Grafton - 3 Drawers Chest
Assembly Instructions
Dimensions
Width - 83cm
Depth - 43cm
Height - 86cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400 800
- Please keep for future reference
397/7697
408/6295
Issue 1 - 05/05/15
Advertisement
Summary of Contents for GRAFTON 397/7697
- Page 1 Grafton - 3 Drawers Chest Assembly Instructions - Please keep for future reference 397/7697 408/6295 Dimensions Width - 83cm Depth - 43cm Height - 86cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400 800...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly . Check you have all the . We do not This product contain components and tools listed on Natural timber; you may recommend the pages 2 and 3. notice some variation in the grain use of power and colour of different component...
- Page 3 Components - Panels Please check you have all the panels listed below Right back foot (84.2 x 4.5cm) Left back foot (84.2 x 4.5cm) Right front foot Left front foot (84.2 x 4.5cm) (84.2 x 4.5cm) Right side panel Left side panel (77.2 x 32.5cm) (77.2 x 32.5cm) Drawer front x 3...
- Page 4 If you have damaged or missing components, Components - Fittings call the Customer Helpline: 03456 400 800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 Assembly Instructions Assembly Instructions Attention: Step 1 Fitting Metal dowels. Screw metal dowels in the parts indicated. Note: Insert metal dowels as far as shown. Do not over tighten. Insert dowels into the Attention: indicated parts.
- Page 6 Assembly Instructions Step 2 Insert dowels into the indicated parts.
- Page 7 Assembly Instructions Step 3 .a) Fit side panel , left front leg and left back together as shown. b) Insert locking nuts where shown. Use a screwdriver to turn locking nuts clockwise to lock. Do not over tighten. Step 4 Attention pre drilled holes Fixing runners.
- Page 8 Assembly Instructions Step 5 .a) Fit side panel , right front leg and right back together. b) Insert locking nuts where shown. Use a screwdriver to turn locking nuts clockwise to lock. Do not over tighten. Step 6 Fixing runners. Attach left runners to the pre drilled holes on left side panel...
- Page 9 Assembly Instructions Step 7 Assembling the cabinet. Fit parts on the left side panel as shown. unfinished side Step 8 Insert 5 locking nuts in the indicated parts. Use a screwdriver to turn locking nuts clockwise to lock. Do not over tighten.
- Page 10 Assembly Instructions Step 9 Fixing right side panel. Fit right side panel on to cabinet. Step 10 Insert 5 locking nuts into rails where shown. Use a screwdriver to turn locking nuts clockwise to lock. Do not over tighten.
- Page 11 Assembly Instructions Step 11 Fixing the top panel. Fit top panel on to cabinet. Insert 4 locking nuts into top panel where shown. Use a screwdriver to turn locking nuts clockwise to lock. Do not over tighten. Step 12 Fixing back panel. Step 12 Step 12 Important:...
- Page 12 Assembly Instructions Step 13 Assembling the drawers: Fit drawer sides to the large drawer front Insert 4 locking nuts into drawer sides where shown. Use a screwdriver to turn locking nuts clockwise to lock. Do not over tighten. Slide large drawer bottom into slots on drawer sides.
- Page 13 Assembly Instructions Step 15 Hook the wheels of the runners on the back of the drawers over the wheels of the runners on the left and right sides, then hold the drawers level and slide backwards into position. Step 16 Adjusting drawers.
-
