- Page 1 LIN101 RS232 / LAN INTERFACE LIN101 RS232 / LAN INTERFACE 24/02/2004 English ELPRO Video Labs s.r.l. Via della Praia 4/a FERRIERA di BUTTIGLIERA ALTA (TO) - ITALY Tel. +39 0119348778 - FAX +39 0119348779...
- Page 2 LIN101 is a Serial Device Server, the main function of the LIN101 is to network-enable existing serial devices. Using the LIN101 you can add an Ethernet port practically to any serial device with RS232 interface. It is possible to communicate with any serial device from any PC (or other device) connected to the LAN.
- Page 3 There are three basic ways to communicate with the LIN101: • with a serial device controlled via the network using an existing PC software, then you can use the LIN101 to network-enable this serial device and communicate with it from the PC through our Virtual Serial Port Driver (VSPD).
-
Page 4: Lan Ethernet
LIN101 has two operating modes: • Normal Mode: is entered after the powerup, it is in the Normal Mode that the LIN101 performs its Etherne/Serial data routing. Network Programming of the LIN101 can also proceed in the Normal Mode in parallel with the data routing ELPRO Video Labs s.r.l. - Page 5 Serial Programming Mode: is entered pressing the SETUP button or escape sequence is sent into the LIN101 serial port while the LIN101 is in the Normal Mode. This mode is used to program the LIN101’s functioning parameters (Settings) via the serial port 1.3 Status LED signals...
- Page 6 2.2 Serial comunications The serial port of the LIN101 supports TX, RX, CTS, and RTS signals and can work at baudrates up to 115200. In the Normal Mode the serial port transmits the data between the LIN101 and attached serial device (microcontroller). In the Serial Programming Mode the port is used to program the LIN101’s Settings.
- Page 7 Gateway IP when using the LIN101 in the Slave Routing Mode; In the Master Routing Mode the LIN101 needs to be able to send the data to a predefined remote station at any time. This means that not only LIN101’s own IP-address and Data Port Number must be set but also the Destination IP- address and the Destination Data Port Number.
- Page 8 Many clients to one data source operation is achieved by using the LIN101 in the Slave Routing Mode. The LIN101 will reply to any sender in this mode, so any station will be able to access the host serial device with the LIN101 inside.
- Page 9 When Start On Any Character is set to “yes” the LIN101 will accept any character following the end of the previous serial data block as the beginning of the next block. When Start On Any Character is set to “no” the LIN101 will only open the serial data block when one of the preset Start Characters is received.
- Page 10 Serial -> Ethernet buffer the only way to protect the buffer is to enable the RTS/CTS Flow Control in the LIN101 and on the host serial device. This way the LIN101 will be able to signal the host serial device to stop transmitting the data once the buffer becomes full.
- Page 11 PC that can be used as harware installed COMs. 5.2 Programming via RS232 The Device Server Manager is a DST function taht allows to configure all LIN101 network settings or modify them by a PC serial port or through the network LIN101 programming can be done in a following manners: •...
- Page 12 LIN101 RS232 / LAN INTERFACE Select the PC serial communication port connected to the LIN101. ELPRO Video Labs s.r.l. Via della Praia 4/a FERRIERA di BUTTIGLIERA ALTA (TO) - ITALY Tel. +39 0119348778 - FAX +39 0119348779...
- Page 13 In this example the Slave Routing Mode is selected and the connection timeout is disabled, in this case the application can control the serial device indefinitely. ELPRO Video Labs s.r.l. Via della Praia 4/a FERRIERA di BUTTIGLIERA ALTA (TO) - ITALY...
- Page 14 RS232 / LAN INTERFACE No Start and Stop condition are defined, then the TCP packet is completed after the 20 ms timeout as defined. ELPRO Video Labs s.r.l. Via della Praia 4/a FERRIERA di BUTTIGLIERA ALTA (TO) - ITALY Tel. +39 0119348778 - FAX +39 0119348779...
- Page 15 LIN101 RS232 / LAN INTERFACE Attached device serial port parameters: All defined parameters are now sent to the LIN101, and It is possible to connect the LIN101 between the HUB and serial device. Creation of a Virtual COM. Execute the Virtual Serial Port Manager function to create a virtual COM on the PC ELPRO Video Labs s.r.l.
- Page 16 LIN101 RS232 / LAN INTERFACE This tool links a virtual COM with the defined IP-address ELPRO Video Labs s.r.l. Via della Praia 4/a FERRIERA di BUTTIGLIERA ALTA (TO) - ITALY Tel. +39 0119348778 - FAX +39 0119348779...
- Page 17 RS232 / LAN INTERFACE The existing PC software then can interface COM3: as an installed hardware communication port. Note: after the LIN101 configured it is possible to test it by PING command. In DOS environment use the following ping 169.254.100.40 5.3 Port Monitor Log...
-
Page 18: Pin Signal
Ethernet port 10BaseT: RJ45 8 pin fem. Signal no connection no connection no connection no connection Ethernet wiring Wiring between LIN101 and HUB Wiring between two LIN101 Side A Side B Side A Side B Note: wire 1 and 2 twisted pair wire 3 and 6 twisted pair ELPRO Video Labs s.r.l. -
Page 19: Technical Specifications
: 0 ÷ 45° C Security : EN 60065 : EN 55103-1, EN 55103-2, EN 50081 part 1 e 50082 part 1 ELPRO Video Labs s.r.l. Via della Praia 4/a FERRIERA di BUTTIGLIERA ALTA (TO) - ITALY Tel. +39 0119348778 - FAX +39 0119348779...
