke/CO larm becomes contaminated by excessive dirt,
dust and/or grime, and cannot be cleaned to avoid unwanted
alarms, replace the unit immediately.
• Relocate the unit if it sounds frequent unwanted alarms. See
"Where This larm Should Not Be Installed" for details.
ctual battery service life depends on the Smoke/CO larm and the
environment in which it is installed. Regardless of the manufacturer's
suggested battery life, you MUST replace the larm immediately once
the unit starts "chirping" (the "low battery warning").
TO PERMANENTLY DEACTIVATE THE SMOKE/CO
ALARM
fter 10 years of operation or Low Battery
warning, deactivate the larm: Insert a tool
below edge where shown and break tab.
Then slide activation switch to discharge mode.
NOTE: t end of life or low battery indication (chirp): unit must be
put in to deactivation mode to discharge remaining stored energy
in battery. Unit will no longer function once put into this mode.
Unit will resist re-mounting.
WHAT YOU NEED TO KNOW ABOUT CO
WHAT IS CO?
CO is an invisible, odorless, tasteless gas produced when fossil fuels
do not burn completely, or are exposed to heat (usually fire). Electrical
appliances typically do not produce CO.
These fuels include: Wood, coal, charcoal, oil, natural gas, gasoline,
kerosene, and propane.
Common appliances are often sources of CO. If they are not properly
maintained, are improperly ventilated, or malfunction, CO levels can
rise quickly. CO is a real danger now that homes are more energy
efficient. " ir-tight" homes with added insulation, sealed windows,
and other weatherproofing can "trap" CO inside.
SYMPTOMS OF CO POISONING
These symptoms are related to CO POISONING and should be
discussed with LL household members.
Mild Exposure: Slight headache, nausea, vomiting, fatigue ("flu-like"
symptoms).
Medium Exposure: Throbbing headache, drowsiness, confusion, fast
heart rate.
Extreme Exposure: Convulsions, unconsciousness, heart and lung
failure. Exposure to Carbon Monoxide can cause brain damage, death.
This CO larm measures exposure to CO over time. It alarms if CO
levels are extremely high in a short period of time, or if CO levels reach
a certain minimum over a long period of time. The CO larm generally
sounds an alarm before the onset of symptoms in average, healthy
adults. Why is this important? Because you need to be warned of a
potential CO problem while you can still react in time. In many reported
cases of CO exposure, victims may be aware that they are not feeling
well, but become disoriented and can no longer react well enough to
exit the building or get help. lso, young children and pets may be the
first affected. The average healthy adult might not feel any symptoms
when the CO larm sounds. However, people with cardiac or respiratory
problems, infants, unborn babies, pregnant mothers, or elderly people
can be more quickly and severely affected by CO. If you experience
even mild symptoms of CO poisoning, consult your doctor immediately!
FINDING THE SOURCE OF CO AFTER AN ALARM
Carbon monoxide is an odorless, invisible gas, which often makes it
difficult to locate the source of CO after an alarm. These are a few of
the factors that can make it difficult to locate sources of CO:
• House well ventilated before the investigator arrives.
• Problem caused by "backdrafting."
• Transient CO problem caused by special circumstances.
Because CO may dissipate by the time an investigator arrives, it may
be difficult to locate the source of CO. BRK Brands, Inc. shall not be
obligated to pay for any carbon monoxide investigation or service
call.
Continued...
5
POTENTIAL SOURCES OF CO IN THE HOME
Fuel-burning appliances like:
portable heater, gas or wood burning
fireplace, gas kitchen range or cook-
top, gas clothes dryer.
Damaged or insufficient venting:
corroded or disconnected water heater
vent pipe, leaking chimney pipe or flue,
or cracked heat exchanger, blocked or
clogged chimney opening.
Improper use of appliance/device:
operating a barbecue grill or vehicle
in an enclosed area (like a garage or
screened porch).
Transient CO Problems: "transient" or on-again-off-again CO problems
can be caused by outdoor conditions and other special circumstances.
The following conditions can result in transient CO situations:
1. Excessive spillage or reverse venting of fuel appliances caused by
outdoor conditions such as:
• Wind direction and/or velocity, including high, gusty winds.
Heavy air in the vent pipes (cold/humid air with extended
periods between cycles).
• Negative pressure differential resulting from the use of exhaust
fans.
• Several appliances running at the same time competing for
limited fresh air.
• Vent pipe connections vibrating loose from clothes dryers,
furnaces, or water heaters.
• Obstructions in or unconventional vent pipe designs which can
amplify the above situations.
2. Extended operation of unvented fuel burning devices (range, oven,
fireplace).
3. Temperature inversions, which can trap exhaust close to the
ground.
4. Car idling in an open or closed attached garage, or near a home.
These conditions are dangerous because they can trap exhaust in your
home. Since these conditions can come and go, they are also hard to
recreate during a CO investigation.
HOW CAN I PROTECT MY FAMILY FROM
CO POISONING?
CO larm is an excellent means of protection. It monitors the air
and sounds a loud alarm before Carbon Monoxide levels become
threatening for average, healthy adults.
CO larm is not a substitute for proper maintenance of home
appliances.
To help prevent CO problems and reduce the risk of CO poisoning:
• Clean chimneys and flues yearly. Keep them free of debris,
leaves, and nests for proper air flow. lso, have a professional
check for rust and corrosion, cracks, or separations. These
conditions can prevent proper air movement and cause
backdrafting. Never "cap" or cover a chimney in any way
that would block air flow.
• Test and maintain all fuel-burning equipment annually. Many
local gas or oil companies and HV C companies offer appliance
inspections for a nominal fee.
• Make regular visual inspections of all fuel-burning appliances.
Check appliances for excessive rust and scaling. lso check the
flame on the burner and pilot lights. The flame should be blue.
yellow flame means fuel is not being burned completely and
CO may be present. Keep the blower door on the furnace
closed. Use vents or fans when they are available on all fuel-
burning appliances. Make sure appliances are vented to the
outside. Do not grill or barbecue indoors, or in garages or on
screen porches.
• Check for exhaust backflow from CO sources. Check the draft
hood on an operating furnace for a backdraft. Look for cracks
on furnace heat exchangers.
• Check the house or garage on the other side of shared wall.
• Keep windows and doors open slightly. If you suspect that CO is
escaping into your home, open a window or a door. Opening
windows and doors can significantly decrease CO levels.
In addition, familiarize yourself with all enclosed materials. Read
this manual in its entirety, and make sure you understand what to
do if your CO larm sounds.
REGULATORY INFORMATION FOR
SMOKE/CO ALARMS
REGULATORY INFORMATION FOR CO ALARMS
WH T LEVELS OF CO C USE N L RM?
Underwriters Laboratories Inc. Standard UL2034 requires residential
CO larms to sound when exposed to levels of CO and exposure times
as described below. They are measured in parts per million (ppm) of
CO over time (in minutes).
UL2034 Required larm Points*:
• If the alarm is exposed to 400 ppm of CO, IT MUST L RM
BETWEEN 4 and 15 MINUTES.
• If the alarm is exposed to 150 ppm of CO, IT MUST L RM
BETWEEN 10 and 50 MINUTES.
• If the alarm is exposed to 70 ppm if CO, IT MUST L RM
BETWEEN 60 and 240 MINUTES.
* pproximately 10% COHb exposure at levels of 10% to 95% Relative
Humidity (RH).
The unit is designed not to alarm when exposed to a constant level of
30 ppm for 30 days.
CO larms are designed to alarm before there is an immediate life
threat. Since you cannot see or smell CO, never assume it's not present.
• n exposure to 100 ppm of CO for 20 minutes may not affect
average, healthy adults, but after 4 hours the same level may cause
headaches.
• n exposure to 400 ppm of CO may cause headaches in average,
healthy adults after 35 minutes, but can cause death after 2 hours.
Standards: Underwriters Laboratories Inc. Single and Multiple Station
carbon monoxide alarms UL2034.
ccording to Underwriters Laboratories Inc. UL2034, Section 1-1.2:
"Carbon monoxide alarms covered by these requirements are intended
to respond to the presence of carbon monoxide from sources such as,
but not limited to, exhaust from internal-combustion engines, abnormal
operation of fuel-fired appliances, and fireplaces. CO larms are intended
to alarm at carbon monoxide levels below those that could cause a loss
of ability to react to the dangers of Carbon Monoxide exposure." This
CO larm monitors the air at the larm, and is designed to alarm before
CO levels become life threatening. This allows you precious time to
leave the house and correct the problem. This is only possible if larms
are located, installed, and maintained as described in this manual.
Gas Detection at Typical Temperature and Humidity Ranges: The
CO larm is not formulated to detect CO levels below 30 ppm typically.
UL tested for false alarm resistance to Methane (500 ppm), Butane (300
ppm), Heptane (500 ppm), Ethyl cetate (200 ppm), Isopropyl lcohol
(200 ppm) and Carbon Dioxide (5000 ppm). Values measure gas and
vapor concentrations in parts per million.
udible larm: 85 dB minimum at 10 feet (3 meters).
REGULATORY INFORMATION FOR SMOKE ALARMS
RECOMMENDED LOCATIONS FOR SMOKE ALARMS
Installing Smoke larms in Single-Family Residences
The National Fire Protection ssociation (NFP ), recommends one
Smoke larm on every floor, in every sleeping area, and in every
bedroom. In new construction, the Smoke larms must be C powered
and interconnected. See " gency Placement Recommendations" for
details. For additional coverage, it is recommended that you install a
Smoke larm in all rooms, halls, storage areas, finished attics, and
basements, where temperatures normally remain between 40˚ F (4.4˚ C)
and 100˚ F (37.8˚ C). Make sure no door or other obstruction could
keep smoke from reaching the Smoke larms.
Continued...
6
