SPECIFICATIONS:
LED Chips: 204 pcs
Total Power: 12W
CRI (Color Rendering Index) RA: 0-90%
Luminous Flux: 1440 lumens at 1 meter
COMPONENTS:
LED Panel
1. Shoe Adapter
1. Shoe Adapter: Used to attach the LED panel to any standard shoe mount or 1/4 20 male thread.
2. Color Temperature Knob: Adjust LED color temperature from 3200K to 5600K.
3. Battery Mount: Location for mounting the included NP-F750 battery
4. Power Adjustment Knob: Allows stepless light output adjustment
5. Battery Power Level Indicator: Indicates current battery power level.
6. Test Button: Press to check the current battery power level.
7. Power Switch: Used to turn the LED panel on/o
8. AC Power Plug: Allows use of the included AC power supply to run the
LED panel from available AC power source.
LUMINOUS PRO LED VIDEO LIGHT
USER MANUAL LED204
2. Color Temperature Knob
3. Battery Mount
4. Power Adjustment Knob
Voltage: DC 6-17V
Color Temperature: 3200K ~ 5500K
Stepless adjustment of both Kelvin
temperature and power
5. Battery Power Level Indicator
6. Test Button
7. Power Switch
8. AC Power Plug
Advertisement
Table of Contents
Summary of Contents for Savage LED204
-
Page 1: Specifications
LUMINOUS PRO LED VIDEO LIGHT USER MANUAL LED204 SPECIFICATIONS: LED Chips: 204 pcs Voltage: DC 6-17V Total Power: 12W Color Temperature: 3200K ~ 5500K CRI (Color Rendering Index) RA: 0-90% Stepless adjustment of both Kelvin Luminous Flux: 1440 lumens at 1 meter... - Page 2 AVAILABLE BATTERIES: INSTRUCTIONS: 1. Slide NP-F750 battery into the "Battery Mount"on back of the light. 2. Use Power Switch to power up the Luminous Pro Video Light. 3. Video light can be secured to any standard shoe mount by sliding onto shoe and tightening the knurled knob to secure or screw directly to any 1/4 20 male thread.
