Pro-Tech BE-0986 User Manual

3.5” sbc intel celeron n3350/ pentium n4200 soc/ hdmi/ 12 to 24v
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER
MANUAL
BE-0986 M1
BE-0986
3.5" SBC Intel® Celeron®
N3350/ Pentium® N4200
SoC/ HDMI/ 12 to 24V

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BE-0986 and is the answer not in the manual?

Questions and answers

Related Manuals for Pro-Tech BE-0986

Summary of Contents for Pro-Tech BE-0986

  • Page 1 USER MANUAL BE-0986 3.5” SBC Intel® Celeron® N3350/ Pentium® N4200 SoC/ HDMI/ 12 to 24V BE-0986 M1...
  • Page 2 BE-0986 3.5 SBC Intel® Celeron® N3350/ Pentium® N4200 SoC/HDMI /12 to 24V COPYRIGHT NOTICE & TRADEMARK All trademarks and registered trademarks mentioned herein are the property of their respective owners. This manual is copyrighted in June 2017. You may not reproduce or transmit in any form or by any means, electronic, or mechanical, including photocopying and recording.
  • Page 3 FCC NOTICE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Table Of Contents

    Introduction ..................1-1 About This Manual ..............1-2 Getting Started ..................2-1 Packing List ................2-2 BE-0986 Specifications ............. 2-3 Safety Precautions ..............2-6 Hardware Configuration ..............3-1 JUMPER & CONNECTOR QUICK REFERENCE TABLE ..3-2 COMPONENT LOCATIONS ............. 3-3 3.2.1...
  • Page 5 3.4.10 I2C WAFER ..............3-14 3.4.11 MCU FW Rewrite Connector ........... 3-15 3.4.12 SYSTEM FAN CONNECTOR ......... 3-15 3.4.13 DC POWER INPUT CONNECTOR ......... 3-15 3.4.14 MINI PCI EXPRESS SLOT ..........3-16 3.4.15 mSATA Connector ............3-17 3.4.16 LVDS CONNECTOR ............3-18 3.4.17 SLIDE SWITCH FOR LVDS RESOLUTION SELECTION ..................
  • Page 6 Accessing Setup Utility .............. 5-3 Main ................... 5-6 Advanced .................. 5-8 5.4.1 Advanced - ACPI Settings ..........5-9 Advanced – Onboard Device Configuration ....5-10 5.4.2 Advanced – Hardware Monitor ........5-11 5.4.3 Smart Fan Mode Configuration ........... 5-12 Smart Fan Mode Configuration - [Manual Duty Mode] ....5-13 5.4.4 Advanced - F81966 Watchdog ........
  • Page 7 South Bridge - Miscellaneous Configuration ....... 5-39 Security ................... 5-40 Boot ..................5-42 Save & Exit ................5-44 Appendix A Technical Summary ..........A-1 BE-0986 Block Diagram ................A-2 Interrupt Map ....................A-3 I/O MAP ....................A-20 Memory Map ...................A-22 Configuring WatchDog Timer ..............A-24...

  • Page 8: Introduction

    Introduction This chapter provides the introduction for the BE-0986 system as well as the framework of the user manual. The following topics are included: • About This Manual BE-0986 SERIES USER MANUAL Page: 1-1...

  • Page 9: About This Manual

    It is not intended for general users. The following section outlines the structure of this user manual. Chapter 1 Introduction This chapter provides the introduction for the BE-0986 system as well as the framework of the user manual. Chapter 2 Getting Started This chapter describes the package contents and outlines the system specifications.

  • Page 10: Getting Started

    Getting Started This chapter provides the information for the BE-0986 system. It describes the package contents and outlines the system specifications. The following topics are included: • Package List • System Specification • Safety Precautions Experienced users can go to Chapter 3 Hardware Configuration on page 3-1 for a quick start.

  • Page 11: Packing List

    If you discover any of the items listed above are damaged or lost, please contact your local distributor immediately. Item Q’ty BE-0986 Quick Reference Guide Manual / Driver DVD Mini Jumper (2.0 mm) SATA & SATA Power Cable (150mm) BE-0986 SERIES USER MANUAL Page: 2-2...

  • Page 12: Be-0986 Specifications

    AC power is lost.  GPIO pin header provides 5V power Pin / GND pin.  1 x SATA III port (6.0Gb/sec) SATA Interface  1 x full-sized mSATA slot (with SATA and USB signals) Expansion Slot/mSATA BE-0986 SERIES USER MANUAL Page: 2-3...
  • Page 13  1 x I2C 4-pin wafer  I2C (read/write function) is supported by Protech’s Other I/O, Bus Function Utility & API  1 x 4-pin FAN connector (with speed control/monitoring by API / BIOS) BE-0986 SERIES USER MANUAL Page: 2-4...
  • Page 14  BE-0986RA-D0N: 0°C ~ 60°C (with heatsink)  BE-0986RA-N0N: without heatsink Operating Temp.  BE-0986RA-D1N: 0°C ~ 60°C (with heatsink)  BE-0986RA-N1N: without heatsink  -40°C ~ 85°C Storage Temp.  20%~ 95% Humidity BE-0986 SERIES USER MANUAL Page: 2-5...

  • Page 15: Safety Precautions

    Also avoid the system from any heating device.). Or do not use BE-0986 when it has been left outdoors in a cold winter day. Avoid moving the system rapidly from a hot place to a cold place, and vice •...

  • Page 16: Hardware Configuration

    This chapter contains helpful information about the jumper & connector settings, and component locations. The following sections are included: • Jumper & Connector Quick Reference Table • Component Locations • Configuration and Jumper Settings • Connector Pin Assignments BE-0986 SERIES USER MANUAL Page: 3-1...

  • Page 17: Jumper & Connector Quick Reference Table

    Mini PCI Express Slot M_PCIE1 mSATA Connector M_SATA1 LVDS Connector LVDS1 Front Panel Connector JFP1 HD Audio Connector AUDIO1 Panel Inverter Connector JINV1 SATA 3.0 Connector SATA1 SATA Power Connector SATA_PWR1 BIOS Reset Connector BE-0986 SERIES USER MANUAL Page: 3-2...

  • Page 18: Component Locations

    Make sure both the system and peripheral devices are turned OFF as sudden surge of power could damage sensitive components. Make sure BE-0986 is properly grounded. CAUTION: Observe precautions while handling electrostatic sensitive components. Make sure to ground yourself to prevent static charge while you are working on the connectors and jumpers.

  • Page 19: Jumper Setting Of Be-0986Ra-**N

    COM2 SATA_PWR1 LVDS Backlight M_SATA1 Control Selection COM1 SO_DIMM1 JFP1 3.3V M_PCIE1 (default) AUDIO1 Clear CMOS Data PWR2 Normal Clear CMOS (default) LVDS1 JBAT1 USB3 LVDS VCC Voltage FAN1 JINV1 JP_VDD1 SATA1 3.3V (default) BE-0986 SERIES USER MANUAL Page: 3-4...

  • Page 20: Bottom View Of Be-0986Ra-N0N/ Be-0986Ra-N1N

    Chapter 3 Hardware Configuration 3.2.3 Bottom View of BE-0986RA-N0N/ BE-0986RA-N1N 3.2.4 I/O View of BE-0986RA-**N USB 3.0 HDMI BE-0986 SERIES USER MANUAL Page: 3-5...

  • Page 21: How To Set Jumpers

    PIN1 & PIN2 to create one setting by shorting. You can either connect PIN2 & PIN3 to create another setting. The same jumper diagrams are applied all through this manual. The figure below shows what the manual diagrams look and what they represent. BE-0986 SERIES USER MANUAL Page: 3-6...

  • Page 22: Jumper Settings

    Jumper Block looks like this Jumper Settings 2 pin Jumper close(enabled) Looks like this 3 pin Jumper 2-3 pin close(enabled) Looks like this Jumper Block 1-2 pin close(enabled) Looks like this BE-0986 SERIES USER MANUAL Page: 3-7...

  • Page 23: Setting Connectors And Jumpers

    Setting Connectors and Jumpers 3.4.1 COM3 and COM4 PIN9 Definition Selection Guide JP_COM3, JP_COM4: COM3 and COM4 Port pin9 RI/5V/12V Selection SELECTION JUMPER SETTING JUMPER ILLUSTRATION (Default Setting) JP_COM3 JP_COM4 +12V JP_COM3 JP_ COM4 JP_ COM4 JP_COM3 BE-0986 SERIES USER MANUAL Page: 3-8...

  • Page 24: Com Port

    ASSIGNMENT COM2(RS485) Connector Pin Assignment: ASSIGNMENT ASSIGNMENT Notes: COM2 is selectable as RS232, RS422, RS485 by BIOS setting. Default setting is RS232. Please see Chapter 5 “Advanced – Onboard Device Configuration” for selection details. BE-0986 SERIES USER MANUAL Page: 3-9...
  • Page 25 COM4/ COM4_DTR COM4_RI_SEL Note: COM3, COM4: Pin 9 is selectable for RI, +5V or +12V by jumper setting. Default setting is RI, please see “COM3 and COM4 PIN9 Definition Selection Guide” for selection details. BE-0986 SERIES USER MANUAL Page: 3-10...

  • Page 26: Vga Port

    VGA1: VGA Port, D-Sub 15-pin (I/O port) VGA1 PIN ASSIGNMENT PIN ASSIGNMENT PIN ASSIGNMENT CRT_RED CRT_GREEN CRT_DATA CRT_BLUE CRT_HSYNC CRT_VCC CRT_VSYNC CRT_CLK 3.4.4 HDMI PORT HDMI1: HDMI Port Connector ASSIGNMENT ASSIGNMENT HOT_PLUG_DET I2C_DATA I2C_CLK CLK- CLK+ HDMI1 BE-0986 SERIES USER MANUAL Page: 3-11...

  • Page 27: Lan Port

    Status Description Right Side LED Yellow Blink LAN Message Active No LAN Message Active Left Side LED Green 10/100Mbps LAN connection is enabled. Orange Giga LAN connection is enabled. No LAN switch/hub is connected BE-0986 SERIES USER MANUAL Page: 3-12...

  • Page 28: Dual Usb 3.0 Port (Usb1)

    VCC5_USB1 3.4.7 USB 3.0 PORT (USB2) USB2: USB 3.0 port x 2 USB 3.0 signals PIN ASSIGNMENT PIN ASSIGNMENT USB3_RXN2 USB3_RXP2 USB2_P2_DP USB3_TXN2 USB2_P2_DN USB3_TXP2 VCC5_USB1 USB3_RXN1 USB2 USB3_RXP1 USB2_P1_DP USB3_TXN1 USB2_P1_DN USB3_TXP1 VCC5_USB1 BE-0986 SERIES USER MANUAL Page: 3-13...

  • Page 29: Usb 2.0 Port (Usb3)

    Default setting is GPI every time when system AC power is re-applied from power failure state Configuration can be still kept even in S5 state unless system AC power is lost. 3.4.10 I2C WAFER JI2C1: I2C Wafer PIN ASSIGNMENT VCC5 I2C0_SCL_33 I2C0_SDA_33 JI2C1 BE-0986 SERIES USER MANUAL Page: 3-14...

  • Page 30: Mcu Fw Rewrite Connector

    Default BIOS setting is “Auto Duty-Cycle Mode”. Please see Chapter 5 or check API document for more details. 3.4.13 DC POWER INPUT CONNECTOR PWR2: DC Power Input Connector PIN ASSIGNMENT PIN ASSIGNMENT VCC12 VCC12 PWR2 BE-0986 SERIES USER MANUAL Page: 3-15...

  • Page 31: Mini Pci Express Slot

    Mini PCI Express is the successor of the Mini PCI card and provides an increased data throughput. The cards have a detached network interface and are equipped with one lane. They are used in particular in embedded designs or compact box PCs. BE-0986 SERIES USER MANUAL Page: 3-16...

  • Page 32: Msata Connector

    Chapter 3 Hardware Configuration 3.4.15 mSATA Connector M_SATA1: mSATA Slot (USB type mPCIe card is supported.) ASSIGNMENT ASSIGNMENT V3P3S_MSATA SATA_RXP1 V3P3S_MSATA SATA_RXN1 M_SATA1 SATA_TXN1 SATA_TXP1 USB2_P0_DN USB2_P0_DP V3P3S_MSATA V3P3S_MSATA V3P3S_MSATA BE-0986 SERIES USER MANUAL Page: 3-17...

  • Page 33: Lvds Connector

    Chapter 3 Hardware Configuration 3.4.16 LVDS CONNECTOR LVDS1: LVDS Connector ASSIGNMENT ASSIGNMENT LVDS_VCC LVDS_CLKB_DP LVDS_CLKB_DN LVDS_B2_DN LVDS1 LVDS_B2_DP LVDS_B1_DP LVDS_B1_DN LVDS_B3_DN LVDS_B3_DP LVDS_B0_DN LVDS_B0_DP LVDS_CLKA_DP LVDS_CLKA_DN LVDS_A2_DN LVDS_A2_DP LVDS_A1_DP LVDS_A1_DN LVDS_A0_DN LVDS_A0_DP LVDS_A3_DN LVDS_A3_DP LVDS_VCC LVDS_VCC BE-0986 SERIES USER MANUAL Page: 3-18...

  • Page 34: Slide Switch For Lvds Resolution Selection

    Jumper Name: SW1 Description: Slide Switch for LVDS Resolution/Channel/Color Bit Selection SELECTION SETTING 800 x 600 1CH/18bit (Default Setting) 1024 x 768 1CH/18bit 1024 x 768 1CH/24bit 1280 x 768 1CH/18bit 1280 x 800 1CH/18bit BE-0986 SERIES USER MANUAL Page: 3-19...
  • Page 35 Chapter 3 Hardware Configuration SELECTION SETTING 1280 x 960 1CH/18bit 1280 x 1024 2CH/24bit 1366 x 768 1CH/18bit 1366 x 768 1CH/24bit 1440 x 900 2CH/24bit 1400 x 1050 2CH/24bit BE-0986 SERIES USER MANUAL Page: 3-20...
  • Page 36 Chapter 3 Hardware Configuration SELECTION SETTING 1600 x 900 2CH/24bit 1680 x 1050 2CH/24bit 1600 x 1200 2CH/24bit 1920 x 1080 2CH/24bit 1920 x 1200 2CH/24bit BE-0986 SERIES USER MANUAL Page: 3-21...

  • Page 37: Front Panel Connector

    HDD LED+ POWER LED+ HDD LED- JFP1 RESET BTN POWER BTN 3.4.19 HD AUDIO CONNECTOR AUDIO1: HD Audio Connector for Line_in/Line_out/Mic_in. ASSIGNMENT ASSIGNMENT LINE-OUT-L LINE-OUT-L HD_GND HD_GND HD_LINE-IN-R HD_LINE-IN-L HD_GND HD_GND HD_MIC1-R HD_MIC1-L AUDIO1 BE-0986 SERIES USER MANUAL Page: 3-22...

  • Page 38: Panel Inverter Connector

    JINV1: Panel Inverter Connector ASSIGNMENT VCC12 VCC12 JINV1 LVDS_BKLCTL LVDS_BKLTEN 3.4.21 SATA 3.0 CONNECTOR SATA1: Serial ATA 3.0 Connector ASSIGNMENT SATA_TXP0 SATA_TXN0 SATA1 SATA_RXN0 SATA_RXP0 SATA Power CONNECTOR 3.4.22 SATA_PWR1: Serial ATA Power Connector ASSIGNMENT VCC5 SATA_PWR1 BE-0986 SERIES USER MANUAL Page: 3-23...

  • Page 39: Bios Reset Connector

    JUMPER SETTING JUMPER ILLUSTRATION 3.3V (Default Setting) Note 1: Users can change the setting according to panel specification Note 2: Please refer to PANEL INVERTER CONNECTOR for more details about pin definition of JINV1. BE-0986 SERIES USER MANUAL Page: 3-24...

  • Page 40: Lvds Vcc Voltage Selection

    Description: Voltage selection jumper for selecting PIN1, PIN29, PIN30 (LVDS_VCC) voltage of LVDS1. JUMPTER SELECTION JUMPER ILLUSTRATION SETTING 3.3V (Default Setting) JP_VDD1 JP_VDD1 Note: Please refer to PANEL INVERTER CONNECTOR for more information about pin definition of JINV1. BE-0986 SERIES USER MANUAL Page: 3-25...

  • Page 41: Clear Cmos Data Selection

    Step3. Remove the cap which is just used on JP4 (1-2), so that JP4 returns to “OPEN”. Step4. Power on the PC and the PC will then auto-reboot for once in order to set SoC’s register. Step5. Done! SELECTION JUMPER SETTING JUMPER ILLUSTRATION Open Normal (Default Setting) Clear CMOS* BE-0986 SERIES USER MANUAL Page: 3-26...

  • Page 42: Software Utilities

    The following topics are included: • Installing Intel ® Chipset Software Installation Utility • Installing VGA Driver Utility • Installing LAN Driver Utility • Installing Sound Driver Utility BE-0986 SERIES USER MANUAL Page: 4-1...
  • Page 43 Chapter 4 Software Utilities Introduction Enclosed with the BE-0986 Series package is our driver utilities contained in a DVD-ROM disk. Refer to the following table for driver locations: Filename Win10 (Assume that DVD-ROM Purpose Shell 64-bit drive is D:) ...

  • Page 44: Introduction

    10, and it should be installed immediately after the OS installation is finished. Please follow the steps below: Connect the USB DVD-ROM device to BE-0986 and insert the driver disk. Enter the Main Chip folder where the Chipset driver is located (depending on your OS platform).

  • Page 45: Installing Vga Driver Utility

    Chapter 4 Software Utilities Installing VGA Driver Utility The VGA interface embedded in BE-0986 can support a wide range of display types. You can have triple displays via LVDS, VGA and HDMI interfaces and make the system work simultaneously. To install the VGA driver utility, follow the steps below: Connect the USB DVD-ROM device to BE-0986 and insert the driver disk.

  • Page 46: Installing Lan Driver Utility

    Enhanced with LAN function, BE-0986 supports various network adapters. To install the LAN Driver, follow the steps below: Connect the USB DVD-ROM device to BE-0986 and insert the driver disk. Enter the LAN folder where the driver is located (depending on your OS platform).

  • Page 47: Installing Sound Driver Utility

    Chapter 4 Software Utilities Installing Sound Driver Utility To install the Sound Driver, follow the steps below: Connect the USB DVD-ROM device to BE-0986 and insert the driver disk. Open the Sound folder where the driver is located (depending on your OS platform).

  • Page 48: Bios Setup

    The BIOS Setup Utilities consist of the following menu items: Accessing Setup Utilities • Main Menu • Advanced Menu • Chipset Menu • Security Menu • Boot Menu • Save & Exit Menu • BE-0986 SERIES USER MANUAL Page: 5-1...

  • Page 49: Introduction

    Chapter 5 BIOS Setup Introduction The BE-0986 System uses an AMI (American Megatrends Incorporated) Aptio BIOS that is stored in the Serial Peripheral Interface Flash Memory (SPI Flash) and can be updated. The SPI Flash contains the built-in BIOS setup program, Power-On Self-Test (POST), PCI auto-configuration utility, LAN EEPROM information, and Plug and Play support.

  • Page 50: Accessing Setup Utility

    All the menu settings are described in details in this chapter. Accessing Setup Utility After the system is powered on, BIOS will enter the Power-On Self-Test (POST) routines and the POST message will be displayed: Figure 5-2. POST Screen with AMI Logo BE-0986 SERIES USER MANUAL Page: 5-3...
  • Page 51 English. You may use <↑> or <↓> key to select among the items and press <Enter> to confirm and enter the sub-menu. The following table provides the list of the navigation keys that you can use while operating the BIOS setup menu. BE-0986 SERIES USER MANUAL Page: 5-4...
  • Page 52 Load the previous configuration values. <F3> Load the default configuration values. <F4> Save the current values and exit the BIOS setup menu. <Esc> Close the sub-menu. Trigger the confirmation to exit BIOS setup menu. BE-0986 SERIES USER MANUAL Page: 5-5...

  • Page 53: Main

    No changeable options Displays the date that the current BIOS Time version is built. Access Level No changeable options Displays the current user access level. BXT SOC No changeable options Displays the SOC stepping. BE-0986 SERIES USER MANUAL Page: 5-6...
  • Page 54 The “Day” is automatically changed. System Time Hour, minute, second Sets the system time. The format is [Hour: Minute: Second]. Users can directly enter values or use <+> or <-> arrow keys to increase/decrease it. BE-0986 SERIES USER MANUAL Page: 5-7...

  • Page 55: Advanced

    S5 RTC Wake Settings Sub-Menu RTC wake parameters. CPU Configuration Sub-Menu CPU configuration parameters. F81966 Super IO Sub-Menu System Super IO chip parameters Configuration USB Configuration Sub-Menu USB configuration parameters. Platform Trust Sub-Menu Platform Trust Technology. Technology BE-0986 SERIES USER MANUAL Page: 5-8...

  • Page 56: Advanced - Acpi Settings

    - Enabled (default) Hibernate (OS/S4 Sleep State). This option may be not effective with some OS. Enable Sleep (S3) - Disabled Enables or Disables System ability to Sleep - Enabled (default) (OS/S3 Sleep State). BE-0986 SERIES USER MANUAL Page: 5-9...

  • Page 57: Advanced - Onboard Device Configuration

    Advanced – Onboard Device Configuration 5.4.2 Menu Path Advanced > Onboard Device Configuration Onboard Device Configuration Screen BIOS Setting Options Description/Purpose - RS-422 COM2 Mode - RS-232 (default) Selects COM2 mode. Selection - RS-485 BE-0986 SERIES USER MANUAL Page: 5-10...

  • Page 58: Advanced - Hardware Monitor

    Detects and displays 12V voltage. Detects and displays the voltage level VDDQ No changeable options of the VDDQ in supply. Detects and displays the voltage level VCC3V No changeable options of VCC3V in supply. BE-0986 SERIES USER MANUAL Page: 5-11...

  • Page 59: Smart Fan Mode Configuration

    VSB5V in supply. Detects and displays the battery VBAT No changeable options voltage. Smart Fan Mode Configuration Menu Path Advanced > Hardware Monitor > Smart Fan Mode Configuration Smart Fan Mode Configuration Screen BE-0986 SERIES USER MANUAL Page: 5-12...

  • Page 60: Smart Fan Mode Configuration - [Manual Duty Mode]

    • 60~65°C: 70~100% • > 65°C: 100% Smart Fan Mode Configuration - [Manual Duty Mode] Menu Path Advanced > Hardware Monitor > Smart Fan Mode Configuration > [Manual Duty Mode] Smart Fan Mode Configuration Screen BE-0986 SERIES USER MANUAL Page: 5-13...

  • Page 61: Advanced - F81966 Watchdog

    Advanced - F81966 Watchdog Menu Path Advanced > F81966 Watchdog If the system hangs or fails to respond, enable the F81966 watchdog function to trigger a system reset via the 255-level watchdog timer. F81966 Watchdog Screen BE-0986 SERIES USER MANUAL Page: 5-14...
  • Page 62 BIOS Setting Options Description/Purpose - Disabled (default) Enables/Disables 81966 Watchdog Enable Watchdog - Enabled timer settings. Sets the timeout for Watchdog timer. Watchdog Timer Count (Numeric) 10 to 255 Watchdog Timer = 1sec * Count BE-0986 SERIES USER MANUAL Page: 5-15...

  • Page 63: Advanced - S5 Rtc Wake Settings

    - Fixed Time alarm event. - Dynamic Time • Fixed Time: The system will wake on the time (hr::min::sec) specified. • Dynamic Time: The system will wake on the current time + increased minute(s). BE-0986 SERIES USER MANUAL Page: 5-16...

  • Page 64: S5 Rtc Wake Settings [Fixed Time]

    (Numeric) from 0 to 23 power-on event. Sets a minute for a scheduled Wake up minute (Numeric)from 0 to 59 power-on event. Sets a second for a scheduled Wake up second (Numeric)from 0 to 59 power-on event. BE-0986 SERIES USER MANUAL Page: 5-17...

  • Page 65: S5 Rtc Wake Settings [Dynamic Time]

    S5 RTC Wake Setting Screen (Dynamic Time) BIOS Setting Options Description/Purpose Wake up minute increase (Numeric) from 1 to 5 Sets a period of time (in minutes) to wake up the system after it enters S5 state. BE-0986 SERIES USER MANUAL Page: 5-18...

  • Page 66: Advanced - Cpu Configuration

    CPU power management options. - Disabled When enabled, a VMM can utilize the Intel Virtualization - Enabled (default) additional hardware capabilities Technology provided by Vanderpool Technology. - Disabled (default) VT-d Enables/Disables CPU VT-d. - Enabled BE-0986 SERIES USER MANUAL Page: 5-19...

  • Page 67: Socket 0 Cpu Information

    L1 Data Cache No changeable options L1 Data Cache Size. L1 Code Cache No changeable options L1 Code Cache Size. L2 Cache No changeable options L2 Cache Size. L3 Cache No changeable options L3 Cache Size. BE-0986 SERIES USER MANUAL Page: 5-20...

  • Page 68: Cpu Power Management Configuration

    Advanced > CPU Configuration > CPU Power Management Configuration CPU Power Management Configuration Screen BIOS Setting Options Description/Purpose EIST - Disabled Enables/Disables Intel Speed Step - Enabled feature for dynamic scaling processor (default) frequency. BE-0986 SERIES USER MANUAL Page: 5-21...

  • Page 69: Advanced - F81966 Super Io Configuration

    No changeable options Displays the super I/O chip model. Serial Port 1 Configuration Sub-Menu COM1 parameters. Serial Port 2 Configuration Sub-Menu COM2 parameters. Serial Port 3 Configuration Sub-Menu COM3 parameters. Serial Port 4 Configuration Sub-Menu COM4 parameters. BE-0986 SERIES USER MANUAL Page: 5-22...

  • Page 70: F81966 Super Io Configuration - Serial Port 1 Configuration

    Allows users to change Device's - IO=3F8h; IRQ=4 Resource settings. New settings will - IO=3F8h; IRQ=3,4,5,7,9,10,11,12; be reflected on this Setup Page after - IO=2F8h; IRQ=3,4,5,7,9,10,11,12; System restarts. - IO=3E8h; IRQ=3,4,5,7,9,10,11,12; - IO=2E8h; IRQ=3,4,5,7,9,10,11,12; BE-0986 SERIES USER MANUAL Page: 5-23...

  • Page 71: F81966 Super Io Configuration - Serial Port 2 Configuration

    - Auto (default) Allows users to change Device's - IO=2F8h; IRQ=3 Resource settings. New settings will - IO=3F8h; IRQ=3,4,5,7,9,10,11,12; be reflected on this Setup Page after - IO=2F8h; IRQ=3,4,5,7,9,10,11,12; System restarts. -IO=3E8h; IRQ=3,4,5,7,9,10,11,12; -IO=2E8h; IRQ=3,4,5,7,9,10,11,12; BE-0986 SERIES USER MANUAL Page: 5-24...

  • Page 72: F81966 Super Io Configuration - Serial Port 3 Configuration

    - Auto (default) Allows users to change Device's - IO=3E8h; IRQ=7 Resource settings. New settings will - IO=3E8h; IRQ=3,4,5,7,9,10,11,12; be reflected on this Setup Page after - IO=2E8h; IRQ=3,4,5,7,9,10,11,12; System restarts. - IO=2F0h; IRQ=3,4,5,7,9,10,11,12; -IO=2E0h; IRQ=3,4,5,7,9,10,11,12; BE-0986 SERIES USER MANUAL Page: 5-25...

  • Page 73: F81966 Super Io Configuration - Serial Port 4 Configuration

    - Auto (default) Allows users to change Device's - IO=2E8h; IRQ=10 Resource settings. New settings will - IO=3E8h; IRQ=3,4,5,7,9,10,11,12; be reflected on this Setup Page after - IO=2E8h; IRQ=3,4,5,7,9,10,11,12; System restarts. -IO=2F0h; IRQ=3,4,5,7,9,10,11,12; -IO=2E0h; IRQ=3,4,5,7,9,10,11,12 BE-0986 SERIES USER MANUAL Page: 5-26...

  • Page 74: Advanced - Usb Configuration

    DEVICES: [drive(s)] - Floppy to their media format. Optical drives - Forced FDD are emulated as 'CD-ROM'. Drives - Hard Disk with no media will be emulated - CD-ROM according to a drive type. BE-0986 SERIES USER MANUAL Page: 5-27...

  • Page 75: Advanced - Platform Trust Technology

    Advanced - Platform Trust Technology Menu Path Advanced > Platform Trust Technology The Platform Trust Technology allows users to configure TPM settings. Platform Trust Technology BIOS Setting Options Description/Purpose - Enabled fTPM Enables/Disables fTPM. - Disabled (default) BE-0986 SERIES USER MANUAL Page: 5-28...

  • Page 76: Chipset

    This menu allows users to configure advanced Chipset settings such as North Bridge and South Bridge configuration parameters. Chipset Screen BIOS Setting Options Description/Purpose North Bridge Sub-menu North Bridge Parameters. South Bridge Sub-menu South Bridge Parameters. BE-0986 SERIES USER MANUAL Page: 5-29...

  • Page 77: Chipset - North Bridge

    "8192 MB (LPDDR3)". Memory Speed No changeable options Displays memory speed. Memory Slot0 No changeable options Displays the current amount and type of memory on each memory slot, e.g. "8192 MB (LPDDR3)". BE-0986 SERIES USER MANUAL Page: 5-30...

  • Page 78: Chipset - South Bridge

    Description/Purpose HD-Audio Configuration Sub-Menu HD-Audio configuration settings. LPSS Configuration Sub-Menu LPSS configuration settings. PCI Express Configuration Sub-Menu PCI Express configuration settings. SATA Drives Sub-Menu SATA Drives configuration settings. Miscellaneous Configuration Sub-Menu Miscellaneous configuration settings BE-0986 SERIES USER MANUAL Page: 5-31...

  • Page 79: South Bridge - Hd-Audio Configuration

    Chapter 5 BIOS Setup South Bridge - HD-Audio Configuration Menu Path Chipset > South Bridge > HD-Audio Configuration HD-Audio Configuration Screen BIOS Setting Options Description/Purpose - Disabled HD-Audio Support Enables/Disables HD-Audio support. - Enabled (default) BE-0986 SERIES USER MANUAL Page: 5-32...

  • Page 80: South Bridge - Lpss Configuration

    (D22:F0) - PCI Mode (default) support. - ACPI Mode Set LPSS I2C #1 Speed - Standard Mode Selects LPSS I2C #1 speed. - Fast Mode (default) - Fast Plus Mode - High Speed Mode BE-0986 SERIES USER MANUAL Page: 5-33...

  • Page 81: South Bridge - Pci Express Configuration

    Sub-menu PCIE RP1 parameters (I210 LAN). (I210 LAN) PCI E Express Root Port 2 Sub-menu PCIE RP2 parameters (I210 LAN). (I210 LAN) PCI E Express Root Port 3 Sub-menu PCIE RP3 parameters (Mini-PCIe). (Mini-PCIe) BE-0986 SERIES USER MANUAL Page: 5-34...
  • Page 82 PCI E Express Root Port 1 - Disable Enables/Disables PCIE root port 1 (I210 LAN) - Enable (I210 LAN). - Auto (default) PCIe Speed - Auto (default) Configures PCIe speed. - Gen1 - Gen2 BE-0986 SERIES USER MANUAL Page: 5-35...
  • Page 83 Options Description/Purpose - Disable Enables/Disables PCIE root port 2 PCI E Express Root Port 2 - Enable (I210 LAN). (I210 LAN) Auto (default) PCIe Speed Auto (default) Configures PCIe speed. - Gen1 - Gen2 BE-0986 SERIES USER MANUAL Page: 5-36...
  • Page 84 BIOS Setting Options Description/Purpose PCI E Express Root Port 3 - Disable Enables/Disables PCIE root port 3 (Mini-PCIe) - Enable (Mini-PCIe). Auto (default) PCIe Speed Auto (default) Configures PCIe speed. - Gen1 - Gen2 BE-0986 SERIES USER MANUAL Page: 5-37...

  • Page 85: South Bridge - Sata Drives

    Enables/Disables SATA port 0. - Enabled (default) Displays SATA drive branding No changeable SATA Port 1 information if the device exists on options port 1. - Disabled Port 1 Enables/Disables SATA port 1. - Enabled (default) BE-0986 SERIES USER MANUAL Page: 5-38...

  • Page 86: South Bridge - Miscellaneous Configuration

    Power button is pressed. Wake On Lan - Disable Enables or Disables the Wake-On-LAN. - Enable (default) Win 8/8.1/10 don't support WOL from hybrid shutdown state (S4). If user needs BE-0986 SERIES USER MANUAL Page: 5-39...

  • Page 87: Security

    An administrator has much more privileges over the settings in the Setup utility than a user. Heed that a user password does not provide access to most of the features in the Setup utility. Security Screen BE-0986 SERIES USER MANUAL Page: 5-40...
  • Page 88 <Enter>, and the password dialog entry box appears. Select the configured Administrator Password or User Password that you want to delete. Leave the dialog box blank and press <Enter>. Press <Enter> again when the password confirmation box appears. BE-0986 SERIES USER MANUAL Page: 5-41...

  • Page 89: Boot

    Selects the NumLock sate after the - Off system is powered on. • On: Enables the NumLock function automatically after the system is powered on. • Off: Disables the NumLock function after the system is powered on. BE-0986 SERIES USER MANUAL Page: 5-42...
  • Page 90 - Disabled (default) Enables or Disables Fast Boot - Enabled Options. OS Selection Windows (default) Selects the target OS. - Android - Intel Linux Boot Option #1~#n - [Drive(s)] Sets the system boot order. - Disabled BE-0986 SERIES USER MANUAL Page: 5-43...

  • Page 91: Save & Exit

    Discard Changes and Reset to discard any changes you have made and restore the factory BIOS defaults. Load User Defaults You may simply press F3 at any time to load the Optimized Values which resets all BIOS settings to the factory defaults. Save & Exit Screen BE-0986 SERIES USER MANUAL Page: 5-44...
  • Page 92 Save the changes done so far as User Save as User Defaults No changeable options Defaults. Restore the User Defaults to all the Restore User Defaults No changeable options setup options. Forces to boot from selected Boot Override - [Drive(s)] [drive(s)]. BE-0986 SERIES USER MANUAL Page: 5-45...

  • Page 93: Appendix A Technical Summary

    Appendix A Technical Summary This appendix will give you a brief introduction of the allocation maps for BE-0986 resources. The following topics are included: • BE-0986 Block Diagram • Interrupt Map • I/O Map • Memory Map • Configuring WatchDog Timer •...

  • Page 94: Be-0986 Block Diagram

    Appendix A Technical Summary BE-0986 Block Diagram Page: A-2 BE-0986 SERIES USER MANUAL...

  • Page 95: Interrupt Map

    IRQ 65 Microsoft ACPI-Compliant System IRQ 66 Microsoft ACPI-Compliant System IRQ 67 Microsoft ACPI-Compliant System IRQ 68 Microsoft ACPI-Compliant System IRQ 69 Microsoft ACPI-Compliant System IRQ 70 Microsoft ACPI-Compliant System IRQ 71 Microsoft ACPI-Compliant System BE-0986 SERIES USER MANUAL Page: A-3...
  • Page 96 IRQ 92 Microsoft ACPI-Compliant System IRQ 93 Microsoft ACPI-Compliant System IRQ 94 Microsoft ACPI-Compliant System IRQ 95 Microsoft ACPI-Compliant System IRQ 96 Microsoft ACPI-Compliant System IRQ 97 Microsoft ACPI-Compliant System IRQ 98 Microsoft ACPI-Compliant System BE-0986 SERIES USER MANUAL Page: A-4...
  • Page 97 IRQ 119 Microsoft ACPI-Compliant System IRQ 120 Microsoft ACPI-Compliant System IRQ 121 Microsoft ACPI-Compliant System IRQ 122 Microsoft ACPI-Compliant System IRQ 123 Microsoft ACPI-Compliant System IRQ 124 Microsoft ACPI-Compliant System IRQ 125 Microsoft ACPI-Compliant System BE-0986 SERIES USER MANUAL Page: A-5...
  • Page 98 IRQ 146 Microsoft ACPI-Compliant System IRQ 147 Microsoft ACPI-Compliant System IRQ 148 Microsoft ACPI-Compliant System IRQ 149 Microsoft ACPI-Compliant System IRQ 150 Microsoft ACPI-Compliant System IRQ 151 Microsoft ACPI-Compliant System IRQ 152 Microsoft ACPI-Compliant System BE-0986 SERIES USER MANUAL Page: A-6...
  • Page 99 IRQ 173 Microsoft ACPI-Compliant System IRQ 174 Microsoft ACPI-Compliant System IRQ 175 Microsoft ACPI-Compliant System IRQ 176 Microsoft ACPI-Compliant System IRQ 177 Microsoft ACPI-Compliant System IRQ 178 Microsoft ACPI-Compliant System IRQ 179 Microsoft ACPI-Compliant System BE-0986 SERIES USER MANUAL Page: A-7...
  • Page 100 IRQ 200 Microsoft ACPI-Compliant System IRQ 201 Microsoft ACPI-Compliant System IRQ 202 Microsoft ACPI-Compliant System IRQ 203 Microsoft ACPI-Compliant System IRQ 204 Microsoft ACPI-Compliant System IRQ 256 Microsoft ACPI-Compliant System IRQ 257 Microsoft ACPI-Compliant System BE-0986 SERIES USER MANUAL Page: A-8...
  • Page 101 IRQ 278 Microsoft ACPI-Compliant System IRQ 279 Microsoft ACPI-Compliant System IRQ 280 Microsoft ACPI-Compliant System IRQ 281 Microsoft ACPI-Compliant System IRQ 282 Microsoft ACPI-Compliant System IRQ 283 Microsoft ACPI-Compliant System IRQ 284 Microsoft ACPI-Compliant System BE-0986 SERIES USER MANUAL Page: A-9...
  • Page 102 IRQ 305 Microsoft ACPI-Compliant System IRQ 306 Microsoft ACPI-Compliant System IRQ 307 Microsoft ACPI-Compliant System IRQ 308 Microsoft ACPI-Compliant System IRQ 309 Microsoft ACPI-Compliant System IRQ 310 Microsoft ACPI-Compliant System IRQ 311 Microsoft ACPI-Compliant System BE-0986 SERIES USER MANUAL Page: A-10...
  • Page 103 IRQ 332 Microsoft ACPI-Compliant System IRQ 333 Microsoft ACPI-Compliant System IRQ 334 Microsoft ACPI-Compliant System IRQ 335 Microsoft ACPI-Compliant System IRQ 336 Microsoft ACPI-Compliant System IRQ 337 Microsoft ACPI-Compliant System IRQ 338 Microsoft ACPI-Compliant System BE-0986 SERIES USER MANUAL Page: A-11...
  • Page 104 IRQ 359 Microsoft ACPI-Compliant System IRQ 360 Microsoft ACPI-Compliant System IRQ 361 Microsoft ACPI-Compliant System IRQ 362 Microsoft ACPI-Compliant System IRQ 363 Microsoft ACPI-Compliant System IRQ 364 Microsoft ACPI-Compliant System IRQ 365 Microsoft ACPI-Compliant System BE-0986 SERIES USER MANUAL Page: A-12...
  • Page 105 IRQ 386 Microsoft ACPI-Compliant System IRQ 387 Microsoft ACPI-Compliant System IRQ 388 Microsoft ACPI-Compliant System IRQ 389 Microsoft ACPI-Compliant System IRQ 390 Microsoft ACPI-Compliant System IRQ 391 Microsoft ACPI-Compliant System IRQ 392 Microsoft ACPI-Compliant System BE-0986 SERIES USER MANUAL Page: A-13...
  • Page 106 IRQ 413 Microsoft ACPI-Compliant System IRQ 414 Microsoft ACPI-Compliant System IRQ 415 Microsoft ACPI-Compliant System IRQ 416 Microsoft ACPI-Compliant System IRQ 417 Microsoft ACPI-Compliant System IRQ 418 Microsoft ACPI-Compliant System IRQ 419 Microsoft ACPI-Compliant System BE-0986 SERIES USER MANUAL Page: A-14...
  • Page 107 IRQ 440 Microsoft ACPI-Compliant System IRQ 441 Microsoft ACPI-Compliant System IRQ 442 Microsoft ACPI-Compliant System IRQ 443 Microsoft ACPI-Compliant System IRQ 444 Microsoft ACPI-Compliant System IRQ 445 Microsoft ACPI-Compliant System IRQ 446 Microsoft ACPI-Compliant System BE-0986 SERIES USER MANUAL Page: A-15...
  • Page 108 IRQ 467 Microsoft ACPI-Compliant System IRQ 468 Microsoft ACPI-Compliant System IRQ 469 Microsoft ACPI-Compliant System IRQ 470 Microsoft ACPI-Compliant System IRQ 471 Microsoft ACPI-Compliant System IRQ 472 Microsoft ACPI-Compliant System IRQ 473 Microsoft ACPI-Compliant System BE-0986 SERIES USER MANUAL Page: A-16...
  • Page 109 IRQ 494 Microsoft ACPI-Compliant System IRQ 495 Microsoft ACPI-Compliant System IRQ 496 Microsoft ACPI-Compliant System IRQ 497 Microsoft ACPI-Compliant System IRQ 498 Microsoft ACPI-Compliant System IRQ 499 Microsoft ACPI-Compliant System IRQ 500 Microsoft ACPI-Compliant System BE-0986 SERIES USER MANUAL Page: A-17...
  • Page 110 Intel(R) I210 Gigabit Network Connection IRQ 4294967288 Intel(R) I210 Gigabit Network Connection IRQ 4294967289 Intel(R) USB 3.0 eXtensible Host Controller - 1.0 (Microsoft) IRQ 4294967290 Intel(R) Trusted Execution Engine Interface IRQ 4294967291 Intel(R) HD Graphics BE-0986 SERIES USER MANUAL Page: A-18...
  • Page 111 Express Root Port - 5AD9 IRQ 4294967294 Intel(R) Celeron(R)/Pentium(R) Processor PCI Express Root Port - 5AD8 Note: These resource information were gathered using Windows 10 (the IRQ could be assigned differently depending on OS). BE-0986 SERIES USER MANUAL Page: A-19...

  • Page 112: I/O Map

    0x00000067-0x00000067 Motherboard resources 0x00000070-0x00000070 Motherboard resources 0x00000070-0x00000070 System CMOS/real time clock 0x00000078-0x00000CF7 PCI Express Root Complex 0x00000080-0x0000008F Motherboard resources 0x00000092-0x00000092 Motherboard resources 0x000000A0-0x000000A1 Programmable interrupt controller 0x000000A4-0x000000A5 Programmable interrupt controller 0x000000A8-0x000000A9 Programmable interrupt controller BE-0986 SERIES USER MANUAL Page: A-20...
  • Page 113 0x0000164E-0x0000164F Motherboard resources 0x0000D000-0x0000DFFF Intel(R) Celeron(R)/Pentium(R) Processor PCI Express Root Port - 5AD9 0x0000E000-0x0000EFFF Intel(R) Celeron(R)/Pentium(R) Processor PCI Express Root Port - 5AD8 0x0000F000-0x0000F03F Intel(R) HD Graphics 0x0000F040-0x0000F05F Intel(R) Celeron(R)/Pentium(R) Processor SMBUS - 5AD4 BE-0986 SERIES USER MANUAL Page: A-21...

  • Page 114: Memory Map

    Intel(R) Celeron(R)/Pentium(R) Processor SMBUS - 5AD4 0x91100000-0x911FFFFF Intel(R) Celeron(R)/Pentium(R) Processor PCI Express Root Port - 5AD9 0x91280000-0x912FFFFF Intel(R) I210 Gigabit Network Connection #2 0x9127C000-0x9127FFFF Intel(R) I210 Gigabit Network Connection #2 0x91180000-0x911FFFFF Intel(R) I210 Gigabit Network Connection BE-0986 SERIES USER MANUAL Page: A-22...
  • Page 115 Intel(R) Trusted Execution Engine Interface 0x80000000-0x8FFFFFFF Intel(R) HD Graphics 0x91314000-0x91315FFF Standard SATA AHCI Controller 0x9131A000-0x9131A0FF Standard SATA AHCI Controller 0x91319000-0x913197FF Standard SATA AHCI Controller 0x7B800001-0x7BFFFFFF PCI Express Root Complex 0x7C000001-0x7FFFFFFF PCI Express Root Complex BE-0986 SERIES USER MANUAL Page: A-23...

  • Page 116: Configuring Watchdog Timer

    To exit the Extended Function Mode, writing 0xAA to the EFER is required. Once the chip exits the Extended Function Mode, it is in the normal running mode and is ready to enter the configuration mode. BE-0986 SERIES USER MANUAL Page: A-24...
  • Page 117 ;------------------------------- Enable Watch PME-------------------------------------------- dx, al dx, al ;-------------------------- Set second as counting unit -------------------------------------- dx, al dx, al ;-------------------------- Start the watchdog timer -------------------------------------- dx, al ;---------------------------------Exit the extended function mode ------------------------- dx, al BE-0986 SERIES USER MANUAL Page: A-25...

  • Page 118: Flash Bios Update

    (3) The system will go into the BIOS setup menu. (4) Select [Boot] menu. (5) Set the USB bootable device to be the 1st boot device. (6) Press F4 to save the configuration and exit the BIOS setup menu. BE-0986 SERIES USER MANUAL Page: A-26...
  • Page 119 ?” to see all the definition of each control options. The recommended options for BIOS ROM update include following parameters: Program main BIOS image. /B: Program Boot Block. /N: Program NVRAM. /X: Don’t check ROM ID. BE-0986 SERIES USER MANUAL Page: A-27...
  • Page 120 Restart the system and boot up with the new BIOS configurations. The BIOS Update is completed after the system is restarted. Reboot the system and verify if the BIOS version shown on the initialization screen has been updated. BE-0986 SERIES USER MANUAL Page: A-28...
  • Page 121 Appendix A Technical Summary BE-0986 SERIES USER MANUAL Page: A-29...

  • Page 122: Revision History

    Revision History The revision history of BE-0986 User Manual is described below: Version No. Revision History Page No. Date Initial Release 2017/06/30 Page: A-30 BE-0986 SERIES USER MANUAL...

Table of Contents
